ACCESSORIES
Flower guard
Charger
Battery pack
(WA3551.1)
Spool (WA0004)
Safety guard
Edger wheel
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store
personnel can assist you and offer advice.

ASSEMBLY AND OPERATION

NOTE: Before using the tool, read the
instruction book carefully.
Intended Use
The machine is intended for the cutting of grass and
weeds under bushes, as well as on slopes and edges
that can not be reached with the lawn mower.
14
WARNING! The charger and battery pack are
specially designed to work together so do not
attempt to use any other devices. Never insert or
allow metallic objects into your charger or battery
pack connections because of an electrical failure and
hazard will occur.
WARNING! Always wear the eye protection.
Never lean over the trimmer head. Rocks or
debris can ricochet or be thrown into eyes and face
and cause blindness or other serious injury. When
operating unit, check for the following:
Wear eye protection and heavy clothing. Hold front
handle with one hand and auxiliary handle with
the other hand. Keep unit below waist level. Work
only from your right to your left to ensure debris is
thrown away from you. Without bending over, keep
line near and parallel to the ground (perpendicular
when edging) and not crowded into material being
cut.
WARNING! Make sure that line is fed out
before operation. Make sure motor is up
to full speed before trimming or edging.
WARNING! Only use 1.65mm diameter
cutting line. Other sizes of line will not feed
properly and will result in improper cutting head
function or can cause serious injury. Do not use other
2-in-1 Grass Trimmer/Edger
WG163E WG163E.1 WG163E.9
1 1
1 1
(WA3760) (WA3760)
2 1
(WA3551)
1 1
1 1
1 1
material such as wire, string, rope, etc. Wire can
break off during cutting and become a dangerous
projectile that can cause serious injury.
ASSEMBLY & OPERATION
1
/
Assembly
Assembling the Safety Guard
/
Mounting the Edger Wheel
1
WARNING: Make Sure
the ON/OFF Switch
1
is Locked Off to Prevent
1 Accidental Starting.
Installing and Removing the
Battery Pack
Charging the battery pack
More details can be found in
charger's manual
Checking the battery condition
(Only for WG163E.1 )
Operation
Safety ON/OFF Switch
WARNING! The cutting
head continues to rotate
after the trimmer has been
switched off; wait until it has
completely stopped then lay down
the tool.
Trimming
- Adjusting the Shaft
WARNING! Make Sure the
ON/OFF Switch is Locked
Off to Prevent Accidental Starting.
- Adjusting the Trimmer Head
- Adjusting the Auxiliary handle
- Trimming
- Using the Flower Guard
Edging
- Changing the tool into the
Edging mode
- Edging
Command feeding the line
Manually feeding the line
Action
See Fig. A1, A2
See Fig. B
See Fig. C
See Fig. D1
See Fig. D2
See Fig. E
See Fig. F
See Fig. G1, G2
See Fig. H
See Fig. I1
See Fig. I2
See Fig. J1, J2
See Fig. K
See Fig. L
See Fig. M
Figure
