t110W/t130W
Installation and Operation Manual
Marine Satellite Television Antenna System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T110W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intellian T110W

Summary of Contents for Intellian T110W

  • Page 1 Installation and Operation Manual Marine Satellite Television Antenna System...
  • Page 3 © 2013 Intellian Technologies Inc. All rights reserved. Intellian and the Intellian logo are trademarks of Intellian Technologies, Inc., registered in the U.S. and other countries. t110W, t130W and w-Series are trademarks of Intellian Technologies, Inc. Intellian may have patents, patent applications, trademarks, copyrights, or other intellectual property rights covering subject matter in this document.
  • Page 4 INDEX...
  • Page 5 OPERATING THE ACU Introduction Normal Mode Setup Mode Intallation Settings Antenna Settings Satellite Settings System Settings PC CONTROLLER SOFTWARE Introduction Program Initialing and Serial Port Setup Main Menu Controller Menu s WARRANTY Appendix : t110W Technical Specification Appendix : t130W Technical Specification...
  • Page 6 – Marine Satellite Television System INTRODUCTION Introduction to Intellian t110W/t130W Features of Intellian t110W/t130W Basic System Configuration...
  • Page 7 INTRODUCTION Introduction to Intellian t110W/t130W The Intellian t110W/t130W is the world’s first and only marine satellite TV antenna capable of operating in all global markets without the need of changing the LNB unit inside of the antenna's dome each time the vessel crosses into a different satellite service region.
  • Page 8 Features of Intellian t110W/t130W Global Satellite Services Comptibility Intellian t110W/t130W provides the ultimate convenience to connect you up to thousands of Free TV, pay TV, Standard Definition, and high Definition programming all over the world with one LNB module which incorporates multi (8) LO frequencies.

  • Page 9: Basic System Configuration

    INTRODUCTION Basic System Configuration For your satellite TV system to work properly, the system will have to be connected with all of the provided components properly, as shown in the figure below (see the “Installation” section of this manual). Separate purchase of a satellite receiver and a TV is required.

  • Page 10: Installing The Antenna

    – Marine Satellite Television System INSTALLING THE ANTENNA System Package Antenna Unit ACU (Antenna Control Unit) Installation Kit Planning the Installation Selection of Antenna Installation Site System Cables Power Requirement Tools Required for Installation Antenna Installation Unpacking the Wooden Crate...
  • Page 11 INTRODUCTION System Package The Intellian t110W/t130W consists of two major units, an antenna assembly unit and an antenna control unit. Antenna Unit The antenna unit includes an antenna pedestal inside a radome assem- bly unit. The pedestal consists of the satellite antenna main dish and...
  • Page 12 – Marine Satellite Television System Figure 3. World View LNB Module Antenna Control Unit (ACU) The Antenna Control Unit (ACU) provides power to the antenna and controls various settings of the antenna. Additionally, VFD (Vacuum Fluorescent Display) allows for you to operate the ACU in the dark.
  • Page 13 INSTALLING THE ANTENNA The functions of the ACU are as follows : • System startup • Change of target satellite • Monitoring current status • Setting antenna manual search • Setting antenna set skew • Setting antenna go position • Setting antenna search parameter •...

  • Page 14: Installation Kit

    – Marine Satellite Television System Installation Kit Contains the items required for securing the antenna unit and ACU to your vessel. Q’ty Description Size Remark Self-Tapping Table Mount 4 x 16 Screw Bracket Rack Mount Flat Head Screw M3 x 8L...
  • Page 15 INSTALLING THE ANTENNA Item Image Q’ty Description Size Remark USB Cable 1.8m ACU to PC (A-A / M-M) Synchro AK950-5 ACU Connector Step by Step AK950-4 ACU Connector NMEA Out AK950-3 ACU Connector Gyro NMEA /GPS NMEA IN AK950-2 ACU Connector Rubber Gland Antenna Cables...

