KOBALT
and the K Design
®
trademarks of LF, LLC. All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Serial Number _______________ Purchase Date _______________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-3KOBALT (1-800-356-2258), 8 a.m. - 8 p.m., EST, Monday - Friday.
AB12443
are registered
®
20-VOLT
IMPACT WRENCH
MODEL #K20LW-26A
kobalttools.com
ITEM #0437515
Français p. 11
Español p. 21
Advertisement
Table of Contents
Related Manuals for Kobalt K20LW-26A
Summary of Contents for Kobalt K20LW-26A
- Page 1 IMPACT WRENCH KOBALT and the K Design are registered ® ® MODEL #K20LW-26A trademarks of LF, LLC. All Rights Reserved. Français p. 11 Español p. 21 ATTACH YOUR RECEIPT HERE Serial Number _______________ Purchase Date _______________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-800-356-2258), 8 a.m.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Specifications ............. . 2 Safety Information . -
Page 3: Safety Information
SAFETY INFORMATION Know the Tool To operate this tool, carefully read this manual and all labels affixed to the impact wrench before using it. Keep this manual available for future reference. Important This tool should only be serviced by a qualified service technician. Read all Instructions Thoroughly General Safety Rules for all Power Tools WARNING: Read all safety warnings and all instructions. - Page 4 SAFETY INFORMATION Personal Safety • Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. • Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection, used for appropriate conditions, will reduce personal injuries.
-
Page 5: Preparation
SAFETY INFORMATION Battery Tool Use and Care • Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. • Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire. • When a battery pack is not in use, keep it away from other metal objects, such as paper clips, coins, keys, nails, screws or other small metal objects that can make a connection from one terminal to another. -
Page 6: Package Contents
PACKAGE CONTENTS PARTS DESCRIPTION Variable-speed trigger switch Direction-of-rotation selector (forward/center lock/reverse) 1/2 in. square driver Battery pack Battery-release button LED work light WARNING: Do not allow familiarity with the impact wrench to cause carelessness. Remember that one careless moment is enough to cause severe injury. Before attempting to use any tool, be sure to become familiar with all of the operating features and safety instructions. -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS 1. To Attach Battery Pack a. Place the direction-of-rotation selector ( B ) in the center ( locked ) position. b. Align the raised portion on the battery pack (D) with DETACH the grooves on the bottom of the impact wrench, and then slide the battery pack onto the impact wrench as shown. - Page 8 OPERATING INSTRUCTIONS 3. Direction-Of-Rotation Selector (Forward/Center Lock/Reverse) The direction of bit rotation is reversible and is controlled by a selector located above the trigger switch (A). With the impact wrench held in the normal operating position, pointing away from you: a.
- Page 9 OPERATING INSTRUCTIONS Tightening Fasteners WARNING: Battery tools are always in operating condition. Therefore, the direction-of-rotation selector should always be locked when not in use or carrying at your side. Tighten fasteners with the impact wrench. The proper fastening torque may differ depending on the type or size of the bolt, the material of the workpiece to be fastened, etc.
-
Page 10: Care And Maintenance
This warranty excludes blades, bits, bulbs and accessories. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state. Printed in China KOBALT and the K Design are registered trademarks ®...
