- Page 1 Original Instructions Version 1 85L/min, 2.5HP PETROL WATER PUMP 87680...
-
Page 2: Preface
All photographs and drawings within this manual are document is part of the product; retain it for the life supplied by Draper Tools to help illustrate correct of the product, passing it on to subsequent holders. operation of the product. -
Page 3: Table Of Contents
2. Contents 1. Preface 8. Maintenance and Troubleshooting 15-21 1.1 Product Reference 8.1 General Maintenance 1.2 Revisions 8.2 Cleaning Out Blockages 1.3 Understanding the Safety Content of This 8.3 Draining the Fuel Manual 8.4 Draining the Engine Oil 1.4 Copyright © Notice 8.5 Air Filter Care 2. Contents 8.6 Spark Plug Care 3. -
Page 4: Product Introduction
Net weight: 11kg *Draper Tools recommends using an additive or stabiliser with E10 petrol so the fuel can be safely stored in the fuel tank for longer. Important: The declared noise emissions values have been measured in accordance with a standard test method and may be used for comparing one tool with another. -
Page 5: Health And Safety Information
• Important: DO NOT use this product if it is leaking or • Never transport the machine while the engine is damaged in any way. Contact Draper Tools to discuss running. repair and replacement options. -
Page 6: Additional Health And Safety Instructions For This Water Pump
4. Health and Safety Information Electrical Safety 4.2 Additional Health and Safety Instructions for this Water Pump WARNING! Risk of electric shock. • The engine speed has been set at the factory to ensure safe operation. − This product produces enough electrical power to ... -
Page 7: Health And Safety Information For Machines With A Petrol Engine
E10 fuel before using it in this • NEVER remove the fuel cap while the engine is machine. Draper Tools recommends using an additive or running or immediately after use. stabiliser with E10 petrol to extend the period that it can −... -
Page 8: Identification And Unpacking
5. Identification and Unpacking 5.1 Product Overview (10) (11) (19) (12) (13) (14) (15) (18) (16) (17) Feet (11) Transport handle Exhaust and muffler (12) Pump outlet Water drain (13) Pump Inlet (suction) Spark plug cover (14) Hose barb Fuel tank cap (15) Oil filler cap with dipstick Fuel tank (16) Base frame... -
Page 9: What's In The Box
If any part is occurred during shipment. damaged or missing, do not attempt to use the product. Please contact the Draper Helpline; contact details can be found at the back of this manual. 1 x Pump unit (not shown) -
Page 10: Preparing The Pump
(12). covered hose barb and tighten the clamp screw until • Draper Tools recommends installing a non-return the hose is held securely in place. valve into the suction line to prevent the pump from losing its prime. -
Page 11: Fuelling The Pump
• E10 petrol should be used within 30 days of purchase. Do not use fuels with more than 10% ethanol in Draper products. Important: Ensure that the notches in the fuel filter lip To fuel the machine: are correctly aligned before attaching the fuel tank cap. -
Page 12: Checking And Topping Up The Engine Oil
6. Preparing the Pump 6.3 Checking and Topping Up the Engine Oil ATTENTION This machine is NOT supplied with engine oil. Check the engine oil level before every use. Running the machine with a low oil level oil may cause serious damage to the engine and is not covered by your warranty. -
Page 13: Basic Pump Operation
7. Basic Pump Operation Important: Before operating this product, read and 6. Turn the engine power switch (18) to the ON position. understand all the safety instructions listed in this manual. Ensure that the pump is correctly prepared before use; see 6. Preparing the Pump. (18) Important: Place the pump on a firm and level surface during use. -
Page 14: Stopping The Pump
7. Basic Pump Operation 7.2 Stopping the Pump Important: Before stopping the engine, lower the throttle to idle and allow the engine to run for a few minutes. (19) Fig. 14 If the pump is being stopped temporarily, slide the fuel lever (19) to the off position and turn the engine power switch (18) to the OFF position. -
Page 15: Maintenance And Troubleshooting
Important: DO NOT use solvents as this may damage any plastic or uninsulated parts. 4. To open the impeller housing, remove the six bolts surrounding the inlet (13) and pull the cover away • Use ONLY spare parts supplied by Draper Tools. from the pump. (13) Fig. -
Page 16: Draining The Fuel
8. Maintenance and Troubleshooting 8.3 Draining the Fuel Important: Fuel should be stored in the tank for no more than four weeks. Draper Tools recommends draining the fuel from the pump before storage, particularly if it will be stored for long periods. -
Page 17: Draining The Engine Oil
8. Maintenance and Troubleshooting 8.4 Draining the Engine Oil 8.5 Air Filter Care Important: The engine oil level and condition should be Clean the air filter chamber and element at least after inspected before every use and replaced every three every 50 hours of use or every three months to ensure months or after 50 hours of use. -
Page 18: Spark Plug Care
8. Maintenance and Troubleshooting 8.6 Spark Plug Care 5. Screw the spark plug into place using 20Nm (2mkg, 14ftlb) of torque and replace the spark plug cover Ensure that the spark plug is clean and has the correct securely. gap. The spark plug may become contaminated over time if the machine is run with part-throttle for prolonged ATTENTION periods. -
Page 19: Maintenance Schedule
8. Maintenance and Troubleshooting 8.8 Maintenance Schedule Item Remarks Pre- Initial 1 Every 3 Every 6 Every Year operation months or months or months or or 300Hr check (daily) 20Hr 50Hr 100Hr Spark plug Check condition, adjust gap and clean. Replace if necessary. Engine oil Check oil level. -
Page 20: Troubleshooting
8. Maintenance and Troubleshooting 8.10 Troubleshooting Problem Possible cause Remedy The engine does not start. The engine power key switch is in Press the engine power key switch the OFF position. to the ON position. The fuel or oil level is too low. Check and top up the fuel and oil levels as appropriate (see 6.2 and 6.3). -
Page 21: Spares, Returns And Disposal
Helpline for details of your nearest authorised agent. Draper Tools will endeavour to hold any spare parts, if • DO NOT dispose of this product with domestic waste; applicable, for seven years from the date that it sells the most local authorities provide appropriate recycling final matching stock item. -
Page 22: Warranty
This warranty period covers parts and labour for 12 months from the date of Your Draper Tools guarantee is not effective until you can purchase. Where tools have been hired out, the warranty produce, upon request, a dated receipt or invoice to period covers 90 days from the date of purchase. -
Page 23: Explanation Of Symbols
11. Explanation of Symbols Warning! Read the instruction manual Do not incinerate or throw onto fire Wear face mask and safety glasses For outdoors use only. Wear ear defenders Danger! Wear protective gloves Highly flammable liquid CAUTION! Do not abandon in the environment Risk of electric shock Engine &... - Page 24 Telephone Sales Desk: +44 (0) 23 8049 4333 General Enquiries: +44 (0) 23 8026 6355 General Fax: +44 (0) 23 8026 0784 Please contact the Draper Tools Product Helpline for repair and servicing enquiries. © Published by Draper Tools Limited © Published by Draper Tools Limited...