  • Page 16: Planning The Installation

    – Marine Satellite Television System Planning the Installation Selection of Antenna Installation Site Install the antenna in accordance with the following procedures to ensure maximum performance of the antenna. The ideal antenna site should have a clear view of the horizon or satellite all around it.
  • Page 17 RF Cables (Customer Supplied) Due to voltage losses across the length of the RF coax on L-Band, Intellian recommends the following 75 ohm coax cable types for standard system installations. For cables that run longer than 100 meters, please consult Intellian Technologies.
  • Page 18 – Marine Satellite Television System Tools Required for Installation 11 mm Spanner Power Drill 13 mm Spanner Cross Head Screwdriver 19 mm Spanner Flat Head Screwdriver 13 mm Drill Bit 5 mm Allen/Hex key Figure 10. Tool Sets for Installation...

  • Page 19: Antenna Installation

    INSTALLING THE ANTENNA Antenna Installation Unpacking the Wooden Crate of t110W/t130W The antenna pedestal is shipped completely assembled in its radome. Remove the four shipping bolts which mount the antenna to the pallet. The pallet should be lifted by means of a suitable sized lifting equipment.
  • Page 20 Intellian strongly recommends to restrain the antenna pedestal properly while underway when power is removed from the antenna. The normal operating condition for the t110W/t130W is to remain powered up at all times.

  • Page 21: Antenna Dimensions

    ø133 cm (52.4”) ø165.2 cm (65”) Figure 14. Radome Dimension of t110W Figure 15. Radome Dimension of t130W Antenna Mounting Templates The mounting holes must be in the exact same place as shown in the diagram below.
  • Page 22 – Marine Satellite Television System Preparing Antenna Supporting Pole Mounting Plate Min. 1 cm (0.4”) Max. 3 cm (15”) Support Pedestal Appr. Ø25.4 cm (10”) Figure 18. Recommended Dimension of Mounting Pole (Unit: cm/inch) WARNING: Ensure that cables have been run through watertight fittings to prevent...
  • Page 23 INSTALLING THE ANTENNA Mounting the Radome Bolt the radome base directly to the support pedestal. Makesure to use the Intel- lian supplied bolts from the accessory box when you mount the radome. Figure 19. Mounting Components Diagram...

  • Page 24: Installing The System Cables

    – Marine Satellite Television System Installing the System Cables The coax cables must be inserted through the cable strain relief(s) at the base of the radome. The cables must be routed from the antenna through the deck and through various ship spaces to the antenna control unit. When pulling the cables in place, avoid sharp bends, kinking, and the use of excessive force.
  • Page 25 When all the hardware and cables have been installed, turn on the power switch. Use an RG11 rubber gland if you’re using an RF11 cable instead of an RG6 cable supplied by Intellian. Figure 22. Cable Connection on Power Switch Box...

  • Page 26: Installing The Acu

    INSTALLING THE ACU Mounting the ACU 19” Rack Mount Type Table Mount Type ACU Dimensions Selection of ACU Installation Site Connecting the System's Cables Up to 4 Receivers Connection Multi-Switch Connection Ship Gyro Connection...
  • Page 27 INSTALLING THE ACU Mounting the ACU Intellian supplies two types of mounting methods (a)19” Rack Mount Type and (b) Table Mount Type to mount your ACU. 19” Rack Mount Type The ACU should be installed using the two supplied Rack Mounting Brackets •...

  • Page 28: Acu Dimensions

    – Marine Satellite Television System ACU Dimensions 47.32 cm (18.6”) 45.32 cm (17.8”) 43 cm (16.9”) 4.4 cm (1.7”) 48.43 cm (19”) 46.5 cm (18.3”) 3.18 cm (1.3”) Figure 25. Dimension of ACU Selection of ACU Installation Site •...
  • Page 29 INSTALLING THE ACU Connecting the System's Cables Up to 4 Receivers Connection In Universal LNB mode, RF1, RF2, RF3 and RF4 can be connected, however, when you switch and use the system from universal LNB mode (ex. Europe) to single LNB mode (ex. US), RF3 and RF4 will not work and only RF1 and RF2 will transfer the satellite's signal.
  • Page 30 – Marine Satellite Television System Multi-Switch Connection When you use the multi-switch in single LNB mode, you need to connect RF1 and RF2 to the low-band (Horizontal Low and Vertical Low) outputs of the 4x8 multi- switch and disable DisEqC function while connecting to a receiver other than a European receiver.
  • Page 31 INSTALLING THE ACU Ship Gyro Connection For satellite tracking, you must connect a ship’s Gyro to the antenna system through the gyro interface on the rear of the ACU. If the ship’s gyrocompass output is other than NMEA 0183 and Synchro, a separate purchase of a gyro converter is required.

