OPERATING INSTRUCTIONS AND TROUBLESHOOTING FOR A97
CPN108172
ISSUE DATE: 16071 – 7/03
MODEL
A97
SERIES
Switchmode Utility
Rectifier/Battery Charger
ECN/DATE
106 BRADROCK DRIVE
DES PLAINES, IL. 60018-1967
(847) 299-1188
FAX: (847)299-3061
Page 1 of 7
INSTRUCTION DRAWING NUMBER:
P25-
20800-1-4/15
LA97-1
Advertisement
Table of Contents
Related Manuals for Lamarche A97 Series
Summary of Contents for Lamarche A97 Series
- Page 1 OPERATING INSTRUCTIONS AND TROUBLESHOOTING FOR A97 MODEL SERIES Switchmode Utility Rectifier/Battery Charger ECN/DATE CPN108172 20800-1-4/15 106 BRADROCK DRIVE DES PLAINES, IL. 60018-1967 (847) 299-1188 FAX: (847)299-3061 ISSUE DATE: 16071 – 7/03 INSTRUCTION DRAWING NUMBER: LA97-1 P25- Page 1 of 7...
- Page 2 OPERATING INSTRUCTIONS AND TROUBLESHOOTING FOR A97 IMPORTANT SAFETY INSTRUCTIONS FOR THE LA MARCHE POWER CONVERSION EQUIPMENT SAVE THESE INSTRUCTIONS This manual contains important safety and operating instructions for the La Marche Power Conversion Equipment. Before using this equipment, read all instructions and cautionary markings on (1) unit, (2) battery, and (3) product using the battery.
- Page 3 OPERATING INSTRUCTIONS AND TROUBLESHOOTING FOR A97 PREPARING TO CHARGE 1. If it is necessary to remove the battery connections, always remove grounded the terminal from the battery first. Make sure all loads are disconnected and unit is off, so as not to cause an arc. 2.
- Page 4 OPERATING INSTRUCTIONS AND TROUBLESHOOTING FOR A97 RECEIVING INSTRUCTIONS GENERAL EQUIPMENT INFORMATION CAUTION: To ensure safe installation and operation, the information given in the instruction manual should be read and understood before installing or using the equipment. RECEIVING INSTRUCTIONS Unpacking and Inspection: Examine the shipping crate upon arrival. If there is obvious damage, describe on the receiving documents.
- Page 5 OPERATING INSTRUCTIONS AND TROUBLESHOOTING FOR A97 GENERAL The A97 Series is available in two mounting types. A97W (Wall/Shelf Mount) and A97R (Rack Mount). See data sheet for details. This rectifier is designed to operate on a specific number of cells.
- Page 6 OPERATING INSTRUCTIONS AND TROUBLESHOOTING FOR A97 INSTALLATIONS INSTRUCTIONS To operate the rectifier, connect the a.c. power to the a.c. input circuit breaker. Connect the battery or loads to the d.c. output circuit breaker. ******OBSERVE PROPER POLARITY****** Be sure that the battery type, number of cells, and the a.c. input agree with the nameplate data.
- Page 7 La Marche Sales Representative should be contacted to provide this service. All sales are final. Only standard LaMarche units will be considered for return. A 25% restocking fee is charged when return is factory authorized. Special units are not returnable.
