AQG-10072-01
FL6500 Series
Quick Guide
NAVIGATION
The Windows® Embedded Handheld operating system en-
hances the ability of the handheld to recognize touch gestures,
making it easy to use a finger to navigate. The keyboard or the
stylus also can be used.
Navigation options vary depending on the screen you are
viewing.
VERTICAL AND HORIZONTAL MOVEMENT
•
Flick up, down, or sideways on the touchscreen.
•
For more precise positioning, touch, hold, and move the
screen up or down.
•
Use the scroll bar if it is available.
•
Use the navpad to move around on a screen.
•
A horizontal scrolling menu is located on control panel
screens near the top.
TOUCHSCREEN SELECTION
•
Press or tap the function gadget or application icon you
want to select, turn on, activate, or turn off.
•
Press and hold a function gadget to bring up a control
panel, menu, or list.
KEYBOARD SELECTION
•
Use the up, down, right, and left arrow keys on the nav-
pad to select (highlight) a gadget or icon on the screen. A
ring appears around the selection.
•
Perform the selected action by pressing the return key
or the center action key. For dashboard gadgets like Wi-
Fi, one press of the return key shows you which icon is
selected, a second key press performs the action, and a
third key press turns the action off. For application icons
on the Start screen or in favorites, continue to use the
arrow keys on the navpad and return or action keys until
you get to the screen or menu you want.
FIELDLOGIC INSTALLATION
FieldLogic setup and configuration is handled through
FieldLogic Hub which runs on a PC. For instructions on how
to install FieldLogic Hub, please see the FieldLogic Hub Quick
Guide or the FieldLogic Installation Guide.
FieldLogic Hub allows you to set up the device configurations
that you will want to use within FieldLogic and also allows you
to define which primary and secondary tasks for FieldLogic
Tools will appear on the home screen of the FL650X.
Once you have the appearance and configurations defined in
FieldLogic Hub there are two different methods you can use to
install the configuration bundles on the FL650X.
1. Connect the FL650X directly to the PC running FieldLogic
Hub using the ethernet connection. Once connected,
you can register the FL650X in Hub and the default
configuration will automatically be downloaded into the
FL650X.
2. Use a USB flash drive to transfer the configuration bundles.
Plug in a USB flash drive to the PC running FieldLogic Hub
and then in Hub, go to Tools > Create installation media
and follow the steps as directed. Once you are finished, you
can remove the USB flash drive from the PC and plug it into
your FL650X. The installation files will automatically upload
once the USB flash drive is plugged in.
Once you have installed the software, the FL650X screen will
appear with FieldLogic Tools as an option in the Start menu.
