  • Page 1 Artisan Technology Group is your source new and certified-used/pre-owned equip SERVICE CENTER REPAIRS WE BUY USED E • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell your exce at our full-service, in-house repair center We also offer •...
  • Page 2 PCM-3375 VIA Mark SBC with CFC, USB, LAN, LPT, COM, PC/104 CPU User Manual...
  • Page 3 ESS is a trademark of ESS Technology, Inc. Creative is a trademark of Creative Technology LTD. All other product names or trademarks are properties of their respective owners. For more information on this and other Advantech products, please visit our websites at: http://www.advantech.com http://www.advantech.com/eplatform For technical support and service, please visit our support website at: http://www.advantech.com/support...
  • Page 4 Packing List Before you begin installing your card, please make sure that the following materials have been shipped: • 1 PCM-3375 all-in-one single board computer • 1 CD disk for utility and drivers • 1 startup manual • 1 PS/2 Keyboard & Mouse cable (p/n: 1700060202) •...
  • Page 5 There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the manufacturer. Discard used batter- ies according to the manufacturer’s instructions. Achtung! PCM-3375 User Manual...
  • Page 6 Additional Information and Assistance 1. Visit the Advantech web site at www.advantech.com where you can find the latest information about the product. 2. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
  • Page 7 PCM-3375 User Manual...

  • Page 8: Table Of Contents

    Contents Chapter 1 General Information ........2 Introduction ............... 2 Features ................2 Specifications ..............2 Board layout: dimensions..........4 Figure 1.1:Board layout: dimension (component side) .. 4 Figure 1.2:Board layout: dimension (solder side) ..5 Chapter 2 Installation ............8 Jumpers................8 Table 2.1:Jumpers............
  • Page 9 5.2.2 Installation for Windows 2000 ........62 Further information ............67 Appendix A Programming Watchdog Timer....70 Watchdog programming..........70 Appendix B Pin Assignments ..........72 LAN Connector (CN1) ..........72 Table B.1: LAN Connector (CN1) ....... 72 PCM-3375 User Manual viii...
  • Page 10 USB 1/2 Connector (CN2) ......... 72 Table B.2: USB 1/2 Connector (CN2)......72 FPD Connector (TTL) (CN3) ........73 Table B.3:FPD Connector (TTL) (CN3) ...... 73 LCD Signal Mapping ............74 RS422/485 Connector (CN4) .......... 75 Table B.5:RS422/485 Connector (CN4)....... 75 COM1 RS232 Connector (CN5) .........
  • Page 11 Appendix D Mechanical Drawings........90 Mechanical Drawings............90 Figure D.1:PCM-3375 Mech Drawing (component side) Figure D.2:PCM-3375 Mech Drawing (solder side) ..90 PCM-3375 User Manual...
  • Page 12 General Information This chapter gives background information on PCM-3375. Sections include: • Introduction • Features • Specifications • Board layout and dimensions Chapter 1...

  • Page 13: Chapter 1 General Information

    KB/MS, 2 x USB 1.1, also supports up to 512MB SDRAM, 1 x 24bit TTL LCD panel and 2 channel 18-bit LVDS, CRT display function and ISA interface. PCM-3375 is a cost effective choice for customers. With a similar I/O layout as PCM-3350, PCM-3375 will be the best choice to replace PCM- 3350.
  • Page 14 • Parallel port: One parallel port, supports SPP/EPP/ECP mode • Keyboard/mouse connector: Wafer Box 6pin connector • Power management: APM 1.2 compliant • Watchdog timer: 62-level timer intervals • USB: Two USB 1.1 compliant host ports • Expansion: Supports PC/104 ISA module connector Solid State Disk •...

  • Page 15: Board Layout: Dimensions

    1.4 Board layout: dimensions Figure 1.1: Board layout: dimension (component side) PCM-3375 User Manual...
  • Page 16 Figure 1.2: Board layout: dimension (solder side) Chapter 1...
  • Page 17 PCM-3375 User Manual...
  • Page 18 Installation This chapter explains the setup proce- dures of PCM-3375 hardware, includ- ing instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all safety precautions before you begin the instal- lation procedure. Chapter 2 Installation...

