- Page 1 Installation Manual SmartRow™...
- Page 2 GPS satellites, the OmniSTAR correction service or the WAAS correction service. Raven Industries accepts no responsibility for the use of the signal for other than the stated purpose. Raven Industries shall not be responsible or liable for incidental or consequential damages or a loss of anticipated benefits or profits, work stoppage or loss or impairment of data arising out of the use, or inability to use, the SmarTrax or any of its components.
-
Page 3: Table Of Contents
CHAPTER 2 Introduction ..............3 Installation ........................3 Updates ......................... 4 Overview of the SmartRow Installation Process ............4 Recommendations ......................4 Reviewing SmartRow Kit Contents ................5 Electric Clutch Systems ..................5 CHAPTER 3 Electric Clutch Systems Installation ......7 Process Overview ...................... - Page 4 Table of Contents SmartRow Installation Manual...
-
Page 5: Chapter 1 Important Safety Information
Raven dealer for support. • Follow all safety labels affixed to the SmartRow system components. Be sure to keep safety labels in good condition and replace any missing or damaged labels. To obtain replacements for missing or damaged safety labels, contact your local Raven dealer. -
Page 6: Electrical Safety
Do not reverse power leads. Doing so could cause severe damage to the equipment. Always make sure that the power leads are connected to the correct polarity as marked. Ensure that the power cable is the last cable to be connected. SmartRow Installation Manual... -
Page 7: Chapter 2 Introduction
The following instructions are designed to assist you in the proper installation of the SmartRow system. See the Operation Manual of your SmartRow console for instructions on setting up the software and using the SmartRow system. -
Page 8: Updates
Updates for Raven manuals as well as software updates for Raven consoles are available at the Applied Technology Division web site: http://www.ravenprecision.com/Support/index2.jsp Sign up for e-mail alerts and we will notify you when updates for your Raven products are available on the Raven web site. http://www.ravenprecision.com... -
Page 9: Reviewing Smartrow Kit Contents
This section contains a list of the kit contents that you should have received in these SmartRow kits. Before you begin assembling the kit, compare the items in your SmartRow kit with this list. If you have questions about your kit, contact your Raven dealer. - Page 10 Chapter 2 SmartRow 3 Clutch Kit (P/N 117-3001-009) Component Part Number Quantity SmartRow Clutch Cable for 3 Clutch System 115-3001-023 6’ GPS Cable 115-0171-119 12’ Receiver Cable 115-0171-460 SmartRow Console 063-0172-828 SmartRow 4 Clutch Kit (P/N 117-3001-010) Component Part Number...
-
Page 11: Chapter 3 Electric Clutch Systems Installation
E lectric Clutch CHAPTER C H A P T E R 3 Systems Installation Process Overview To install the SmartRow Electric Clutch, you must complete the following steps: Install the Power Harness. Install the Planter Harness. Install the Remote Switch. Recommendations Observe the following recommendations while installing the AutoBoom system: •... -
Page 12: Installing The Power Harness And Planter Harness
Locate the 20 pin connector on the SmartRow power harness (P/N 115-3001-020) and connect to the Control receptacle on the rear of the SmartRow console. Locate the 4 pin connector on the SmartRow power harness (P/N 115-3001-020) and connect to the Power receptacle on the rear of the SmartRow console. -
Page 13: To Install The Planter Harness
Electric Clutch Systems Installation To Install the Planter Harness Route the 14 pin connector to the planter hitch and secure with the supplied straps. Locate the existing electric clutches on the planter and route the section leads to their respective clutch. - Page 14 Locate positive (+) stud or terminal on clutch and attach the section lead. John Deere 7200 Clutch FIGURE 1. White 8500 Clutch FIGURE 2. SmartRow Installation Manual...
-
Page 15: Installing The Remote Switch
Refer to the Remote Switch Assembly kit instructions. Note: SmartRow will control clutches and generate coverage map on a console, only when the switch is activated. Be sure to mount the switch to accommodate varying field conditions and planting depths to ensure the switch will always be activated during seeding. -
Page 16: Installation Complete
A row unit linkage. Kinze Row Unit Linkage FIGURE 4. Route the remote switch harness lead to the remote switch and connect. Installation Complete Refer to the “SmartBoom/SmartRow Installation and Operation Manual” for instructions on mounting the SmartRow console. SmartRow Installation Manual... -
Page 17: System Cable Drawing
Electric Clutch Systems Installation System Cable Drawing Manual No. 016-3001-002... - Page 18 Chapter 3 SmartRow Installation Manual...
-
Page 19: Chapter 4 Air Clutch Systems Installation
A ir Clutch Systems CHAPTER C H A P T E R 4 Installation Process Overview To install the SmartRow Electric Clutch, you must complete the following steps: Install the Power Harness. Install the Planter Harness. Install the Remote Switch. Recommendations Observe the following recommendations while installing the AutoBoom system: •... -
Page 20: Installing The Power Harness And Planter Harness
Locate the 20 pin connector on the SmartRow power harness (P/N 115-3001-020) and connect to the Control receptacle on the rear of the SmartRow console. Locate the 4 pin connector on the SmartRow power harness (P/N 115-3001-020) and connect to the Power receptacle on the rear of the SmartRow console. -
Page 21: To Install The Planter Harness
Air Clutch Systems Installation To Install the Planter Harness Route the 14 pin connector to the planter hitch and secure with the supplied straps. Locate the 6 pin packard connectors from the air valve box extension harness. 4- Section System: •... -
Page 22: Installing The Remote Switch
Refer to the Remote Switch Assembly kit instructions. Note: SmartRow will control clutches and generate coverage map on a console, only when the switch is activated. Be sure to mount the switch to accommodate varying field conditions and planting depths to ensure the switch will always be activated during seeding. -
Page 23: Installation Complete
A row unit linkage. Kinze Row Unit Linkage FIGURE 2. Route the remote switch harness lead to the remote switch and connect. Installation Complete Refer to the “SmartBoom/SmartRow Installation and Operation Manual” for instructions on mounting the SmartRow console. Manual No. 016-3001-002... -
Page 24: System Cable Drawing
Chapter 4 System Cable Drawing SmartRow Installation Manual... - Page 25 How Can I Get Service? Bring the defective part and proof of purchase to your Raven Dealer. If your Dealer agrees with the warranty claim, the Dealer will send the part and proof of purchase to their distributor or to Raven Industries for final approval.
- Page 26 P.O. Box 5107 Fax: 605-331-0426 Sioux Falls, SD 57117-5107 www.ravenprecision.com atdinfo@ravenind.com Notice: This document and the information provided are the property of Raven Industries, Inc. and may only be used as authorized by Raven Industries, Inc. All rights reserved under copyright laws.
