- Page 1 StealthyPro Instructions 3-point Shooter Mode / Handheld Mode / Monopod Mode Place the black piece between the handle and the silver ring (as pictured).
- Page 2 In stabilizer mode, thread the handle up (ar- row shown in picture). This way, the handle will clear the base of the StealthyPro. Then place the black piece below the handle. On earlier versions of the StealthyPro, the piece must be inserted with the depression facing upward (as shown).
- Page 3 Stealthy from one useful mode to another. The VariZoom Stealthy has won 3 prominent Awards including The 2013 “Black Diamond Award” TV Technologies 2013 “Superior Technology Award” as well as Videomaker’s “Best Accessory” for 2013.
- Page 5 Getting familiar with adjustments on Your Stealthy 1. Caution: Always use fingers and thumbs to adjust. Never should you need to tighten with a hand grip. Finger strength only is required. Never turn the handle of stealthy when the bottom of handle is engaged with another part of Stealthy body.
- Page 6 screw is not loose. (Note: You should never unlock the gimbal when the bottom of handle is engaged. If you do the handle will turn and can cause damage to device if operator continuously turns handle while engaged.) 6. Camera plate: The camera plate is slid into and removed from the captive re- ceiving platform.
- Page 7 Stealthy Modes: 10. Handheld mode / Holster mode / table rest mode: (see diagrams) These modes are all basically the same configuration but used and applied differently. The Stealthy in this mode is folded up. On the monopod there is a chrome plated ring that should rest in half round arc of Stealthy main body.
- Page 8 You are now in monopod mode and may adjust the height of monopod by using the #9. (Short monopod) adjustment to raise and lower the height by adjusting telescoping tube. 11. A. Long monopod accessory: If you have the long monopod accessory you can add this long attachment by simply sticking the threaded end of long monopod acces- sory in to the hole at bottom of Stealthy short monopod until is it meets the threaded hole inside then you can turn clockwise until the long monopod is securely attached.
- Page 9 12. 3-point Shooter / Tripod mode: To adjust from monopod mode in to 3-point shooter mode you will need to do 3 things: A. #2. Handle Lock Knob is loosened with thumb and index finger while handle is held and base of monopod rests on lap of oper- ator or a table type surface.
- Page 10 13. Stabilizer mode: This mode is the toughest to describe and best demonstrat- ed by video which can be found online at www.Stealthy.TV or at www.VariZoom.com/ Stealthy.
- Page 11 Please watch video and have all weights and allen wrench that was included with Stealthy. The video will show you how to balance the device quickly and how to begin using the camera stabilizer mode. Stealthy includes: belt hook, 3 ring weights, and allen wrench. Optional accessories (not included): Long monopod, Weights for cameras over 2 3/4 lbs.