  • Page 19: Chapter 2 Installation

    Chapter 2 Installation 2.1 Jumpers The PCM-3375 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers. Table 2.1: Jumpers Label Function Clear CMOS LVDS Panel Power Select 2.2 Connectors...
  • Page 20 Table 2.2: Connectors CN16 Multi-function Connector CN17 FDD Connector CN18 CFC Connector CN19 Memory Connector CN20 Battery Connector Chapter 2 Installation...

  • Page 21: Locating Connectors

    2.3 Locating Connectors Figure 2.1: Jumper & Connector (component side) Figure 2.2: Jumper & Connector (solder side) PCM-3375 User Manual...

  • Page 22: Setting Jumpers

    2.4 Setting Jumpers You may configure your card to match the needs of your application by setting jumpers. A jumper is a metal bridge used to close an electric cir- cuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 23: Ide, Cdrom Hard Drive Connector (Cn7)

    2.6 IDE, CDROM hard drive connector (CN7) The PCM-3375 provides 1 IDE channels which you can attach up to two Enhanced Integrated Device Electronics hard disk drives or CDROM to the PCM-3375’s internal controller. The PCM-3375's IDE controller uses a PCI interface.

  • Page 24: Solid State Disk

    2.7 Solid State Disk The PCM-3375 provides a CompactFlash card socket for Solid state disk solutions. 2.7.1 CompactFlash (CN18) The CompactFlash card shares a secondary IDE channel which can be enabled/disabled via the BIOS settings. 2.8 Keyboard and PS/2 mouse connector (CN14) The PCM-3375 board provides a keyboard connector that supports both a keyboard and a PS/2 style mouse.

  • Page 25: Crt Display Connector (Cn10)

    The PCM-3375 uses the VIA Mark CoreFusion processor that supports single- or dual-channel LVDS panel up to SXGA panel resolution with frequency range from 25 MHz to 112 MHz. The PCM-3375 supports sin- gle or dual-channel LVDS panels up to UXGA panel resolution with fre- quency range from 25MHz to 112MHz.
  • Page 26 Chapter 3 Ducks that Need Love! Award BIOS Setup This chapter describes how to set BIOS configuration data.

  • Page 27: Chapter 3 Award Bios Setup

    The CMOS memory has lost power and the configuration informa- tion has been erased. The PCM-3375 Series' CMOS memory has an integral lithium battery backup. The battery backup should last ten years in normal service, but when it finally runs down, you will need to replace the complete unit.

  • Page 28: Award Bios Setup

    3.2 Award BIOS setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. 3.2.1 Entering setup Power on the computer and press <Del>...

  • Page 29: Standard Cmos Features Setup

    Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive and display. Once a field is high- lighted, on-line help information is displayed in the left bottom of the Menu screen. Figure 3.2: CMOS Features setup PCM-3375 User Manual...

  • Page 30: Advanced Bios Features Setup

    3.2.3 Advanced BIOS Features setup By choosing the Advanced BIOS Features Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-3375 Series. Figure 3.3: Advanced BIOS Features setup...

  • Page 31: Advanced Chipset Features Setup

    3.2.4 Advanced Chipset Features setup By choosing the Advanced Chipset Features option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-3375 Series. Figure 3.4: Advanced Chipset Features setup PCM-3375 User Manual...

  • Page 32: Integrated Peripherals

    3.2.5 Integrated Peripherals Choosing the Integrated Peripherals option from the Initial Setup Screen menu should produce the screen below. Here we see the manufacturer’s default values for the PCM-3375 Series. Figure 3.5: Integrated Peripherals...

  • Page 33: Power Management Setup

    3.2.6 Power Management Setup By choosing the Power Management Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-3375 Series. Figure 3.6: Power Management Setup PCM-3375 User Manual...

  • Page 34: Pnp/Pci Configurations

    3.2.7 PnP/PCI Configurations By choosing the PnP/PCI Configurations option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-3375 Series. Figure 3.7: PnP/PCI Configurations...

