OP940-SW
Overview
The OP940 is a compact, stand-alone insertion loss and return loss test meter. Using
a pulse-based system for return loss measurements the user is not required to perform
mandrel wraps or use matching gel on the DUT to get quick and accurate insertion loss
and return loss measurements.
The OP940 allows the user to view the IL and RL for up to two wavelengths simultaneously.
The color display coupled with user configurable pass/fail (green/red) settings make it
extremely easy to qualify fiber optic patchcords for telecom standards.
Additionally, the unit features an Optical Reflectance Scan Mode, On Screen Context
Help, and the ability to measure return loss on both ends of a DUT through the front
panel.
The OP940 uses the USB interface to communicate and be driven by OptoTest software
which further integrates the unit into a highly efficient production line.
