106 Bradrock Dr. Des Plaines 60018-1967
Tel: 847 299 1188
Fax: 847 299 3061
La Marche Manufacturing Company
www.lamarchemfg.com
ESCR125
Industrial Battery Charger
Installation and Operation Manual
CPN 137791
Instruction Drawing Number: P25-LESCR125-1
Revision A00
Rev. Date: 12/17
ECN: 21664

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESCR125 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lamarche ESCR125

  • Page 1 La Marche Manufacturing Company www.lamarchemfg.com ESCR125 Industrial Battery Charger Installation and Operation Manual 106 Bradrock Dr. Des Plaines 60018-1967 CPN 137791 Instruction Drawing Number: P25-LESCR125-1 Tel: 847 299 1188 Fax: 847 299 3061 Revision A00 Rev. Date: 12/17 ECN: 21664...
  • Page 2: Electrical Safety

    Important Safety Instructions Before using this equipment read all manuals and other documents related to this charger and other equipment connected to this charger. Always have a copy of a charger’s manual on file nearby, in a safe place; if a replacement copy of a manual is needed, it can be found at www.lamarchemfg.com.
  • Page 3: Charger Location

    Charger Location  Allow at least 3 inches of free air on all vented surfaces (and external heatsinks) for proper cooling.  Allow sufficient clearance to open the front panel for servicing.  Do not operate this charger in a closed-in area or restrict ventilation in any way. ...
  • Page 4: Table Of Contents

    Start-Up Sequence ........................8 Front Panel Display ........................9 2.2.1 Controls ..........................9 2.2.2 LED Indicators/Alarms......................10 Configuration Mode ........................11 ESCR125 Customer Configuration Menu Structure ................ 11 Service ............................. 14 Performing Routine Maintenance ....................14 Troubleshooting Procedure ......................15...
  • Page 5: Table Of Figures

    Troubleshooting Chart ....................... 16 Appendix A: ESCR125 Specifications ......................17 Appendix B: Manufacturer’s Warranty ......................18 Appendix C: Document Control and Revision History ................... 18 Table of Figures Figure 1 - 3 Enclosure Wall Mounting Dimensions ........... Error! Bookmark not defined.
  • Page 6: Model Scope/General Description

    Understanding the Model Number The ESCR125 model number is coded to describe the features that are included. Find the model number on the nomenclature nameplate of the charger. Follow the chart below to determine the configuration of the battery charger.
  • Page 7: Installation

    Installation Mounting the ESCR125 For user convenience, the ESCR125 can be wall or floor mounted. The 4 enclosure can also be rack mounted. Be sure that the Wall or Floor planned for installation can support the weight of the ESCR125.
  • Page 8: Floor Mounting

    1.1.3 Rack Mounting (4 Enclosure Only) The ESCR125 can be installed in most relay racks with standard EIA hole spacing. If a relay rack is needed, they are available for purchase from La Marche. The 4 enclosures are shipped from the factory with the necessary brackets installed for rear mounting on a 19”...
  • Page 9: Electrical Connections

    1.2.1 Changing Transformer Taps The ESCR125 accepts standard input voltages of 120, 208, or 240 VAC by changing the connections to the input terminals. Before changing the AC input taps, assure that AC supply and DC loads to the ESCR125 are turned off and locked out.
  • Page 10: Ac Input Connections

    1.2.2 AC Input Connections Before beginning any work inside the charger, ensure that all incoming AC supply is de-energized. Verify that no voltage is present inside the case by using a voltmeter at all input and output terminals. Check that the source voltage and frequency match the charger front nameplate specifications.
  • Page 11 Power Cabling Guide Use the following formulas and table to determine proper wire size for minimal voltage drop. At distances exceeding 10 feet, the DC wire size should be chosen to keep the voltage difference between the charger’s DC output terminals and the battery at less than 1/2 volt when the charger is fully loaded. Table of Conventions: Size Area...
  • Page 12: Standard Alarms

