10F. Lightspeed Rocket Traffic Bridge - 10Gb Fiber Rear Panel Connections
Power Cor r d Power Cords ds
Power Good LEDs Power Good LEDs
AC Power AC Power
Inlets Inlets
USB Ports (Gen 2) USB Ports (Gen 2)
USB Ports (Gen 3) USB Ports (Gen 3)
Step 1 Connect one end of the yellow Ethernet cable
into the Ethernet port labeled MANAGEMENT.
Step 2 Connect the other end of the yellow Ethernet
cable into an available switch port on your Local
Area Network. This port will require Internet
access.
Step 3 Please review the latest Lightspeed Systems
Rocket Web Filter Product Manual on the
Lightspeed Systems Community Site at
(http://community.lightspeedsystems.com/
documentation/web-filter3/).
Step 4 Connect the power cords.
Step 5 Proceed to Front Panel Operation on page 18.
CAUTION
The power supply is hot-swappable only when you have a server with
redundant power supplies installed. If you only have one power supply
installed, before removing or replacing the power supply, you must first
take the server out of service, turn off all peripheral devices connected to
the server, turn off the server by pressing the power button, and unplug the
AC power cord from the server or wall outlet.
NOTE: The server offers redundant, hot-swap capability. The connections
to AC mains should be made in a manner appropriate to local code and
consistent with customer power distribution with or without redundant
sources.
Lightspeed Rocket Hardware Installation Guide
*NOTE: Please install the SFP (Small Form-factor Pluggable) prior to powering on the appliance.
4 4 4
Management Management anagement age
Port Por Port
Auxilliary Auxilliary Auxilliary xilli
Port Port Port
INTERN INTERNAL* INTERNAL* ERN
Video Port V ideo Port
1 1
Ethernet Ether net net
Cable Cable
Power Supply Status LED
There is a single bi-color Power Good LED on each
power supply module to indicate power supply status.
The LED operation is defined in the table below.
Power Supply Condition
Output ON and OK
No AC power to both power supplies
AC present / Only 5VSB on (PS off)
AC cord unplugged or AC power lost; with a
second power supply in parallel still with AC
input power
Power supply warning events where the power
supply continues to operate; high temp, high
power, high current, slow fan
Power supply critical event causing a shutdown;
failure, OCP, OVP, fan fail
In normal operation the Power Good LED on Power Supply Module
1 and Module 2 will be SOLID GREEN. If the power is down, both
LEDs will BLINK GREEN.
Network Interface Connectors Network Interface Connectors
EXTERNAL* EXTERNAL* ER
Local Local
Ar Area ea
Network Network
2 2 2
LED State
GREEN
AMBER
1Hz Blinking
AMBER
AMBER
OFF
OFF
