- Page 1 POND FILTRATION PUMP STOCK No. 54876. PART No. PFP3500. • INSTRUCTIONS • IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND EFFECTIVE USE OF THIS PRODUCT. 11/2000...
- Page 2 Getting to Know your Filtration pump...............6 Pump Operation ....................7 Maintenance/Spare parts ................8-9 DECLARATION OF CONFORMITY We Draper Tools Ltd., Hursley Road, Chandler’s Ford, Eastleigh, Hampshire. S053 1YF England. Declare under our sole responsibility that the product: Part No:- PFP3500 Stock No:- 54876...
- Page 3 Part No........
- Page 4 IMPORTANT Draper Tools Limited recommends that this machine should not be modified or used for any application other than that for which it was designed. If you are unsure of its relative applications do not hesitate to contact us in writing and we will advise you.
- Page 5 (i.e. red). Fuse covers are available from your Draper Tools stockist. If the fitted plug is not suitable, it should be cut off and destroyed. *The end of the cable should now be suitably prepared and the correct type of plug fitted.
- Page 6 GETTING TO KNOW YOUR FILTRATION PUMP ✚✌ ✙✌ ✕✌ ✛✌ ✘✌ ✗✌ ✖✌ 1. Motor. 2. Filter cover. 3. Filter. 4. Moulded plug and cable. 5. Telescopic extension tube. 6. Spray head. 7. Waterfall flow control.
- Page 7 PUMP OPERATION INSTALLATION Fig1. Fit the telescopic tube onto the pump and select the desired spray head and attach to the tube. The spray head must always be above the water level. Place the pump on a solid and level platform. (FIG 1).
- Page 8 MAINTENANCE Important: Disconnect from the mains supply before carrying out any maintenance procedures. This filtration pump has a watertight syncronus motor, so requires only a small amount of maintenance. 1. The pre-chambered filters and rotor should be cleaned every week, or when the water flow drops excessively.
- Page 9 SPARE PARTS LISTING STOCK No.54876 PART No.PFP3500 PARTS LISTING/DRAWING 06/2000 ✕✌ ✖✌ ✗✌ ✘✌ ✙✌ ✚✌ PART No. STOCK No. DESCRIPTION KEY No. YPFP-R8243 55387 Spray Head (Dome) YPFP-R8308 55408 Telescopic Extension Tube YPFP-R50067 55409 Spray Head (Three Tier) YPFP-R3801...
- Page 10 NOTES - 10 -...
- Page 11 NOTES -11-...
- Page 12 ©Published by Draper Tools Ltd. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd.
