Power/Stimulation LED is ORANGE – your PowerDot is in Stimulation mode.
WARNING! Never de‐attach pads from the body or touch unstuck or partially unstuck pads when
PowerDot is in Stimulation state. Always PAUSE your stimulation session and make sure that
Power/Stimulation LED is either BLUE or completely OFF before touching pads surface.
CHARGING LED is ORANGE ‐ the device is charging its battery. Device can't be charging and stay in
stimulation mode simultaneously, hence, you will never be able to see CHARGING LED on together with
Power/Stimulation LED being ORANGE.
WARNING! NEVER charge PowerDot when it is worn on the body or held in the hand. Always use
an original charging cable provided. Never charge PowerDot from unreliable or problematic power
sources!
Tactile Power Button (2) Modes:
Power Button Action
Hold for ~1 second
Hold for ~0.5 seconds
Short Click
Short Click
Hold for 10 seconds
Micro‐USB connector (3):
PowerDot uses the same high voltage micro‐USB connector (5) for both leads connection and charging.
If device is operating in stimulation mode, it will be stopped immediately once leads are unplugged from
micro‐USB connector.
When device is in charging mode and not completely charged as yet, Charging LED (4) will be ON. See
Re‐Charging PowerDot section of User Manual for more information on PowerDot charging.
Device Initial State
Device is in OFF state (Power LED is
OFF)
Device is in ON state (Power LED is
ON)
Device is in ON state (Power LED is
ON)
Device is in STIMULATION state
(Stimulation LED is ON)
Device is in OFF state (Power LED
blinks 3 times and then turns OFF)
Device Resulting State
Device moves into ON state (Power
LED becomes ON)
User confirmed readiness for the
stimulation session
Device moves into OFF state (Power
LED becomes OFF)
Stimulation is stopped and device
moves into ON state
Activation lock removed, device is OFF
