SERVICE MANUAL
IMPORTANT
• Before using this product, read this manual carefully to understand the
contents herein stated.
• After reading this manual, be sure to keep it near the product or in a
convenient place for easy reference when necessary.
Advertisement
Table of Contents
Related Manuals for Sega LINDBERGH RED
Summary of Contents for Sega LINDBERGH RED
- Page 1 42 0 -7 0 3 2 - 0 1 UK PRINTING SERVICE MANUAL SEGA AMUSEMENTS EUROPE LIMITED IMPORTANT Suite 3a, Oaks House, 12/22 West Street, Epsom, Surrey. KT18 7RG. United Kingdom. • Before using this product, read this manual carefully to understand the Tel: +441372 731820.
- Page 2 TABLE OF CONTENTS BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING: TABLE OF CONTENTS INTRODUCTION ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙1 HANDLING PRECAUTIONS ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙3 LINDBERGH RED SPECIFICATIONS ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙4 2-1 CABINET ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙4 2-2 PARTS DETAILS ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙5 LINDBERGH RED COMPONENTS ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙9 SYSTEM TEST MODE ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙10 ERROR CODES DISPLAY ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙24...
- Page 3 URL: http: //www.fsf.org/licenses/gpl.html URL: http: //www.fsf.org/licenses/lgpl.html Customers using this product who wish to obtain this source code should enter the following password on the website below to download it. URL: http: //amproduct-softlicense.sega.jp/ ID: amsoftwebdl Password: segaamhd1 (2) Lcensed Software Other Than GPL/LGPL At the web site given above, the Company gives notice of information on licensed software other than GPL/LGPL based on stipulations by the copyright holders.
- Page 4 Indicates important information that, if ignored, will result in the mishandling of the product and cause faulty operation and damage to the product. SEGA AMUSEMENTS EUROPE, LTD. Suite 3a, Oaks House 12-22, West Street, Epsom, Surrey, KT18 7RG, United Kingdom...
- Page 5 Definition of 'Site Maintenance Personnel or Other Qualified Individuals' Procedures not described in this manual or marked as 'to be carried out by site maintenance personnel or other qualified professionals' should not be carried out by personnel without the necessary skill or technology. Work carried out by unqualified persons may cause serious accidents, including electrocution.
- Page 6 Ensure the IC Board surfaces are always kept clean. • Keep the IC board well cooled. The LINDBERGH RED board case is provided with ventilating fans. Do not block the air outlets of these fans. Also do not place anything closely to the LINDBERGH RED board case.
- Page 7 Use the LINDBERGH RED board with the SEGA specified cabinet. When using the NAOMI CABINET, NET CITY, NEW NET CITY or BLAST CITY cabinets, you must acquire the correct kits, including the special power supply, and modify the cabinet correctly for LINDBERGH RED use. Cabinet...
- Page 8 2-2 PARTS DETAILS BOARD CASE (1) Shield case (2) Intake vent (Do not block or cover.) (3) Exhaust vent (Do not block or cover.) (4) Board number (5) Board serial number...
- Page 9 CONNECTORS AND SWITCHES Do not connect components to (6) JVS I/O or (8) Serial port 3 that are not designated by SEGA. Connecting unspecified components could cause an accident such as an electric shock or fire. (20) (19) (18) (17)
- Page 10 (1) Power Connector 1 (2) Power Connector 2 Terminal Signal Terminal Signal Terminal Signal Terminal Signal Name Name Name Name +3.3V +3.3V +12V +3.3V +12V PS_ON# +12V +12V PWR_ON +12V +5SB +3.3V 3.3VRS(SENCE) +12V +12V +3.3V (3) DVD DRIVE Power Connector (14) Serial port 2 (RS232C) (15) Serial port 1 (RS232C) Terminal...
- Page 11 No. 7, No. 8: Use differs depending on game software. Set according to the service manual provided with the game software itself. The factory settings when a game board (LINDBERGH RED) is purchased as a stand-alone unit. No. 1 No. 2 No.
- Page 12 LINDBERGH RED COMPONENTS Confirm that the accessories listed in the table below are present when setting up the product. 3 TABLE 01 ACCESSORIES DESCRIPTION SERVICE MANUAL Part No. (Qty) 420-7032-01 (1) Notes This manual Figures Parts not labeled with part numbers are as yet unregistered or cannot be registered.
- Page 13 SYSTEM TEST MENU System Test Mode can be used to check the information or the operation of the LINDBERGH RED board, adjust Monitor color, and perform coin/credit settings.
- Page 14 a. SYSTEM INFORMATION The SYSTEM INFORMATION screen displays system information. SYSTEM INFORMATION MOTHER BOARD SERIAL NO. AAH*-************* KERNEL VERSION *.*.**_***** BOOT VERSION *.**(BUILD ****) REGION MODEL TYPE MEMORY SIZE ******* CPU MODEL *.** STORAGE DEVICE STORAGE SIZE ***** MB BASE BOARD SERIAL NO.
- Page 15 b. STORAGE INFORMATION The STORAGE INFORMATION screen displays information on the game contained within the program installer device. This screen is also used when uninstalling the game contained within the program installer device. Until preparations to launch the game are complete, a “now checking” screen will be displayed and uninstall cannot be performed.
