- Page 1 CK622400TX Nailhead Cocktail Table Trunk For assistance with assembly contact: Southern Enterprises Inc. Assembly Instruction Customer Service 1-800-633-5096 service@seidal.com www.seidal.com Max top load Max load inside the trunk...
- Page 2 CK622400TX Nailhead Cocktail Table Trunk Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown actual size. Using a screw that is too long will cause damage.
- Page 3 8 PCS I 8 PCS J 1 PC Small Cam Screw Small Cam Lock Wrench φ6.8 x 36mm φ15 x 12mm 8 PCS L 8 PCS M 29 PCS Screws 3.5 x 16mm Dowel 8 x 30mm Bolts 1/4” x 2-3/4” 1 PC 1 PC P 1 PC...
- Page 4 CK622400TX Nailhead Cocktail Table Trunk Assembly Instructions Step 1: Put all parts on a soft surface to prevent scratches, attach handle-A (O) to the top (A) by using screw (M) and phillips screwdriver to tighten it as shown. Step 2:...
- Page 5 Step 4: Attach handle (Q) to left side panel (D) and right side panel (G) by using screw (M) and phillips screwdriver to tighten it as shown. Step 5: Screw small cam screw (H) into back panel (C ) as shown. Step 6: Insert dowel (K) into to left side panel (D) and right side panel...
- Page 6 Step 7: Turn the trunk base up side down and attach leg (F) to the bottom of trunk by using screw (L) as shown. Step 8: Attach top (A) to the trunk base by using screw (M) and phillips screwdriver to tighten it as shown.
- Page 7 We'd love to hear from you! Email us photos of our products in your home at sei@seidal.com and we might feature it on our site or use it to model one of our inspirational photos. “ PARTS WILL BE SENT IF AVAILABLE FORM SEI “...
