Introduction

Read this manual carefully to learn how to operate and
maintain your product properly. The information in this
manual can help you and others avoid injury and product
damage. Although Toro designs and produces safe
products, you are responsible for operating the product
properly and safely. You may contact Toro directly at
www.Toro.com for product and accessory information,
help finding a dealer, or to register your product.
Note: If you are installing this kit (the Pro Control XP
Spray System Kit) along with one or more other kits,
such as the Eductor Kit (model 41612), the Electric
Hose Reel Kit (model 41613), or the Tank Rinse Kit
(41614), we recommend that you assemble the kits into
the manifold valve assembly at the same time.
Whenever you need service, genuine Toro parts, or
additional information, contact an Authorized Service
Dealer or Toro Customer Service and have the model
and serial numbers of your product ready. Figure 1
illustrates the location of the model and serial numbers
on the product.
Model No.
Serial No.
This manual identifies potential hazards and has safety
messages identified by the safety alert symbol (Figure 1),
which signals a hazard that may cause serious injury
or death if you do not follow the recommended
precautions.
1. Safety alert symbol.
This manual uses 2 other words to highlight information.
Important calls attention to special mechanical
information and Note emphasizes general information
worthy of special attention.
© 2011-The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Figure 1
Contents
Introduction................................................................. 2
Safety ........................................................................... 3
Setup ........................................................................... 4
1 Installing the Console Computer ........................ 4
2 Installing the Flowmeter .................................... 5
Product Overview ........................................................ 7
Controls ............................................................... 7
Operation..................................................................... 9
Initially Programming the Console
Computer......................................................... 9
Displaying Data.................................................. 11
Self-Testing the Console Computer..................... 11
Activating the Data Lock .................................... 11
Changing the Data Lock ..................................... 11
Entering the Mode Sequence with the Data
Lock Activated ............................................... 11
Setting the Power Down Delay Time ................... 12
Using the Console Computer Alarm ................... 12
Setting Up the System......................................... 12
Initially Field-testing the System.......................... 13
Maintenance............................................................... 14
Recommended Maintenance Schedule(s) ................ 14
Cleaning the Flowmeter...................................... 14
Programming the Console Computer.................. 14
Calibrating the Flowmeter .................................. 16
Testing the Flowmeter Cable............................... 16
Troubleshooting......................................................... 17