  • Page 32: Operating The Acu

    – Marine Satellite Television System OPERATING THE ACU OPERATING THE ACU Introduction Normal Mode System Startup Change of Target Satellite Monitoring Antenna Current Status Setup Mode Installation Settings Antenna Settings Setting Antenna Manual Search Setup Antenna LNB Skew Angle...
  • Page 33 OPERATING THE ACU Introduction This section of the handbook describes how to set up your Satellite TV System after Installing the ACU or GUI PC controller program and includes the following functions: Normal Mode • System startup • Change of target satellite •...
  • Page 34 – Marine Satellite Television System Mode Arrow Keys ACU Soft Keys PC Cable (USB) Status LED Return Function Number Keys Power Soft Key Functions Soft key Function MODE Enter SETUP mode In SETUP mode: return to the previous menu / option or save the adjusted settings.

  • Page 35: Normal Mode

    OPERATING THE ACU Normal Mode Startup With the system installed and power applied, the ACU screen will show the following sequence. I N T E L L I A N T E C H N O L O G I E S I N C . I N T E L L I A N t 1 1 0 W 1.
  • Page 36 – Marine Satellite Television System Change of Target Satellite Your antenna is programmed with three candidates of target satellites as default. To change the target satellite, press the LEFT soft key. The target satellite is changed and is automatically tracked by the antenna.
  • Page 37 OPERATING THE ACU Monitoring Current Status While POWER ON the Intellian t110W/t130W ACU displays the status of the antenna. Various ACU displays may be shown according to the current status of the antenna. [ 4 ] A S T R A _ 1...
  • Page 38 – Marine Satellite Television System T R A C K I N G [ 4 ] A S T R A _ 1 [ 2 ] H O T _ S P O T [ 3 ] A S T R A _ 3 6.
  • Page 39 OPERATING THE ACU [ P W R ] A N T : 2 3 . 9 V L N B : 1 3 V + 0 K H z A C U : 2 7 . 0 V I R D : 1 3 V + 0 K H z 9.

  • Page 40: Setup Mode

    – Marine Satellite Television System Setup Mode To enter Set-up Mode simply follow the instructions below: T R A C K I N G [ 4 ] A S T R A _ 1 [ 2 ] H O T _ S P O T [ 3 ] A S T R A _ 3 1.

  • Page 41: Installation Settings

    OPERATING THE ACU Installation Settings Installation S E T U P M O D E ? 4 Y E S 1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter setup mode. + A N T E N N A + S A T E L L I T E 4 + I N S T A L L A T I O N...
  • Page 42 – Marine Satellite Television System L A T I T U D E L O N G T I T U D E H E A D I N G 4 1 . 5 0 N 0 8 7 . 3 7 W 0 0 0 .
  • Page 43 OPERATING THE ACU L N B T Y P E L O C A L F R E Q . U N I V E R S A L 1 1 2 5 0 M H z 10. Press the UP and DOWN arrow keys to select LNB TYPE* and press the OK key to set the LNB TYPE.
  • Page 44 – Marine Satellite Television System [ 4 ] T H O R _ 1 S E A R C H [ 2 ] S I R I U S _ 1 15. Region information has been updated. LNB TYPE*...