  • Page 35: Load Optimized Defaults

    Load Optimized Defaults loads the default system values directly from ROM. If the stored record created by the Setup program should ever become corrupted (and therefore unusable), these defaults will load auto- matically when you turn the PCM-3375 Series system on. 3.2.9 Set Password Note...
  • Page 36 Select Save to CMOS and EXIT, type <Y>, then <Enter>. Figure 3.8: To Establish Password To Change Password Choose the Set Password option from the CMOS Setup Utility main menu and press <Enter>. When you see “Enter Password,” enter the existing password and press <Enter>.

  • Page 37: Save & Exit Setup

    This record is required for the system to operate. 3.2.11 Exit Without Saving Selecting this option and pressing <Enter> lets you exit the Setup pro- gram without recording any new values or changing old ones. Figure 3.9: Exit Without Saving PCM-3375 User Manual...
  • Page 38 3375 AGP 4X Setup The PCM-3375 features an onboard AGP 4X flat panel/VGA interface. This chapter provides instructions for installing and operating the software drivers on the included display driver diskette.

  • Page 39: Chapter 4 Agp 4X Setup

    Chapter 4 AGP 4X Setup 4.1 Introduction The PCM-3375 has an onboard AGP flat panel/VGA interface. The spec- ifications and features are described as follows: 4.1.1 Chipset The PCM-3375 uses a VIA Twister 8606T chipset from VIA Technology Inc. for its AGP/SVGA controller. It supports many popular LCD, and LVDS LCD displays and conventional analog CRT monitors.
  • Page 40 Step 3. Click “OK”. Figure 4.1: Selecting Display Settings Chapter 4...

  • Page 41: Installation Of The Svga Driver

    4.2 Installation of the SVGA Driver Complete the following steps to install the SVGA driver. Follow the pro- cedures in the flow chart that apply to the operating system that you are using within your PCM-3375. Notes: 1. The windows illustrations in this chapter are intended as examples only.
  • Page 42 Choose the "Adapter" tab, then press the "Change..." button. Press the "Have Disk" button. Chapter 4...
  • Page 43 Type in the path: D:\vga\VT8606\Win9x_Me Select the highlighted item, and click the "OK" button. PCM-3375 User Manual...
  • Page 44 "S3 GraphicsTwister" appears under the adapter tab. Click the "Apply" button, then the "OK" button. Press “Yes” to reboot. Chapter 4...

  • Page 45: Installation For Windows 98/Me

    4.2.2 Installation for Windows 98/Me Select "Start", "Settings", "Control Panel", "Display", and "Set- tings," then press the "Advanced" button. PCM-3375 User Manual...
  • Page 46 Select “Adapter,” then “Change.” Chapter 4...
  • Page 47 Press “Next,” then “Display a list..” Press the “Have disk...” button. PCM-3375 User Manual...
  • Page 48 Insert the CD into the CD-ROM drive. Type in the path D:\vga\VT8606\Win9x_Me Then press “OK” Select the highlighted item, then click “OK.” Chapter 4...
  • Page 49 "S3 Graphics Twister"appears under the adapter tab. Click the "Apply" button. Press “Yes” to reboot. PCM-3375 User Manual...

  • Page 50: Installation For Windows Nt

    4.2.3 Installation for Windows NT Note: Service Pack X (X = 3, 4, 5, 6,...) must be installed first, before you install the Windows NT VGA driver. Select "Start", "Settings", "Control Panel" and double click the "Display" icon. Chapter 4...
  • Page 51 Choose the "Settings" tab, and press the "Display Type" button. PCM-3375 User Manual...
  • Page 52 Press the "Change..." button. Chapter 4...
  • Page 53 Click the "Have Disk..." button. Type the path: D:\vga\VT8606\Win NT Press the "OK" button. PCM-3375 User Manual...
  • Page 54 Select the highlighted item, and click the "OK" button. Press "Yes" to proceed. Press "OK" to reboot. Chapter 4...

  • Page 55: Installation For Windows 2000

    4.2.4 Installation for Windows 2000 Select "System", "Settings", "Control Panel" and double click the "system" icon. PCM-3375 User Manual...
  • Page 56 Choose the "Video Controller (VGA Compatible)” button. Chapter 4...
  • Page 57 Choose the "Drive" button, press “Update Driver...” button. PCM-3375 User Manual...
  • Page 58 Choose "Display a list of..." , then press “Next” button. Choose “Display adapters”, press “Next” button. Chapter 4...
  • Page 59 Click the “Have Disk” button. Type the path D:\vga\VT8606\Win2000 press the “OK” button. PCM-3375 User Manual...

