- Page 1 CM234800TX Harvey Mixed Tone Credenza For assistance with assembly, contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com PO#: Page | 1...
- Page 2 Harvey Mixed Tone Credenza Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity of 4 Metal Rail Quantity Quantity Quantity of 12 of 12 of 16 Cam Lock Wood Dowel Dia 8 x 30mm Cam Bolt Quantity Quantity Quantity of 3 of 16 of 3 Flat Head Screw Dia 1/8” x 5/8”L (For Magnet and Bracket) Magnet Plate Magnet...
- Page 4 Quantity Quantity Quantity of 32 of 20 of 20 Round Head Screw Spring Washer Dia1/8”x1/2”L (For Back Panel) Flat Washer Quantity Quantity Quantity of 16 of 4 of 1 Allen Wrench Short Bolt Ø1/4” x 1/2”L Long Bolt Ø1/4” x 1-1/2”L Quantity Quantity Quantity...
- Page 5 Harvey Mixed Tone Credenza Assembly Instructions Screw with fingers to help align screws before using screwdriver. Attach Magnets (4) to Top Panel (A) using Flat Head Screws (5). Tighten Flat Head Screws (5) with Phillips screwdriver. Figure 1 Screw with fingers to help align cam bolts before using screwdriver.
- Page 6 Insert Cam Locks (2) into holes on assembled unit. Screw Cam Bolts (1) and insert Wood Dowels into holes on Bottom Panel (B). Insert T-Nut (12) into predrilled holes on Side Panels (C & D). Attach Bottom Panel (B) to assembled unit by inserting Wood Dowels (3) and Cam Bolts (1) into corresponding holes until panels meet.
- Page 7 Attach Metal Frame (L) to Metal Rails (M) with Short Bolts (16), Spring Washers (15) and Flat Washers (14) as shown. Do not fully tighten bolts until Figure 8 is complete. Figure 5 Attach second Metal Frame (L) to assembled rail with Short Bolts (16), Spring Washers (15) and Flat Washers (14) as shown.
- Page 8 Attach Leg’s Levelers (10) to rail by hand. Figure 7 Connect assembled rail to assembled unit with Long Bolts (17), Spring Washers (15) and Flat Washers (14) as shown. Tighten Long Bolts (17) with Allen Wrench (18). Check and tighten all Bolts with Allen Wrench (18).
- Page 9 Attach Hinges (8) to Door Panels (H), (I) and (J) with Screws (9). Tighten Screws (9) with Phillips screwdriver. Attach the Metal Plates (6) onto the inside of the door frames using Flat Head Screws (19). Tighten Flat Head Screws (19) with a Phillips screwdriver.
- Page 10 Insert Shelf Pins (7) into corresponding holes on Side Panels and Vertical Panels. Place Adjustable Shelves (G) onto Shelf Pins as show. Figure 11 To open doors, push on corner corresponding to magnet. Push door on corresponding corner to close. close open Figure 12...
- Page 11 Attach Brackets (22) to back panel using Screws (5). Tighten Screws (5) using Philips screwdriver. Mark two desired locations on wall and drill two 3/16" holes. Insert Plastic Anchors (21) into two holes on wall as shown. Use a hammer to insert plastic anchors until they are flush with wall.
- Page 12 Tip: If the Credenza is not level, please adjust the Leg’s Leveler (10) by hand as shown. Figure 15 Now your Harvey Mixed Tone Credenza is ready for use. Figure 16 Page | 12...
-
Page 13: Parts Replacement Form
Parts Replacement Form Page 4 Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