  • Page 45: Antenna Settings

    OPERATING THE ACU Antenna Settings Setting Antenna Manual Search S E T U P M O D E ? 4 Y E S 1. Press the LEFT key to move cursor to YES and press the OK key to enter setup mode.
  • Page 46 – Marine Satellite Television System Antenna LNB Skew Angle S E T U P M O D E ? 4 Y E S 1. Press the LEFT key to move cursor to YES and press the OK key to enter setup mode.
  • Page 47 OPERATING THE ACU Setting Antenna Angle Position The antenna can be controlled manually by using the ACU. S E T U P M O D E ? 4 Y E S 1. Press the LEFT key to move cursor to YES and press the OK key to enter setup mode.
  • Page 48 – Marine Satellite Television System A Z I M U T H E L E V A T I O N A Z : 2 8 8 . 7 + 2 8 8 . 7 + 4 1 . 0 E L : 4 0 .
  • Page 49 OPERATING THE ACU Setting Antenna Search Parameter It is not recommended for a novice satellite service user to use this mode. S E T U P M O D E ? 4 Y E S 1. Press the LEFT key to move cursor to YES and press the OK key to enter setup mode.
  • Page 50 – Marine Satellite Television System S E A R C H W A I T T I M E I N C R E M E N T S T E P 0 2 0 1 . 0 6. Set the INCREMENT STEP size.
  • Page 51 OPERATING THE ACU A Z . R A N G E E L . R A N G E 0 1 6 8. Set the AZIMUTH RANGE. (Range : 0 - 540) Press the LEFT and RIGHT arrow keys until the desired character is underscored (selected).

  • Page 52: Setting Antenna Parameters

    – Marine Satellite Television System Setting Antenna Parameters It is not recommended for a novice satellite service user to use this mode. S E T U P M O D E ? 4 Y E S 1. Press the LEFT key to move cursor to YES and press the OK key to enter setup mode.
  • Page 53 OPERATING THE ACU S C A N O F F S E T D I S E Q C T H R E S 1 0 0 6. Set the SCAN OFFSET. (Range : 0 -90) THe scan offset is to offset the angle difference between the black marker on the sub-reflector and the optical sensor.
  • Page 54 – Marine Satellite Television System Peak Level Tracking Level Detect Level Noise Level D E T E C T L E V E L T R A C K I N G L E V E L 0 6 0 0 3 0 9.
  • Page 55 OPERATING THE ACU W R S D E T E C T L E V E L V O L T T H R E S . 0 3 0 0 0 6 5 0 12. Set the WRS DETECT LEVEL (Range : 10 - 5,000) The WRS level is to set the WRS detection level.
  • Page 56 – Marine Satellite Television System O F F S E T D I F F . U S E W R S - 0 4 0 Y E S 15. Set the USE WRS. USE WRS is to determine whether the system uses WRS LEVEL or not.
  • Page 57 OPERATING THE ACU + T I L T B I A S 18. Set the TILT BIAS OFFSET. The tilt bias is required to be set when the system is newly installed or when the antenna control board is replaced. Check and see if the bubble is in the center of the circular bubble level vial.
  • Page 58 – Marine Satellite Television System Perfoming Antenna Diagnostic Tests It is possible to see the antenna's status by reviewing the diagnosis results of the antenna. Refer to the following codes, to understand the diagnosis results. S E T U P M O D E ? 4 Y E S 1.
  • Page 59 OPERATING THE ACU D I A G N O S I S C O M M U N I C A T I O N C O D E 1 0 1 R E S U L T : P A S S E D 6.

  • Page 60: Satellite Settings

    – Marine Satellite Television System Satellite Settings Setting the Satellite Pair S E T U P M O D E ? 4 Y E S 1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter setup mode.
  • Page 61 OPERATING THE ACU P R E S E T S L O T D E S T . S A T E L L I T E P R E S E T 1 A S T R A _ 1 6.
  • Page 62 – Marine Satellite Television System Edit Satellite Information It is possible to modify the existing satellite information and input new satellite in- formation into the ACU as well. It is not recommended for a novice satellite service user to use this mode.
  • Page 63 OPERATING THE ACU E D I T N A M E L O N G I T U D E A S T R A _ 1 0 1 9 . 2 0 E 6. Set the SATELLITE NAME. Press the LEFT and RIGHT arrow keys until the desired character is underscored (selected).
  • Page 64 – Marine Satellite Television System D I S E Q C + T R A C K P A R A M E T E R A U T O 10. Set the DISEQC. Press the UP and DOWN arrow keys to select DiSEqC Method* and press the OK key to set the DISEQC ("AUTO"...
  • Page 65 OPERATING THE ACU F R E Q U E N C Y S Y M B OL N I D 1 1 0 3 8 M H z 2 2 0 0 0 K H z 0 x 0 0 0 1 11-3.
  • Page 66 – Marine Satellite Television System Setting the Region S E T U P M O D E ? 4 Y E S 1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter setup mode.
  • Page 67 OPERATING THE ACU 4 S E L E C T C O N T I N E N T S E L E C T R E G I O N E U R O P E D E N M A R K 6.
  • Page 68 – Marine Satellite Television System [ 4 ] T H O R _ 1 S E A R C H [ 2 ] S I R I U S _ 1 11. Region information has been updated. LNB TYPE*...
  • Page 69 OPERATING THE ACU Finding the Transponder S E T U P M O D E ? 4 Y E S 1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter setup mode. 4 + S A T E L L I T E + A N T E N N A + S Y S T E M...
  • Page 70 – Marine Satellite Television System F R E Q . S Y M B O L A G C 1 6 9 1 2 4 2 8 M H z 2 0 0 0 0 K H z N I D 0 x 0 0 0 0 F n 5.

