- Page 1 CM915700TX Mirage Mirrored Console For assistance with assembly, contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com Page 1...
- Page 2 Mirage Mirrored Console Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing.
- Page 3 Mirage Mirrored Console Assembly Instructions Pull out the bottom drawers as shown. Figure 1 Connect the legs (B1, B2, B3, B4) to table top (A) with flat washers (1) and bolts (2). Tighten bolts with Allen wrench (3) as shown. Figure 2 Page 3...
- Page 4 Mirage Mirrored Console Assembly Instructions Insert the drawers into the right position. Figure 3 Attach knobs (5) onto drawer front with the plastic pads (6) and bolts (4). Tighten bolts with Phillips screwdriver. Caution : Please do not over tighten knobs, stop when you feel tight.
- Page 5 Mirage Mirrored Console Assembly Instructions Now your new Mirage mirrored console is ready to use. Figure 5 Page 5...
- Page 6 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
