- Page 1 Split-Top Console - White / Burnt Oak Console - Black / Burnt Oak ASSEMBLY INSTRUCTIONS...
- Page 2 Split-top console Parts list Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the Screw diagrams below.
- Page 3 SPLIT-top console Assembly Instructions Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page Attach Metal rail (E/F) to apron (D) using short bolts (1), tighten short bolt (1) using Allen wrench (4) as shown in figure 1.
- Page 4 Repeat above step to attach other leg (C) to pre-assembled unit in figure 2 as shown. Figure 3 Attach big top (A) to metal rail (E) & leg ( C) using short bolt (1) & flat washer (2), Attach big top (A) to metal rail (F) using long bolt (5) &...
- Page 5 metal Attach small top (B) to rail (E) & leg (C) with short bolt (1) & flat washer (2) Tighten short bolt (1) using Allen wrench (4) as shown Figure 5 Now you split-top console is ready for use Figure 6 Page 5...
- Page 6 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
