Uwatec A2 Quick Use Manual

PAIRING YOUR TRANSMITTER
Mount the 1st stage regulator with the Smart transmitter on a full tank.
❚
Set the A2 to pairing mode (Main Menu > Gas > Pairing) and press
❚
SEL/ESC. The display now shows "pair tank".
Place the A2 near the transmitter.
❚
Open the tank valve, and you are ready to go.
❚
Once pressurized the transmitter will send a pairing sequence to the A2.
❚
When the A2 receives this information, the display changes to show a
❚
listing of tank designations.
Scroll to Tank T1. (Tank T1 is always the main tank you start your dive with.)
❚
Press SEL/ESC to save your selection.
❚
The current pressure of the paired tank will appear on the bottom row
❚
in either BAR or PSI.
HOW TO POSITION AND USE THE HEART RATE MONITOR
Position your HR belt (as shown on the left).
❚
Adjust the strap so that it is comfortable to wear but snug enough so that it stays in place.
❚
HR belt must be worn directly against the skin.
❚
Moisten the electrode areas if your skin is dry or when diving in a drysuit.
❚
The maximum operating depth for the HR belt is 197ft/60m.
❚
HOW TO ACTIVATE THE HEART RATE FUNCTION ON YOUR A2
Go to Main Menu >Settings > User > Workload.
❚
Scroll to Heart Rate and select ON – press SEL/ESC to confirm.
❚
Set your maximum & base HR limits – press SEL/ESC to confirm.
❚
Heart Rate & Skin Temperature functions are now activated.
❚
For more information and to view this card in other languages, visit http://www.scubapro.com
Initial activation:
activate the A2 with a press-and-hold of the bottom left (SEL/ESC) button before the first dive.
Initial activation
requires basic set-up
BUTTONS
Press
The act of pressing and releasing
one of the buttons
Press-and-hold
The act of pressing and holding
one of the buttons for 1 second
before release
Press
The act of pressing and releasing
one of the buttons
Press-and-hold
The act of pressing and holding
one of the buttons for 1 second
A2 Quick Use Guide before release
QUICK USE GUIDE
The A2 is delivered in deep sleep mode where the display is off. You must
Settings Watch Set Time
Set Time
›
› ›
Set Date Settings Watch Set Date
›
› ›
Set Units Settings User Units
›
› ›
Settings Watch Format
Set Time Format
›
› ›
Settings Watch Design
Display Design
› › ›
Button Functions on the Surface
TOP LEFT TOP RIGHT BOTTOM RIGHT
BUTTON BUTTON
(Light) (+/UP)
Adds numerical values Subtracts numerical values
Backlight
Toggles up to the previous menu Toggles down to the next menu
From main time & date display:
shows the selected Dive Mode
From main time & date display:
Launch compass
Shortcut to dive ready mode
From selected dive mode
display: starts swim mode
Button Functions during Diving
Backlight Scrolls through dive displays Scrolls through dive displays
In "timer" display: stop / restart
Reset timer when stopped
timer (SCUBA and GAUGE mode)
Launch compass
Reset average depth counter
In "surface interval" display:
end Apnea exercise (APNEA mode)
(GAUGE mode)
A2
+/UP or -/Down to Select Hours & Minutes
›
+/UP or -/Down to Select Month, Day & Year
›
+/UP or -/Down to Select Measurement Units
›
+/UP or -/Down to Select Time & Date Format
›
+/UP or -/Down to Select Time Display Design
›
BOTTOM LEFT BUTTON
BUTTON
(SEL/ESC)
(-/DOWN)
Access main menu and submenus
Confirm selection / setting
Return to previous menu or cancel the setting
From main time & date display when SCUBA
mode selected: shows current gas settings
Set bookmarks
Manual gas switch
(SCUBA & GAUGE mode) (SCUBA & GAUGE mode)
In "surface interval" display:
end Apnea exercise (APNEA mode)
