Fronius String Control 250/25 Installation

Dowels and Depending on the surface, different dowels and screws may be required
Screws for installing the Fronius String Control 250/25. Therefore, these dowels
and screws are not part of the scope of supply for the Fronius String
Control 250/25. The installer is responsible for selecting the proper do-
wels and screws.
Installation The Fronius String Control 250/25 can be installed in any position from
Position horizontal to vertical. However, the cable inputs and outputs should point
downwards as much as possible.
Selecting a When selecting the location, please observe the following criteria:
Location -
-
-
-
-
Fronius String
1
Control 250/25
Installation
Install on a solid surface.
The ambient temperature may not fall below -25 °C nor exceed +60 °C.
Protection type IP 55 means that the Fronius String Control 250/25
can be installed outside and be exposed to a certain amount of mois-
ture. However, we do recommend that direct wetting be avoided.
Protect from direct sunlight and direct exposure to the elements.
Install under the solar modules where possible.
1
1
2
3
4
5
2
9
2
3
4
5