  • Page 60: Installation For Windows Xp

    Press “Finish" to reboot. 4.2.5 Installation for Windows XP Select "System", "Settings", "Control Panel" and double click the "system" icon. Chapter 4...
  • Page 61 Choose “Hardware” and “Device Manager”, press “OK” button. PCM-3375 User Manual...
  • Page 62 Choose “Video Controller (VGA Compatible), press “OK” button. Chapter 4...
  • Page 63 Choose "Driver”, “Update Driver”, press “OK” button. Choose “Install from a list..” , press “Next”. PCM-3375 User Manual...
  • Page 64 Choose “Don’t search. I will..”, press “Next” button. Choose “Display adapters”, press “Next” button. Chapter 4...
  • Page 65 Type the path D:\vga\VT8606\WinXP then press “OK” button. Choose “S3 Graphics Twister + S3 Hotkey” then press “Next” but- ton. PCM-3375 User Manual...

  • Page 66: Further Information

    Press “Finish" to reboot. 4.3 Further Information For further information about the AGP/VGA installation in your PCM- 3375, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: VIA website: www.via.com.tw Advantech websites: www.advantech.com www.advantech.com.tw Chapter 4...
  • Page 67 PCM-3375 User Manual...
  • Page 68 Ethernet Interface This chapter provides information on Ethernet configuration. Sections include: • Introduction • Installation of Ethernet drivers for Windows 98/2000/NT • Further information...

  • Page 69: Chapter 5 Ethernet Interface

    5.2 Installation of the Ethernet driver Before installing the Ethernet driver, note the procedures below. You must know which operating system you are using in your PCM-3375 Series, and then refer to the corresponding installation flow chart. Then just follow the steps described in the flow chart. You will quickly and successfully complete the installation, even if you are not familiar with instructions for MS-DOS or Windows.
  • Page 70 b. Double click "Network". a. Click "Add New Hardware" and prepare to install network func- tions. Chapter 5...
  • Page 71 Select the "Adapter" item to add the Ethernet card. a. Click "Have Disk" to install the driver. a. Insert the CD into the D: drive b. Fill in "E:\3_LAN\82551ER\W9X&W2K” c. Click "OK" PCM-3375 User Manual...
  • Page 72 a. Choose the " Choose the "Intel(R) GD82559ER PCI Adapter" item. b. Click "Next". a. Make sure the configurations of relative items are set correctly. b. Click "Finish" to reboot. Chapter 5...

  • Page 73: Installation For Windows 2000

    5.2.2 Installation for Windows 2000 a. Select "Start", "Settings". "Control Panel". b. Double click "Network". PCM-3375 User Manual...
  • Page 74 Click “Add new hardware wizard” and prepare to install network function Chapter 5...
  • Page 75 Choose Hardware Device “Ethernet Controller” PCM-3375 User Manual...
  • Page 76 Insert the CD into D: drive a. Fill in the Find the LAN chipset folder at the directory of PCM-3375 win2000 folder from CD ROM drive b. Click “OK”. Choose the "Intel(R) GD82559ER PCI Adapter" item Chapter 5...
  • Page 77 Click “Next” a. Make sure the configurations of relative items are set correctly PCM-3375 User Manual...

  • Page 78: Further Information

    Click “OK” 5.3 Further information Intel website: www.intel.com Advantech websites:www.advantech.com www.advantech.com.tw Chapter 5...
  • Page 79 PCM-3375 User Manual...
  • Page 80 Programming the Watchdog Timer The PCM-3375 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.

  • Page 81: Appendix A Programming Watchdog Timer

    ; Initial Watchdog by output 0AAh to Watchdog I/O port 440h two times OUT DX , AL OUT DX , AL OUT DX , 0xh ; Set 0xh as the Watchdog time period ; Set 00h to disable Watchdog ==================================================== PCM-3375 User Manual...
  • Page 82 Pin Assignments This appendix provides specialized information regarding: • LAN Connector • USB 1/2 Connector • FPD Connector (TTL) • RS422/485 Connector (share with COM2) • COM1 RS232 Connector • FPD Connector (LVDS) • Primary IDE Connector • COM2 RS232 Connector •...

