Rapid assembly/removal of wing doors.
To remove the door, remove the cover cap from
the hinge.
To assemble the door, bring the points marked
with an arrow together.
12
The ASSMANN principle. Good Work.
Assembly instructions
The hinge arm is released by pressing at the
marked points.
Perform a slight rotation and then ...
Intavis
... allow the hinge arm to engage with a little
pressure.
www.assmann.de
