Side adjustment of wing doors (3-D boss hinges with opening angle of 110°).
The front adjusting screw allows the door to be adjusted at the side. The adjusting screw changes the side lift of the hinge arm and therefore changes the
position of the door.
Side adjustment is possible within the range of
–1.5 mm to +4.5 mm.
09
The ASSMANN principle. Good Work.
Assembly instructions
Continue on pages 10/11 or fit 3.5 x 20 retaining
screw.
Intavis
Then clip on the cover cap.