  • Page 83: Appendix B Pin Assignments

    Appendix B Pin Assignments B.1 LAN Connector (CN1) Table B.1: LAN Connector (CN1) Signal Signal VCC_LAN ACT_LED LINK_LED TEMPLANE RTEMPLANE B.2 USB 1/2 Connector (CN2) Table B.2: USB 1/2 Connector (CN2) Signal Signal VCC_USB1 VCC_USB2 USB1N USB2N USB1P USB2P PCM-3375 User Manual...

  • Page 84: Fpd Connector (Ttl) (Cn3)

    B.3 FPD Connector (TTL) (CN3) Table B.3: FPD Connector (TTL) (CN3) Signal Signal VCC_LCD VCC_LCD VCC3_LCD VCC3_LCD FP_z_D0 FP_z_D1 FP_z_D2 FP_z_D3 FP_z_D4 FP_z_D5 FP_z_D6 FP_z_D7 FP_z_D8 FP_z_D9 FP_z_D10 FP_z_D11 FP_z_D12 FP_z_D13 FP_z_D14 FP_z_D15 FP_z_D16 FP_z_D17 FP_z_D18 FP_z_D19 FP_z_D20 FP_z_D21 FP_z_D22 FP_z_D23 FP_z_CLK FP_z_VS...

  • Page 85: Lcd Signal Mapping

    B.4 LCD Signal Mapping Table B.4: LCD Signal Mapping Pin Name 16-bit DSTN 24-bit DSTN 18-bit TFT 24-bit TFT PD10 PD11 PD12 PD13 PD14 PD15 PD16 PD17 PD18 PD19 PD20 PD21 PD22 PD23 PCM-3375 User Manual...

  • Page 86: Rs422/485 Connector (Cn4)

    B.5 RS422/485 Connector (CN4) Table B.5: RS422/485 Connector (CN4) Signal RXD485- RXD485+ TXD485+ TXD485- B.6 COM1 RS232 Connector (CN5) Table B.6: COM1 RS232 Connector (CN5) Signal Signal DCDA# DSRA# RTSA# CTSA# DTRA# RIA# #: Low Active Appendix B...

  • Page 87: Fpd Connector (Lvds) (Cn6)

    B.7 FPD Connector (LVDS) (CN6) Table B.7: FPD Connector (LVDS)(CN6) Signal Signal LVDS0_D0+ LVDS1_D0+ LVDS0_D0- LVDS1_D0- LVDS0_D1+ LVDS1_D1+ LVDS0_D1- LVDS1_D1- LVDS0_D2+ LVDS1_D2+ LVDS0_D2- LVDS1_D2- LVDS0_CLK+ LVDS1_CLK+ LVDS0_CLK- LVDS1_CLK- VCC_LVDS VCC_LVDS PCM-3375 User Manual...

  • Page 88: Primary Ide Connector (Cn7)

    B.8 Primary IDE Connector (CN7) Table B.8: Primary IDE Connector (CN7) Signal Signal PIDERS# PDD7 PDD8 PDD6 PDD9 PDD5 PDD10 PDD4 PDD11 PDD3 PDD12 PDD2 PDD13 PDD1 PDD14 PDD0 PDD15 PDDREQX PDIOWX# PDIORX# PDRDYX PDDACKX# IIRQ14 PDA1 PDA0 PDA2 CS0P# CS1P# PIDEACT# #: Low Active...

  • Page 89: Com2 Rs232 Connector (Cn8)

    Table B.9: COM2 RS232 Connector (CN8) Signal Signal DCDB# DSRB# RTSB# CTSB# DTRB# RIB# #: Low Active B.10 VGA Connector (CN10) 14 16 13 15 Table B.10: VGA Connector (CN10) Signal Signal VGA_z_R VCC_VGA VGA_z_G VGA_z_B VGA_v_DDAT VGA_v_HS VGA_v_VS VGA_v_DCLK PCM-3375 User Manual...