  • Page 71: System Settings

    OPERATING THE ACU System Settings Setting the LNB Type It is possible to select a local frequency from the ACU. It is not recommend- ed for a novice satellite service user to use this mode. S E T U P M O D E ? 4 Y E S 1.
  • Page 72 – Marine Satellite Television System L N B T Y P E L O C A L F R E Q . U N I V E R S A L 1 1 2 5 0 M H z 5.
  • Page 73 OPERATING THE ACU Setting the GPS and Gyrocompass S E T U P M O D E ? 4 Y E S 1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter setup mode.
  • Page 74 – Marine Satellite Television System L A T I T U D E L O N G T I T U D E H E A D I N G 4 1 . 5 0 N 0 8 7 . 3 7 W 0 0 0 .
  • Page 75 OPERATING THE ACU Setting the Remote Control S E T U P M O D E ? 4 Y E S 1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter setup mode. + A N T E N N A + S A T E L L I T E 4 + S Y S T E M...
  • Page 76 – Marine Satellite Television System P R E S S S A M E K E Y A G A I N 6-1. Press the same key again for confirmation. R E M O T E K E Y R E G I S T E R D 6-2.
  • Page 77 OPERATING THE ACU System Backup & Restore S E T U P M O D E ? 4 Y E S 1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter setup mode. + A N T E N N A + S A T E L L I T E 4 + S Y S T E M...
  • Page 78 – Marine Satellite Television System Display Versions S E T U P M O D E ? 4 Y E S 1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter setup mode.
  • Page 79 PC CONTROLLER SOFTWARE PC CONTROLLER SOFTWARE Introduction Program Initialing and Serial Port Setup Main Menu Controller Menus...
  • Page 80 – Marine Satellite Television System Introduction GUI Software of Intellian t110W/t130W has been created for the user to easily set up the antenna by using the user’s personal computer. Using the GUI program enables the user to easily monitor and modify the information of antenna, satellite and GPS.

  • Page 81: Program Initialing And Serial Port Setup

    PC CONTROLLER SOFTWARE Program Initialing and Serial Port Setup Data communication between the ACU and the antenna must be established as the first step in order to start setting your antenna. Figure 30. Setup for Serial Communication Baud Rate Setting: To display the speed of data communication. •...
  • Page 82 – Marine Satellite Television System Main Menu Figure 31. Main Menu Controller Menus Set Antenna GPS and Find Antenna Angle • Set Satellite Information • Set Tracking Information of Satellite (Primary) • • Set Tracking Information of Satellite (Secondary) •...

  • Page 83: Antenna Status

    PC CONTROLLER SOFTWARE Antenna Status • Search 2: The search range corresponds to the Search Pattern 2. Once the signal is located, the antenna will enter into Search 3 mode • Search 3: The antenna is detecting the satellite signal which is above the current tracking level threshold.
  • Page 84 – Marine Satellite Television System 2. Click “Update Default” button and click “ Yes ” button to update the system. Figure 33. Confirm the Update 3. Click the “OK” button to complete the update. Figure 34. Update has been completed...

