3.2 Controls

Low Level

Sets the low level compression threshold. Compression is applied to signals below this
threshold. (From bottom up)
Range: 0 to +48 dBFS

High Level

Sets the high level compression threshold. Compression is applied to signals above this
threshold. (Top down)
Range: 0 to -48 dBFS

Ouput Gain

Range: 0 to -48 dBFS

Output Meters

Range: 0 to -60 dBFS

Cut / Boost Meters

Display the amount of gain cut and/or boost.
Attenuation is displayed from the top down.
Boost is displayed from the bottom up.
Numeric indicators which display the maximum cut and boost are displayed below the
meters.
Reset these values by clicking anywhere on the meter.
The meters display up to -48 dB of attenuation and +48 dB of gain boost.
