Max Re-Bar-Tier Twintier RB441T Instruction Manual And Safety Instructions
  1. Manuals
  2. Brands
  3. Max Manuals
  4. Tools
  5. Twintier RB441T
  6. Instruction manual and safety instructions

Max Re-Bar-Tier Twintier RB441T Instruction Manual And Safety Instructions

Rebar tying tool
Hide thumbs Also See for Re-Bar-Tier Twintier RB441T:

Advertisement

Quick Links

Download this manual
REBAR TYING TOOL
OUTIL DE LIGATURE DE BARRES
ATADORA DE ARMADURAS DE REFUERZO
INSTRUCTION MANUAL AND SAFETY INSTRUCTIONS
MODE D'EMPLOI ET CONSIGNES DE SÉCURITÉ
MANUAL DE INSTRUCCIONES E INSTRUCCIONES DE SEGURIDAD
INDEX
SOMMAIRE
ÍNDICE
Before using the tool, read and understand tool labels and manual. Failure to
follow warnings could result in serious injury. Keep these instructions with the
tool for future reference.
WARNING
Veillez à lire et bien comprendre les étiquettes et le manuel avant d'utiliser cet
outil. Tout manquement au respect des avertissements peut entraîner des
blessures graves. Conservez ces instructions avec l'outil pour toute
AVERTISSEMENT
consultation ultérieure.
Lea y comprenda las etiquetas y el manual de la herramienta antes de usarla.
El incumplimiento de las advertencias puede provocar lesiones graves.
Conserve estas instrucciones junto con la herramienta para futuras consultas.
ADVERTENCIA
RB441T
ENGLISH
Page
FRANÇAIS
Page
ESPAÑOL
Página
(
CE
2
to
17
18
à
32
33
a
48
)

Advertisement

loading
Need help?

Need help?

Do you have a question about the Re-Bar-Tier Twintier RB441T and is the answer not in the manual?

Questions and answers

Callan Taborsky
May 9, 2025

after tying one tie it beeps 3 times 3 times and wont tie after turn it on it does the same thing ties once then beeps

0
1 comments:
Mr. Anderson
May 19, 2025

When the Max Re-Bar-Tier Twintier RB441T beeps three times and stops tying after the first tie, it means the Tiewire is used up. You should open the Magazine cover and replace it with a new Tiewire.

This answer is automatically generated

0
Rob
March 28, 2025

I have a long high beep no response from mechanism

0
1 comments:
Mr. Anderson
March 28, 2025

A long high beep with no response (piii...) indicates that the bending guide (Fig.1.0) is open. You should confirm that the rebar diameters being used are compatible.