  • Page 85: Controller Menus

    PC CONTROLLER SOFTWARE Controller Menus Set Satellite Information Select “Set Satellite information” from the controller menu. Figure 35. Set Satellite Information Satellite Information The name, longitude and confirmation method of the satellite will be displayed when a satellite is selected in the list box. Push the “Edit Satellite Information”...
  • Page 86 “City GPS”. Pushing the “Add City” button stores the GPS's information. By selecting the stored region in the list box, the GPS's information of that region is displayed. The Intellian t110W/t130W satellite TV antenna system utilizes GPS data to locate the satellite faster.
  • Page 87 PC CONTROLLER SOFTWARE Set Tracking Information of Satellite [Primary] Select “Set Tracking Information of Satellite [Primary]” from the controller menu. Figure 37. Set Tracking Information of Satellite [Primary] Command Buttons Edit Satellite Information: To change frequency information of the target •...
  • Page 88 – Marine Satellite Television System Voltage DiSEqC Discription 0KHz 22KHz 13V & 18V and DiSEqC 0KHz & 22KHz tone to LNB AUTO AUTO AUTO AUTO • 13V & 18V and DiSEqC 0KHz tone to LNB AUTO AUTO • 13V & 18V and DiSEqC 22KHz tone to LNB...
  • Page 89 PC CONTROLLER SOFTWARE Set Tracking Information of Satellite [Secondary] Select “Set Tracking Information of Satellite [Secondary]” from the controller menu. Figure 38. Setting up the Secondary Tracking Information Command Buttons Edit Satellite Information: To change frequency information of the target satel- •...
  • Page 90 – Marine Satellite Television System Move Antenna and Skew Calibration Select “Move Antenna and Skew Calibration” from the controller menu. Figure 39. Set up Move Antenna and Skew Calibration Command Buttons Go to Target Position: The current position (angle) of the antenna is •...
  • Page 91 Antenna Information and Set Antenna Parameters for Control It is not recommended for a novice at satellite service to use this mode. Consult Intellian for changing antenna parameters. Select “Antenna Information and Set Antenna Parameters for Control” from the controller menu.

  • Page 92: Parameter Settings

    – Marine Satellite Television System Parameter Settings Scan Offset: The scan offset is to offset the angle difference between the • black marker on the sub-reflector and the optical sensor. • EL Adjust: The elevation adjustment is to offset the angle difference between the mechanical elevation angle and actual elevation angle.
  • Page 93 PC CONTROLLER SOFTWARE Diagnosis and Set Antenna Parameters for Control Select “Diagnosis and Set Antenna Parameters for Control” from the controller menu. Figure 41. Diagnosis and Set Antenna Parameters for Control Command Buttons Diagnosis: If the “Diagnosis” button is pressed, the system will carry out the •...
  • Page 94 – Marine Satellite Television System Parameter Settings Wait Time: To set the time-out for automatic initiation of a search • after the signal level drops below threshold. Search Step: To define the increment search range step size. • •...

  • Page 95: Warranty

    Warranty This product is warranted by Intellian Technologies Inc., to be free from defects in materials and workmanship for a period of Three (3) YEARS on parts and ONE (1) YEAR on labor performed at Intellian Technologies, Inc. service center from the purchased date of the product.
  • Page 96 – Marine Satellite Television System Appendix : t110W Technical Specification General Approvals CE – conforms to EU Directive 89/336/EEC FCC – verified to CFR47:Part 15 Dimensions Satellite antenna unit 133cm (52.4”) x 142cm(55.9”) Antenna dish diameter 105cm(41.3”) Antenna control unit 43cm(16.9”)x29.58cm(11.6”)x4.4cm(1.7”)
  • Page 97 Technical Specification Appendix : t130W Technical Specification General Approvals CE – conforms to EU Directive 89/336/EEC FCC – verified to CFR47:Part 15 Dimensions Satellite antenna unit 155cm (61.0”) x 168.9cm (66.5”) Antenna dish diameter 125cm(49.2”) Antenna control unit 43cm(16.9”)x29.58cm(11.6”)x4.4cm(1.7”) Weight Satellite antenna unit 117kg (258 lbs) Antenna control unit...
  • Page 98 – Marine Satellite Television System APAC Headquarters Seoul Office Intellian Technologies, Inc. Intellian Technologies, Inc. 348-5 Chungho-Ri, Jinwi-Myeon 2F Dongik Building, 98 Nonhyun-Dong Pyeongtaek-Si, Gyunggi-Do 451-862 Korea Gangnam-Gu, Seoul 135-010 Korea T +82 31 379 1000 F +82 31 377 6185...
