- Page 1 CM501400TX Morgana Console Assembly Instructions For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seifurniturestore.com Page 1...
- Page 2 CM501400TX Morgana Console Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or a blanket. Check that you have all the parts indicated. Call customer service if any hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 6 of 2 of 2 Washer Anti-tipping hardware Wood screw Φ1/8”x1-1/2”L Quantity of 1 Right Arm Hinge Quantity Quantity Quantity of 1 of 1 of 1 Top Panel Bottom Panel Left side panel Quantity Quantity Quantity of 1 of 1 of 1...
- Page 4 CM501400TX MORGANA CONSOLE Assembly Instructions Attach Hinges (O) and Washers (S) to Small Door (9) with Screws (E). Attach Hinges (N) and Washers (S) to Big Door (10) with Screws (E). Tighten Screws (E) with Phillips screwdriver (not included). Figure 1 Attach the Plastic Caps (P) to Side Legs (11).
- Page 5 Attach Bumper Bases (R) to Top Panel (1) with Screws (E). Tighten Sscrews with phillips screwdriver (not included). Figure 3 Insert Bumper Pipes (Q). Note: Bumper Pipes (Q) should be facing the front. Figure 4 Page 5...
- Page 6 Attach Legs (11) to the Bottom Panel (2) with Bolts (A) and Bolts (B). Tighten Bolts with Allen Wrench (D). Figure 5 Attach Side Panels and Vertical Panels (3/4/5/6) to Bottom Panel with Bolts (C). Tighten Bolts with Allen Wrench (D). Figure 6 Page 6...
- Page 7 Insert Back Panels (7/8) into pre-assembled unit from Figure Figure 7 Insert Cam Locks (K) into holes on pre-assembled unit from figure 7. Screw Cam Bolts (J) into holes on Top Panel (1). Attach Top Panel (1) to pre-assembled unit from figure 7 by inserting Wood Dowels (I) and Cam Bolts (J) into corresponding holes until...
- Page 8 Attach Back Panel Parts (H) to back of the unit with Screws (F). Tighten Screws with Phillips Screwdriver (not included). Figure 9 Mark two desired locations on wall. Drill two 3/16" holes on wall. Insert plastic anchors (U) into the 2 holes on wall. (When doing this, you will need a hammer help you).
- Page 9 Attach the Anti-tipping Hardware (W) to Plastic Anchors with Wood Screws (X) and Washers (V). Tighten screw with Phillips Screwdriver (not included). Move the unit close to the Anti-tipping Hardware (W) and insert Anti-tipping Hardware (W) through Back Panels (8). Figure 11 Attach Anti-tipping Hardware (W) to Top Panel with Washers...
- Page 10 Attach pre-assembled units from Figure 1 to pre-assembled unit from Figure 7 with Screws (G). Tighten Screws with Phillips Screwdriver (not included) Figure 13 Attach Arm Hinges (M/Y) to pre-assembled unit from Figure 8 with Screws (E). Tighten Screws with Phillips Screwdriver.
- Page 11 Now your Morgana Console is ready for use! Figure 15 Page 11...
-
Page 12: Parts Replacement Form
Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