This answer is automatically generated

0

Related Manuals for Max Re-Bar-Tier Twintier RB441T

Summary of Contents for Max Re-Bar-Tier Twintier RB441T

  • Page 1 REBAR TYING TOOL OUTIL DE LIGATURE DE BARRES ATADORA DE ARMADURAS DE REFUERZO RB441T INSTRUCTION MANUAL AND SAFETY INSTRUCTIONS MODE D'EMPLOI ET CONSIGNES DE SÉCURITÉ MANUAL DE INSTRUCCIONES E INSTRUCCIONES DE SEGURIDAD INDEX ENGLISH Page SOMMAIRE FRANÇAIS Page à ÍNDICE ESPAÑOL Página Before using the tool, read and understand tool labels and manual.
  • Page 2 Fig.1 ① ⑫ ⑪ ⑩ ⑬ ⑭ ② ⑨ ③ ④ ⑧ ⑯ ⑤ ⑮ ⑦ ⑥ ⑳ ⑲ ⑰ ⑱ Fig.2 Fig.3 Fig.4 Fig.5 Fig.6 ③ ② ② ⑮ ⑤ LOCK...
  • Page 3 Fig.7 Fig.8 Fig.9 PUSH ⑨ ⑧ Fig.10 Fig.11 Fig.12 ⑦ ⑥ Fig.13 Fig.14 Fig.15 ⑲ Fig.16 Fig.17 Fig.18 ⑨ ⑱ ⑥ Fig.19 Fig.20 Fig.21 45° ② ⑮...
  • Page 4 Fig.22 Fig.23 Fig.24 ⑪ ⑪ Fig.25 Fig.26 Fig.27 ⑬ Fig.28 Fig.29 Fig.30 Fig.31...
  • Page 5 ENGLISH Original instructions INSTRUCTION MANUAL AND SAFETY INSTRUCTIONS INDEX 1. NAME OF PARTS................. 6 2. LIST OF CONTENTS ..............6 3. GENERAL POWER TOOL SAFETY WARNINGS ....... 7 4. RB441T SAFETY FEATURES............9 5. TOOL SPECIFICATIONS AND TECHNICAL DATA....11 6.
  • Page 6 Magazine cover Fig.13 o Holding slot 2. LIST OF CONTENTS • MAX Rebar Tying tool / RB441T(CE) • Lithium ion Battery pack / JPL91440A • Lithium ion Battery charger / JC925(CE) • Power cord • INSTRUCTION MANUAL AND SAFETY INSTRUCTIONS (This book)
  • Page 7 3. GENERAL POWER TOOL outdoor use reduces the risk of electric shock. SAFETY WARNINGS • If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
  • Page 8 • Do not use the power tool if the switch • Under abusive conditions, liquid may does not turn it on and off. Any power be ejected from the battery; avoid tool that cannot be controlled with the contact. If contact accidentally occurs, switch is dangerous and must be flush with water.
  • Page 9 Failure to do so may lead to serious injury. replaced or repaired, purchase the Return to dealer for safety inspection. replacement part at the dealer where the tool was purchased or MAX CO., LTD. 9. NEVER MODIFY THE TOOL authorized distributors. Modifying the tool will impair performance and Use only genuine authorized replacement operating safety.
  • Page 10 13-2 Charge the Battery from AC between 13-14 Handle the power cord carefully. 220V and 240V wall sockets. Do not carry the Battery charger by its Failure to do so may result in power cord. Do not use the power cord overheating, or inadequate charging to disconnect it from a wall socket;...
  • Page 11 5. TOOL SPECIFICATIONS AND TECHNICAL DATA PRODUCT DESCRIPTION MAX Rebar Tying tool “TWINTIER” PRODUCT NO. RB441T(CE) DIMENSIONS (Battery pack included) (H)295mm x (W)120mm x (L)330mm WEIGHT (Battery pack included) 2.5kg / 5.6lbs BATTERY Lithium ion Battery pack / JPL91440A OPERATING TEMPERATURE -10°C to 40°C / 14°F to 104°F...
  • Page 12 6. TECHNICAL DATA 6-1 NOISE Measured value according to EN 60745: A-weighted sound pressure level (LpA): 79 dB Uncertainty (KpA): 3dB A-weighted sound power level (LWA): 79 dB Uncertainty (KWA): 3dB 6-2 VIBRATION Measured value according to EN 60745: Vibration total values (ah): 0.5 m/s Uncertainty (K): 0.1 m/s •...
  • Page 13 8. WIRE SPECIFICATION TIEWIRE TW1061T TW1061T-PC TW1061T-EG TYPE OF WIRE Electro-galvanized Annealed wire Poly-coated wire wire DIAMETER 1.0mm 1.1mm 1.0mm TIES/COIL 10 mm × 10 mm / #3 × #3 Approx. 265 ties Approx. 230 ties Approx. 265 ties 13 mm × 13 mm / #4 × #4 Approx.