- Page 16 Select NEXT NODE to display information on the next NODE. If no JVS I/O boards are connected, the message “NO JVS NODE” will be displayed JVS TEST INPUT TEST NEXT NODE -> EXIT NODE NAME SEGA ENTERPRISES,LTD. I/O BD JVS 837-13551 Ver1.00 CMD VER JVS VER COM VER SWITCH...
- Page 17 c - 1. JVS INPUT TEST Use the JVS INPUT TEST to test the JVS input. The hexadecimal input information from the JVS I/O board will be displayed in real time. JVS TEST INPUT TEST NODE SYSTEM PLAYER 1 0000 PLAYER 2 0000 COIN 1...
- Page 18 d. MONITOR TEST Use MONITOR TEST to check the output of the monitor. Enter MONITOR TEST and the following color bars will be displayed. M O N I T O R T E S T 1 / 2 P R E S S T E S T N E X T Press the TEST Button and the screen will change to the following cross-hatch screen.
- Page 19 e. SPEAKER TEST Use SPEAKER TEST to check the output of each speaker by having them each emit a test sound. Select each speaker with the cursor and press the TEST Button to turn that speaker ON or OFF. When set to ON a test sound will be emitted from that speaker. It is possible to set multiple speakers to emit the test sound at the same time.
- Page 20 f. COIN ASSIGNMENTS Use COIN ASSIGNMENTS to alter the credit settings. The game will award players the number of credits determined here. Settings will only be saved if they have been changed. COIN ASSIGNMENTS f - 1 COIN CHUTE TYPE COMMON f - 2 SERVICE TYPE...
- Page 21 f - 4. COIN CHUTE #2 COIN TO CREDIT RATE (Coin and credit conversion rate 2) (Can only be set when the COIN CHUTE TYPE is set to COMMON and the COIN setting for the COIN CHUTE #1 COIN TO CREDIT RATE is set to “1”) f - 5.
- Page 22 f - 6. GAME COST SETTING Use the COIN ASSIGNMENTS GAME COST SETTING screen to set the cost (number of required credits) that the game program will use to determine if there are enough credits to play the game. A total of 8 game costs can be defined. The game cost is defined by the BOOT ID, and when the second boot recognizes the game, the game cost defined by the BOOT ID will be displayed.
- Page 23 g. CLOCK SETTING Use CLOCK SETTING to set the date and time. CLOCK SETTING 2007/ 3/ 1(THU) 12:00:00 YEAR MONTH HOUR MINUTE SECOND -> EXIT SELECT WITH SERVICE AND PRESS TEST Use the SERVICE Button to move the cursor to the category that you wish to change and press the TEST Button to increase that value.
- Page 24 h. NETWORK SETTING Use NETWORK SETTING to determine network settings or to test the network. There is no need to alter these settings for a game that does not use a network. NETWORK SETTING h - 1 NETWORK TYPE MAIN h - 2 MAIN NETWORK h - 3...
- Page 25 h-2. MAIN NETWORK Select MAIN NETWORK on the NETWORK SETTING (Setting Menu) and the following screen will be displayed. NETWORK SETTING MAC ADDRESS **:**:**:**:**:** DHCP ******** IP ADDRESS ***.***.***.*** SUBNET MASK ***.***.***.*** GATEWAY ***.***.***.*** PRIMARY DNS ***.***.***.*** SECONDARY DNS ***.***.***.*** ->...
- Page 26 h-3. NETWORK TEST Check the network connection. The test will begin as soon as this screen is displayed. If the test ends successfully “GOOD” will be displayed. If the test is unsuccessful “BAD” will be displayed. If connection is not permitted “N/A” will be displayed. The results of the test may not be correct immediately after changing the network settings.
- Page 27 LINDBERGH RED board in for repairs. The LINDBERGH RED board is equipped to display various errors on-screen to help solve any problems. If an error is displayed the game cannot be used. Use the following table of causes and resolutions to solve the problem.
- Page 28 RED board’s graphics card cannot be found. Verify that the game disk is compatible with the LINDBERGH RED. If it is, COUNTERMEASURES send the LINDBERGH RED board in for repair with the key chip still in place. Error 9 DISPLAY System Memory Not Enough.
- Page 29 DISPLAY Storage Device Not Found. CAUSE The program installer device cannot be found. COUNTERMEASURES Send the LINDBERGH RED board in for repair with the key chip still in place. Error 27 DISPLAY Storage Device is Not Acceptable. CAUSE The program installer device does not have enough space.
- Page 30 Storage Device May be Broken. CAUSE The program installer device is broken. COUNTERMEASURES Send the LINDBERGH RED board in for repair with the key chip still in place. Error 37 DISPLAY Verifying Game Program Failed. The program image is unverified due to the program image not existing on the CAUSE game disk or server.
- Page 31 The button batteries that require replacement can be found on the main board and on the base board, inside the LINDBERGH RED board case. Remove the unit on which the LINDBERGH RED board is placed from the game cabinet. The LINDBERGH RED board must be removed still attached to the base (wooden shelf, etc.).
- Page 32 Press on the front and back of the lid from above and slide toward the side with the fan, releasing the catches on the left and right sides. Remove the lid. The main board is the board on the bottom of the LINDBERGH RED board case. The button battery is location close to the fan.
