A39 UNIVERSAL SCR CHARGER INSTRUCTION MANUAL
A39
UNIVERSAL SCR CHARGER
ECN/DATE
CPN35971
15349-03 – 05/02
14268 – 10/00
16816 - 6/05
14575 – 02/01
10400 – 9/96
106 BRADROCK DRIVE
DES PLAINES, IL. 60018-1967
(847) 299-1188
FAX: (847) 299-3061
ISSUE DATE: 6/90
INSTRUCTION DRAWING NUMBER:
LA39-1
P25-
Page 1 of 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A39 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lamarche A39

Summary of Contents for Lamarche A39

  • Page 1 A39 UNIVERSAL SCR CHARGER INSTRUCTION MANUAL UNIVERSAL SCR CHARGER ECN/DATE CPN35971 15349-03 – 05/02 14268 – 10/00 16816 - 6/05 14575 – 02/01 10400 – 9/96 106 BRADROCK DRIVE DES PLAINES, IL. 60018-1967 (847) 299-1188 FAX: (847) 299-3061 ISSUE DATE: 6/90...

  • Page 2: Important Safety Instructions

    A39 UNIVERSAL SCR CHARGER INSTRUCTION MANUAL IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS. This manual contains important safety and operating instructions. Before using this equipment, read all instructions and cautionary markings on (1) unit, (2) battery, and (3) product using the battery.
  • Page 3 A39 UNIVERSAL SCR CHARGER INSTRUCTION MANUAL RECEIVING INSTRUCTIONS GENERAL EQUIPMENT INFORMATION CAUTION: To ensure safe installation and operation, the information given in the instruction manual should be read and understood before installing or using the equipment. RECEIVING INSTRUCTIONS Unpacking and Inspection: Examine the shipping crate upon arrival. If there is obvious damage, describe on the receiving documents.

  • Page 4: Standard Features

    100% of rated output current, and the charge timer range adjusts between 30 minutes to 99 hours in 30 minute increments. The A39 may be used as a constant current charger where the open circuit voltage can be adjusted, or as a constant voltage charger with a current limit mode. The voltage characteristics in the constant voltage mode are programmable by "dip”...

  • Page 5: Operation And Adjustments

    6. The A39 will stay in current limit until the set voltage is reached. Once the set voltage is reached the current will start to taper. The A39 will run for the specified amount of time and then go to a "Complete"...

  • Page 6: Troubleshooting

    A39 UNIVERSAL SCR CHARGER INSTRUCTION MANUAL TROUBLESHOOTING UNITS AC BREAKER TRIPS: A) Check AC input voltage. B) Check transformer tap setting. DIGITAL DISPLAY FLASHING "0000" A) The A39 not sensing battery WITH THE VOLTS LIGHT FLASHING AT A ONE (1) SECOND INTERNAL:...

  • Page 7: General Maintenance Procedure

    A39 UNIVERSAL SCR CHARGER INSTRUCTION MANUAL General Maintenance Procedure Yearly 1. Blow out rectifier/inverter with a low-pressure air hose. 2. Make sure all connections are tight. 3. Perform a visual check on all internal components. 4. Check front panel meters and alarms for accuracy.

  • Page 8: Manufacturer's Warranty

    Should minor adjustments be required, the local La Marche sales representative should be contacted to provide this service only. All sales are final. Only standard LaMarche units will be considered for return. A 25% restocking fee is charged when return is factory authorized. Special units are not returnable.
