- Page 1 Form No. 3350–449 Debris Blower 600 Model No. 44536—Serial No. 240000001 and Up Operator’s Manual English (EN)
-
Page 2: Table Of Contents
....... . Dealer or Toro Customer Service and have the model and serial numbers of your product ready. -
Page 3: Safety
To ensure optimum performance and safety, always purchase genuine Toro replacement parts and This product may exceed noise levels of 85 dB(A) at accessories to keep the machine all Toro. Never use the operator position. Ear protectors are recommended “will-fit” replacement parts and accessories made by for prolonged exposure to reduce the potential of other manufacturers. -
Page 4: Safety And Instruction Decals
Safety and Instruction Decals Safety decals and instructions are easily visible to the operator and are located near any area of potential danger. Replace any decal that is damaged or lost. 98-3110 1. Danger–See Operator’s 4. Always wear eye Manual protection 2. - Page 5 105–0707 105–0708 1. Danger–Blown object hazard–Keep bystanders away chute oullet. 105–0627 1. Danger 3. Read Operator’s Manual before performing any 2. Stop the engine and maintenance on machine remove the key from tractor ignition before leaving operator’s position. Disconnect PTO shaft.
-
Page 6: Specifications
Specifications General Specifications 7000 CFM + 200 CFM Fan Output 165 MPH + 20 MPH Fan Speed 1173 RPM + 20 RPM @ 540 PTO Input Outlet Area 100 square inches Deflector chute for 180 degree diversion as standard. Rotational control of gate just behind Directional Control 3–point hitch Caster Wheels... -
Page 7: Setup
Mount drive shaft blower and tractor Operator’s Manual Read before operating the machine. Parts Catalog Registration card Fill out and return to Toro. Note: Determine the left and right sides of the machine from the normal operating position. Ballast Requirements Caution... -
Page 8: Connecting The Upper Link
Adjusting the PTO Shaft Length Important A long PTO shaft is supplied with the machine to accommodate large variations in the tractor’s PTO and 3 point locations. For most tractors this shaft is too long and must be cut to the correct length or damage may result. -
Page 9: Connecting The Pto Shaft
8. Remove all debris from the tube sections. Adjusting the Sway Links 9. Grease the steel tubes liberally. Adjust the sway links on the lower draft arms of the 3-point hitch to minimize side-to-side sway to a maximum of 10. Assemble the PTO shaft and secure it to the blower and 1 inch (25 mm) on each side. -
Page 10: Removing The Blower From The Tractor
the full lift range can be used as long as the PTO tubes do Before leaving the operator’s seat on the tractor, wait for not slide apart. Operating the PTO in the fully raised the engine and all moving parts to stop. position may damage the PTO or other components. -
Page 11: Operation
Operation Adjusting Discharge Direction The direction of the discharge opening can be changed Note: Determine the left and right sides of the machine from the side to the front by moving the control handle from the normal operating position. (Fig. 8). Operating Tips Warning Discharged air has considerable force and could... -
Page 12: Maintenance
Maintenance Note: Determine the left and right sides of the machine from the normal operating position. Greasing the Blower Fan Shaft Bearings The (2) fan shaft bearings (Fig. 9) must be lubricated after every 8 hours of operation with a No. 2 Lithium-based grease. -
Page 13: Adjusting The Blower Belt
Adjusting the Blower Belt Make sure belt is properly tensioned to ensure proper operation of the machine and unnecessary wear. Check belt frequently. Note: Check/adjust the blower belt tension after the first 20 hours of operation. 1. Remove the capscrews, washers and nuts securing the belt guard to the blower housing (Fig. -
Page 14: Troubleshooting
Troubleshooting Problem Possible Causes Corrective Action There is excessive vibration. 1. The bearing(s) on the fan shaft 1. Replace the bearings. is damaged. 2. Material is built up on the fan 2. Clean out any build up on the blades. inside of the housing. -
Page 15: Storage
Storage 1. Thoroughly clean the blower. The fan housing should be free of dirt, leaves, and debris. 2. Lubricate all grease fittings. Wipe off any excess lubricant. 3. Place a light coat of grease on the splines of the PTO shaft. -
Page 16: The Toro General Commercial Products Warranty
If for any reason you are dissatisfied with your Distributor’s service or have difficulty obtaining guarantee information, contact the Toro importer. If all other remedies fail, you may contact us at Toro Warranty Company.