  • Page 14 Recycling a Li-ion Battery The MAX battery pack uses a Li-ion battery, it may be illegal to dispose of this Battery into the municipal waste system. Check with your local solid waste officials for details in your area for recycling options or proper disposal.
  • Page 15 2-3 (Fig.21) Tilt the tool 45° angle to the crossed specified may cause breakdown of this tool. rebars. Therefore, be sure only to use the specified MAX 2-4 (Fig.22) Align the Center mark (a) to the TW1061T series. center of the crossed rebars.
  • Page 16 13.STORAGE 3-2 (Fig.11) Rotate the Magazine stopper (6) to open the Magazine cover. 3-3 (Fig.24) Remove the Tiewire from the Do not store the tool in a cold weather Magazine. environment. Keep the tool in a warm area. 3-4 (Fig.25) Remove the wire with the plastic When not in use, the tool should be stored in a piece from the Wire guide.
  • Page 17 Then contact the (Pipo / Pii poh Pii poh...) dealer where the tool was purchased or MAX CO., LTD. authorized distributors. <When no buzzer sounds but malfunction is suspected> Symptom Possible cause Procedures to follow Main switch is "ON"...
  • Page 18 RB441T(CE) EXPLODED SCHEMA ECLATE ET LISTE DES DESPIECE DE LA MAQUINA Y LISTA VIEW AND SPARE PARTS LIST PIECES DE RECHANGE DE RECAMBIOS...
  • Page 19 RB441T(CE) ITEM PART MATERIAL ENGLISH FRANÇAIS ESPAÑOL RB70618 Steel ARM A ASSY ENSEMBLE DU BRAS CONJUNTO DE BRAZO “A” BB40481 Steel BOLT 3X5 BOULON 3X5 PERNO 3X5 AA71408 Steel SCREW M3X3 VIS M3X3 TORNILLO M3X3 RB12633 Steel WIRE GUIDE BASE BASE DU GUIDE FIL BASE DE GUÍA DEL ALAMBRE RB81278...
  • Page 20 RB441T(CE) ITEM PART MATERIAL ENGLISH FRANÇAIS ESPAÑOL FF21234 Steel SPRING PIN 3X12 GOUPILLE ÉLASTIQUE 3X12 PERNO DE MUELLE 3X12 RB12617 Steel CUTTER RING BAGUE DE COUTEAU ANILLO DE CORTADORA RB12618 Steel CUTTER RING GUIDE GUIDE DE BAGUE DE COUTEAU GUÍA DE ANILLO DE CORTADORA JJ21606 Steel C-RING 15...
  • Page 21 RB441T(CE) ITEM PART MATERIAL ENGLISH FRANÇAIS ESPAÑOL CONJUNTO DE CUBIERTA DE RB81289 PA, Steel, etc MAGAZINE COVER ASSY ENSEMBLE DE COUVERCLE DU MAGASIN COMPARTIMENTO DE BOBINA RB81284 PA, Steel MAGAZINE COVER UNIT COUVERCLE DU MAGASIN CUBIERTA DE COMPARTIMENTO DE BOBINA AA05560 Steel SCREW 3X12 CF...
  • Page 22 RB441T(CE) ITEM PART MATERIAL ENGLISH FRANÇAIS ESPAÑOL BB40716 Steel BOLT 3X6 CF BOULON 3X6 CF PERNO 3X6 CF RB70629 PA, Steel, POM, etc FRAME R ASSY(441T) ENSEMBLE DU CADRE R (441T) CONJUNTO DE ARMAZÓN DERECHO (441T) RB70616 Steel JAW BASE ASSY BASE DE MACHOIRE ASSY CONJUNTO DE BASE DE MORDAZA RB12627...
  • Page 24 Camerastraat 19,1322 BB Almere, Holanda Service Environnement & Assurance Qualité Questa dichiarazione di conformità viene emessa sotto la responsabilità esclusiva del En tant que personne responsable désignée par le fabricant et employée par MAX produttore indicato in precedenza. CO., LTD.
  • Page 25 • Le contenu du présent manuel est sujet à modification sans préavis, en vue d'y apporter des améliorations. • El contenido de este manual puede sufrir modificaciones sin previo aviso para la introducción de mejoras. Camerastraat 19 1322 BB Almere The Netherlands Phone: +31-36-546-9669 FAX: +31-36-536-3985 sales@max-europe.com www.max-europe.com 4100252 171025-00/01 PRINTED IN JAPAN...