    1.2.4 Standard Alarms Four alarms are included as a standard feature of the ESCR125. The included alarms are High DC Voltage, Low DC Voltage, Charger Failure, and AC Failure. Each alarm includes a form “C” contact, enabling the user to connect remote annunciators.
  • Page 13: External Temperature Compensation (Option 11W/11Y)

    Alarm Connections Before making any connections to the ESCR125, ensure that the AC Power is off at the main breaker box and that both of the charger’s breakers are off. Verify that no voltage is present by using a voltmeter at all input and output terminals.
  • Page 14: Operation

    2.1.3 Start-Up Sequence Upon powering up the ESCR125, the LCD will display “La Marche ESCR”. During the start up sequence, the Low DC Voltage alarm will be temporarily activated. The display will show “Float Mode” and the output Voltage and Current of the Charger will slowly ramp up.
  • Page 15: Front Panel Display

    Front Panel Display After the ESCR125 has completed start up, the “AC ON” indicator on the front panel and either the “Float” or “Equalize” indicator on the front panel will be lit. The LCD will display the system DC output voltage and DC output current on line one.
  • Page 16: Led Indicators/Alarms

    LCD Display – The LCD Display shows the output DC voltage and output DC amperage of the ESCR125 at all times. The second line of the display shows the mode of the charger, as well as displaying the different alarm conditions, should they occur.
  • Page 17: Configuration Mode

    Equalize cycle starts automatically if battery voltage falls below the Low Voltage Alarm set point In any Equalize Mode, the ESCR125 will return to Float Mode at the end of the Equalize cycle. Current Limit – Allows adjustment of the current limit from 50% to 110% of rated output.
  • Page 18: Figure 10 - Internal Temperature Compensation Setup

    – Allows the user to reset all settings to how they were programmed from the factory. To reset the ESCR125 settings to the original default settings, scroll to DEFAULT SETTING in the configuration menu. Select DEFAULT SETTING. Press the Configure/OK button to confirm.
  • Page 19 ESCR125 Customer Configuration Menu Structure...
  • Page 20: Service

    Service All work inside the ESCR125 should be performed by a qualified electrician. La Marche is not responsible for any damages caused by an unqualified technician. Before working inside the ESCR125, ensure that the AC Power is off at the main breaker box and that both of the charger’s breakers are off.
  • Page 21: Troubleshooting Procedure

    Troubleshooting Procedure Troubleshooting should be performed only by trained service personnel or experienced electricians. Before setting up any complicated testing or making conclusions, inspect the charger using the guide below. Check the following: 1. Check DC output cables, connections, battery type, and number of cells against the charger’s rating. 2.
  • Page 22: Troubleshooting Chart

    Troubleshooting Chart Isolate from all power sources prior to performing any interior verifications or part replacements. Symptom Possible Cause Wrong AC Input Voltage Frequency out of Range AC Breaker Trips (High Input Current) Internal Wiring Failure Defective Component on Heatsink Assembly No AC Power Connected AC MAINS Fail Alarm Incorrect Input AC Voltage Tap Setting...
  • Page 23: Appendix A: Escr125 Specifications

    Appendix A: ESCR125 Specifications ELECTRICAL Voltage Range ± 10% AC Input Frequency Range 50/60Hz DC Output 16 or 25 ADC @ 125 VDC Output Filtering Less than 500mV RMS, with connected battery ± 0.5% from no load to full load over the specified input Regulation voltage, frequency and ambient temperature range.
  • Page 24: Appendix B: Manufacturer's Warranty

    Appendix B: Manufacturer’s Warranty All La Marche Manufacturing Co. equipment has been thoroughly tested and found to be in proper operating condition upon shipment from the factory and is warranted to be free from any defect in workmanship and material that may develop within two (2) years from date of purchase. Any part or parts of the equipment (except fuses, DC connectors and other wear-related items) that prove defective within a two (2) year period shall be replaced without charge providing such defect, in our opinion, is due to faulty material or workmanship and not caused by tampering, abuse, misapplication or improper...
  • Page 25: Appendix C: Document Control And Revision History

    Appendix C: Document Control and Revision History Part Number: 137791 Instruction Number: P25-LESCR125-1 Issue ECN: 21664 21664 – 12/17...
