- Page 1 Avaya 3631 IP Wireless Handset Configuration Guide for Co-existence with the Avaya 3641/3645 IP Wireless Handset Offering Edition 1.0 January 20, 2011 Document number: 21-603883 All rights reserved for Avaya Inc. and Avaya Deutschland GmbH...
-
Page 2: Table Of Contents
ULTIMEDIA REQUIREMENTS INCLUSIVE VIEW ) ..................6 REQUIREMENTS 4.3.1 Upgrade a 3631 installed base from QoS = none to WMM basic ....6 802.1 /WPA/WPA2, ECURITY OPTIONS AND CONFIGURATION INCLUSIVE OF COMMUNICATION MANAGER ADMINISTRATION CONSIDERATIONS AND GUIDELINES ......................7 ..........7... -
Page 3: Introduction
- 3 - 1 Introduction The Avaya IP wireless handset 3631 was generally available from 2007 to 2010. It will be “end of sales” from January 1 2011, see https://support.avaya.com/css/P8/documents/100113780. The Avaya IP wireless handsets 3641 or 3645 can be used as successor. - Page 4 Mute Button OK Button Navigation Button Left Soft Button Right Soft Button End/Power Button Send Button Cancel Button Speakerphone Button A-menu Button Dial Pad Key-Lock Button Quiet mode Button Microphone All rights reserved for Avaya Inc. and Avaya Deutschland GmbH...
-
Page 5: Handset Configuration
It is recommended to use the 3631 and 3641/3645 phones with QoS (Quality of Service) = WMM, because otherwise an AVPP must be purchased and installed for the 3641/3645 phones, but the QoS strategies of the 3631 phones (none or WMM) and 3641/3645 phones (SVP) would not be synchronized with the risk, that access points would become overloaded. -
Page 6: Configuration Within The Same Ssid
4.2 Configuration within multiple SSIDs Configure 364x phones with different WLAN System Set Identifiers SSID as used by 3631 phones. This can be used, if e.g. the installed base of 3631 uses a security method, which 3641/3645 don´t support. Advantages: Required WLAN settings for 364x phones can be done without disturbing the current setup. -
Page 7: Guidelines
4. WPA2-PSK: 364x only supports AES encryption (while 3631 also supports WPA2-PSK with TKIP). 5. WMM: 364x requires that the AP´s WMM policy is set to Required or Allowed (while 3631 can also work with WMM disabled). 6. SW upgrade: 3631 requires a HTTP server for SW upgrade. 364x uses a TFTP server for SW upgrade (alternatively SW upgrade can be done locally through the HAT tool). -
Page 8: Verification Tests And Troubleshooting
Then configure a few new 364x phones, connect them to the network and verify that they go into service. Finally verify the co-existence of both phone types (calls between 3631 phones and 364x phones, QoS if 3631 and 364x phones are associated to the same WLAN Access Point, …).
