- Page 1 CK404700TX 3PC NESTED COCKTAIL/END TABLE SET For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com Page 1...
- Page 2 CK404700TX--3PC NESTED COCKTAIL/END TABLE SET Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage.
- Page 3 Do not return product to store, please call abrasive objects. Manufacturer for assistance, questions or Parts. Page 2 CK404700TX--3PC NESTED COCKTAIL/END TABLE SET Assembly Instructions Assembly Instructions: Unpack and lay parts on clean, padded surface like carpet or blanket.
- Page 4 Figure 3 Page 3 Add 6pcs Glass PAD into Large Frame(A) by hands. Figure 4 Put Large Mirror Panel(J) onto the Large Frame(A).
- Page 5 Figure 5 Page 4 Push the Legs(E) into short square tube(H); Insert 16pcs Bolt (1) and 16pcs Flat washer(2) tighten then by allen wrench(4). Figure 6 Push the Legs(E) into square short tube(H); Insert 16pcs Bolt (1) and 16pcs Flat washer(2) tighten then by allen wrench(4).
- Page 6 Insert 16pcs Bolts(1) and 8pcs Flat washer(2) attach the 4pcs Legs(C & D) to Large Frame(A) tighten then by allen wrench(4). Figure 8 Page 6 Add 8pcs Glass PAD into Small Frame(A) of 2pcs End table by hands. Figure 9 Put 2pcs small mirror Panel(K) onto the small Frame(B) of 2pcs End table.
- Page 7 Now 3pcs nested cocktail and end table are ready to use. Max loading weight for coffee table is 40 lbs. Max loading weight for End table is 20 lbs. Page 7 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number:...
- Page 8 Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product. Replacement, if available, will be honored within this time frame. Parts will not be available for items arriving fully assembled. We do not recommend modifying product(s) and we are not responsible for any damages due to product modification(s).
