Triax CCT 391 Assembly Instructions Manual

Head-end receiver modulator

Advertisement

Quick Links

Head-end Receiver Modulator
CCT 391
CCT 393
CCT 394
CCT 395
A A
C LASS
CLASS
Art. No. 325115 / 325116 / 325117 / 325118
GB
Assembly Instructions
TRIAX - your ultimate connection

Advertisement

Table of Contents
loading

Summary of Contents for Triax CCT 391

  • Page 1 Head-end Receiver Modulator CCT 391 CCT 393 CCT 394 CCT 395 C LASS CLASS Art. No. 325115 / 325116 / 325117 / 325118 Assembly Instructions TRIAX - your ultimate connection...
  • Page 2: Table Of Contents

    Contents 1 Safety regulations ....................3 2 General information .................... 4 2.1 Scope of delivery ................... 4 2.2 Meaning of the symbols used ..............4 2.3 Technical specifications ................4 2.4 Description ................... 5 2.4.1 Software query ................5 3 Installation ......................6 3.1 Installing the cassette in the head-end station ..........
  • Page 3: Safety Regulations

    Safety regulations • Assembly, installation and servicing should be carried out by authorised electricians. • Switch off the operating voltage of the system before beginning with as- sembly or service work or pull out the mains plug. • Do not perform installation and service work during thunderstorms. •...
  • Page 4: General Information

    General information 2.1 Scope of delivery 1 CCT 391 or CCT 393 or CCT 394 or CCT 395 cassette 1 CD (assembly instructions) 2.2 Meaning of the symbols used Important note —> General note • Performing works 2.3 Technical specifications...
  • Page 5: Description

    Output level: typ. 98 dBµV 75 Ω Output impedance: Connections: HF input: IEC socket HF output: IEC socket 10-pin connector for all supply voltages and for the I C bus. 2.4 Description The cassettes are frequency converters and convert two incoming analogue sig- nals into two outgoing analogue signals with free selectable frequency (s.
  • Page 6: Installation

    Installation 3.1 Installing the cassette in the head-end station – Ensure the head-end station is mounted so it will not be able to vibrate. Avoid, for example, mounting the head-end station onto a lift shaft or any other wall or floor construction that vibrates in a similar way. –...
  • Page 7: Emc Regulations

    3.2 EMC regulations To comply with the current EMC regulations, it is necessary to connect the lines leading in and out of the head-end station using cable terminals. When mounting the cassette in an CSE 3319 head-end station which is in- stalled in a 19”...
  • Page 8: The Control Panel At A Glance

    The control panel at a glance 4.1 Menu items Program the cassette using the buttons on the control unit of the head-end sta- tion. The two-line display of the control unit then shows the menus. Use the key to select the following BE–Remote V 40 main menu items:...
  • Page 9: Programming

    Programming The following examples show how the CCT 393 cassette is programmed; the out- put channels can be set from S03 … S24. Set the other cassettes listed in the same way. 5.1 Programming procedure BE–Remote V 40 Ein/On Please wait ... t >...
  • Page 10: Programming The Cassette

    5.2 Programming the cassette —> Pressing the button for longer than 2 seconds cancels the pro- gramming procedure. This takes you back to the program item “Selecting the cassette / channel strip” from any menu. Any entries that have not been saved are reset to the previous settings.
  • Page 11: Compare/Adjust The Hf Output Level Of The Channel Strips

    • For measuring the HF output level of the channel strip, press the button. —> The “Compare/adjust the HF output level of the channel strips” – “Level HF Out:” sub-menu is activated • if the output level has not been set, press —>...
  • Page 12: Setting The Output Channel

    • Press the button. —> The “Setting the output channel” – “OUTPUT:” menu is activated. Setting the output channel Bx 1A OUTPUT: Bx 1A OUTPUT: Fine • Use to set the output channel. —> The channel range that can be set depends on the type of cassette used.
  • Page 13: Setting The Input Channel

    Setting the input channel Bx 1A INPUT: Bx 1A INPUT: 63 … -64 Fine • Use to set the input channel. Setting the fine-tuning • If necessary press down until “Fine 0” also ap- ▶ pears in the display. • Use the buttons to fine-tune the output channel (63 …...
  • Page 14: Saving Settings

    Saving settings • Press the button. —> The settings are saved. —> Back to the “Selecting the cassette / channel strip” menu via connection (page 10). —> By pressing the button, you will be returned to the menu item “Selecting the cassette / channel strip”...
