Summary of Contents for SEI CARSHAW CM979000TX
- Page 1 CM979000TX 4PC CONSOLE/MIRROR/ SCONCE PAIR SET - CARSHAW For assistance with assembly contact: Southern Enterprises, Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com wwww.seidal.com...
- Page 2 4PC CONSOLE/MIRROR/ SCONCE PAIR SET - CARSHAW Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 3 Leg Stabilizer Bar Stabilizer Cap 16pcs Φ1/4"x 1/2"L Bolts Allen Wrench 4pcs 4pcs Plastic Anchors Mounting Screws Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth. Call Customer Service at 1-800-633-5096 Avoid rubbing or scratching the Do not return product to store, please call surface with rough or abrasive objects.
- Page 4 4PC CONSOLE/MIRROR/ SCONCE PAIR SET - CARSHAW Assembly Instructions Console Table: Figure 1 Place the table-top frame (A) upside down on cloth covered work surface and attach the scroll pattern (B) with two bolts (H) vertically above the apron, as shown. Tighten these two bolts (H) completely.
- Page 5 Attach scroll pattern under the metal frame (A) to Figure 3 front legs (C, D) using two bolts (H) and only tighten halfway. 1. Attach leg stabilizer bar (F) to the four legs (C, Figure 4 D, E1, E2) using four bolts (H). 2.
- Page 6 1. Place table upright on the floor. Figure 5 2. Screw stabilizer cap (G) into the leg stabilizer bar (F). Tighten securely. The table is completely assembled. Figure 6 ** We recommend that you save the Allen wrench ** Weight restriction: 40 lbs. (I) and periodically tighten all bolts.
- Page 7 4PC CONSOLE/MIRROR/ SCONCE PAIR SET - CARSHAW Installation Instructions Mount the mirror and two wall sconces on the wall, as following steps. 1. The products should be mounted to studs in the wall if possible. If studs are not available, the products should be mounted into drywall using the plastic anchors and screws provided.
- Page 8 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
