Sensus SonixIQ 250CFH Quick Manual

FEATURES

250CFH or 400 CFH meter class options
Live temperature compensation
Fixed factor pressure compensation
Alarm notifications
Configurable volume pulse output
Configurable scrolling LCD display
20-year battery life
FlexNet SmartPoint® inside (available
with or without)

IDENTIFICATION

The SonixIQ meter with the FlexNet module
will have a visible label containing the
following information:
Model: SONIXIQ
FCC ID: SDBSONIXIQ
IC: 2220A-SONIXIQ
SonixIQ
Quick Guide
The SonixIQ is a solid state residential gas meter, providing
pinpoint accuracy of ultrasonic measurement and no
moving parts to replace or wear out over time. Available
with or without an integrated FlexNet® radio, the SonixIQ
covers both 250 or 400 CFH needs.
The SonixIQ has an LCD display that supports walk up readings and
status, an optical port that can be used with the SonixCom tool for
configuration, a pulse output, and an optional integrated radio for
communication across the Sensus FlexNet system.

Application and Safety

The SonixIQ should be used with clean, dry natural gas or air only. The
meter electronics are enclosed in a vented case that provides both
weather and EMC protection.
Only suitable non incendive circuits and non incendive field wiring
should be connected to the field wiring terminals via the pulse cable.

Meter Specifications

SonixIQ 250 series
Capacity 250 to 299 cfh at 1/2" differential
Connections 20LT connections on 6" center to
center
MAOP 10 psig
Dimensions 9.94" L x 4.38" W x 7.89" H (25.25cm L x 11.13cm W x 20.04cm H)
Weight 6.3 lb (2.86 kg)
Operating -40° to +150°F (-40° to +66°C)
Temperature
Humidity 0 to 95% relative humidity operating and storage (non-condensing
and condensing)
QUI CK G UI DE
400 series
400 to 450 cfh at 1/2"
differential
30LT connections on 6" center
to center
GQG-10004-01
