Product Description; Safety - Fronius String Control 250/25 Operating Instructions Manual

Product Description

Safety

Fronius String
Control 250/25
Device De-
scription
Fronius String Control 250/25
Item Description
(1)
(2)
(3)
WARNING! Operating the device incorrectly can cause serious
injury and damage. The following documentation should be
read and understood in its entirety before the described func-
tions are carried out:
- These operating instructions
- All system component operating instructions including safety
instructions
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12) (13)
Upper mounting clip
Address switch
Terminals with fuse holders for DC cable 'IN'
Cable cross section 2.5 - 6 mm²
