UN2616ACT
FREE HELP
Grill Information Center:
FROM THE GRILL EXPERTS
Grand Hall is the expert on this product
and trained to help you with:
Ÿ
Assembly Questions
Ÿ
Grill Operation
Ÿ
Replacement of Damaged or Missing parts
visit www.grandhall.com or call:
1-800-474-5587
Monday - Friday 8:00am-4:30pm PST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL #
__________________
(see silver CSA label on main body of grill)
Assembly Instructions
UN3216ACT
WARNING
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Ÿ
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled, installed and maintained.
Ÿ
Use your grill at least 3 feet away from any
wall or surface. Use your grill at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences
and overhangs or sources of ignition including
pilot lights on water heaters and live electrical
appliances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
Ÿ
Never use your gas grill in a garage, porch,
shed, breezeway or any other enclosed area.
Ÿ
Never obstruct the flow of ventilation air
around your gas grill housing.
Ÿ
Never disconnect the gas regulator or any gas
fitting while your grill is lit. A lit grill can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Manual # P80151149A - Date:2015/12/15
!
Advertisement
Related Manuals for Barbeques Galore UN2616ACT
Summary of Contents for Barbeques Galore UN2616ACT
- Page 1 Assembly Instructions UN2616ACT UN3216ACT FREE HELP WARNING Grill Information Center: FROM THE GRILL EXPERTS Ÿ Failure to comply with these instructions could Grand Hall is the expert on this product result in a fire or explosion that could cause and trained to help you with: serious bodily injury, death or property damage.
-
Page 2: Part Description
PART # PART DESCRIPTION PURPOSE OF PART P06013019B Hardware Pack For use to assemble UN2616ACT & UN3216ACT S182G04061 Pan Head Screw 1/4"x3/8" Install Caster Seats to the Cart Side Panels S182G03061 Pan Head Screw 3/16"x3/8" S182G03061 Pan Head Screw 3/16"x3/8"... - Page 3 Parts Diagram for Model UN2616ACT...
- Page 4 Parts List for Model UN2616ACT DES TRIP TIO N P ART# Q TY. L P R e g u la to r H o s e H o ld e r P 0 5 5 3 6 0 0 3 4...
- Page 5 Parts Diagram for Model UN3216ACT...
- Page 6 Parts List for Model UN3216ACT DES TRIP TION P ART# Q TY. L P R e g u la to r H o s e H o ld e r P 0 5 5 3 6 0 0 3 4 G rill B o w l Trim P a n e l, L e ft P 0 0 7 4 2 0 2 6 4 G rill B o w l Trim P a n e l, R ig h t...
- Page 7 Assembly Instructions for Model UN2616ACT & UN3216ACT CAUTION : Even though it is possible for one person to assemble this grill, it is better to obtain assistance from another person when handling the large, heavy pieces. Install Caster Seats Attach the Left Front(LF) and Left Rear(LR) Caster Seats on the Left Cart Side Panel using 2 Pan Head Screws 1/4"x3/8"...
- Page 8 Install Cart Rear Panel and Hose Holder Install the Cart Rear Panel to the Cart Side Panels using 6 Pan Head Screws 3/16"x3/8" and tighten securely as shown. Attach the Regulator Hose Holder onto the left side of Cart Rear Panel using 1 Pan Head Screw 3/16"x3/8" and tighten securely as shown.
- Page 9 Install Cart Partition Panel Bracket and Cart Partition Panel (For UN3216ACT only) Install the Cart Partition Panel Brackets onto the Cart Bottom Panel using 2 Pan Head Screw 3/16"x3/8" as shown. Align the 2 holes on the Cart Partition Panel with the 2 holes on the Cart Partition Panel Bracket. Insert 2 Pan Head Screws 3/16"x3/8"...
- Page 10 Install Cart Front Bracket Attach 2 Pan Head Screws 3/16"x3/8" to the front inside edges of both Cart Side Panels, tighten it half way only. Install the Cart Front Bracket to the Cart Side Panels with the notchs on both ends match the screws.
- Page 11 Install Left/Right Grill Bowl Trim Panel Install the Left Grill Bowl Trim Panel on the top of the Left Cart Side Panel using 3 Pan Head Screws 3/16"x3/8" and tighten securely as shown. Repeat the same steps for the Right Grill Bowl Trim Panel. Grill Bowl Trim Panel, Left Pan Head Screw 3/16"x3/8"...
- Page 12 Install Side Shelves Remove pre-assembled 1 Pan Head Screw 3/16"x1/2" and 2 Countersunk Flat Head Screws 3/16"x1/4" from the Right Bowl Side Panel as shown. Keep the 1 Pan Head Screw 3/16"x1/2" for reinstallation. Attach the Right Side Shelf onto the Right Bowl Side Panel using 4 Hex Head Screw 3/16"x3/8" and the removed 1 Pan Head Screw 3/16"x1/2"...
- Page 13 Install LED Control Box(For OB26 & OB32 only) Open the Doors, locate the LED Control Box on the right side. The LED Control Box is assembled with a old Mounting Bracket for built-in model. Detach the Bracket by removing the two screws.(See Fig.3) Replace the Bracket for Cart model.
