Snap Connector (5):
Snap connector is used to attach and hold the device on the rectangular pad.
Lead (6):
In order to further improve comfort of PowerDot stimulation experience, two lengths of leads (6) are
provided with each PowerDot (10 cm and 25 cm), which allow you to select the most suitable wire
length based on the targeted muscle group selection and your anatomical parameters.
WARNING! Never unsnap pads from the lead snap connectors during running stimulation session (i.e.
when Stimulation LED on the device is ON).
Electrode Pads (7,8):
PowerDot uses two types of electrode pads – two 4.5 cm (1.8") round pads (9) and 8x4 cm (3.1"x1.6") (8)
rectangular pad. Rectangular pad is also used as a holder for PowerDot unit itself.
PowerDot pads use unique biocompatible hydrogel with superb conductive and adhesiveness qualities.
The lifetime of PowerDot pads depends a lot on your individual skin properties, level of hairlessness and
quality of maintenance. On average, we expect each pad to last for at least 25 stimulation sessions (or
approximately one month worth of training under 'average' 3 times a week/2 muscle groups per session
schedule). After that, adhesiveness and conductive properties of the pads will likely start to deteriorate.
WARNING! Never cut pad or put them into water. Always store your pads attached to the plastic
safety film, in dry environment (either in their original plastic bags or in PowerDot carry case provided).
Always apply your pads to the dry skin only!