  • Page 90: Lpt Connector (Cn11)

    B.11 LPT Connector (CN11) Table B.11: LPT Connector (CN11) Signal Signal STB_O PRN_AFD# LPD0_O PRN_ERR# LPD1_O PRN_INIT# LPD2_O PRN_SLIN# LPD3_O LPD4_O LPD5_O LPD6_O LPD7_O PRN_ACK# PRN_BUSY PRN_PE #: Low Active B.12 Power input Connector (CN12) Table B.12: Power input Connector (CN12) Signal +12V Appendix B...

  • Page 91: Sm-Bus Connector (Cn13)

    B.13 SM-BUS Connector (CN13) Table B.13: SM-BUS Connector (CN13) Signal SMB_DATA SMB_CLK VCC3 B.14 KB_MS Connector (CN14) Table B.14: KB_MS Connector (CN14) Signal VCCKB B.15 System FAN Connector (CN15) Table B.15: System FAN Connector (CN15) Signal FANSPEED PCM-3375 User Manual...

  • Page 92: Multi-Function Connector (Cn16)

    B.16 Multi-function Connector (CN16) Table B.16: Multi-function Connector (CN16) Signal Function V-5V Negative Power Negative Power V-12V Negative Power SWIN_RST# Reset Reset WDG_OUT# SWIN_RST# IrDA IRRX IrDA IrDA IrDA V12_INVERTER LCD Inverter LCD Inverter ENABLE LCD Inverter LCD Inverter LCD Inverter DIO0 DIO1 DIO2...

  • Page 93: Fdd Connector (Cn17)

    B.17 FDD Connector (CN17) Table B.17: FDD Connector (CN17) Signal Signal INDEX# DSA# DSKCHG# MOA# DIR# STEP# TRACK0# RDATA# HEAD# #: Low Active PCM-3375 User Manual...

  • Page 94: Compactflash Connector (Cn18)

    B.18 CompactFlash Connector (CN18) Table B.18: CompactFlash Connector (CN18) Signal Signal SDD3 SDD11 SDD4 SDD12 SDD5 SDD13 SDD6 SDD14 SDD7 SDD15 SDCS1# SDCS3# SDIOR# SDIOW# IIRQ15 SIDERST# SDRDY SDA2 SDDREQ SDA1 SDDACK# SDA0 SDDACT# SDD0 PDIAG# SDD1 SDD8 SDD2 SDD9 SDD10 #: Low Active Appendix B...

  • Page 95: Battery Connector (Cn20)

    B.19 Battery Connector (CN20) Table B.19: Battery Connector (CN20) Signal VBAT PCM-3375 User Manual...
  • Page 96 System Assignments This Appendix contains information about: • System I/O ports • 1st MB memory map • DMA channel assignments • Interrupt assignments Appendix C...

  • Page 97: Appendix C System Assignments

    3C0-3CF Reserved 3D0-3DF Color/graphics monitor adapter 3E8-3EF Series port 3 3F0-3F7 Diskette controller 3F8-3FF Serial port 1 * PNP audio I/O map range from 220 ~ 250H (16 bytes) MPU-401 select from 300 ~ 330H (2 bytes) PCM-3375 User Manual...

  • Page 98: 1St Mb Memory Map

    C.2 1st MB memory map Table C.2: 1st MB memory map Addr. range (Hex) Device F0000h - FFFFFh System ROM *CC000h - EFFFFh Unused (reserved for Ethernet ROM) C0000h - CBFFFh Expansion ROM (for VGA BIOS) B8000h - BFFFFh CGA/EGA/VGA text B0000h - B7FFFh Unused A0000h - AFFFFh...

  • Page 99: Interrupt Assignments

    IRQ 15 Secondary IDE for CFC * Ethernet interface IRQ select: 9, 11, 15 * PNP audio IRQ select: 9, 11, 15 * PNP USB IRQ select: 9, 11, 15 * PNP ACPI IRQ select: 9, 11, 15 PCM-3375 User Manual...
  • Page 100 Mechanical Drawings Appendix D...
  • Page 101 Appendix D Mechanical Drawings D.1 Mechanical Drawings Figure D.1: PCM-3375 Mech Drawing (component side) Figure D.2: PCM-3375 Mech Drawing (solder side) PCM-3375 User Manual...
  • Page 102 Artisan Technology Group is your source new and certified-used/pre-owned equip SERVICE CENTER REPAIRS WE BUY USED E • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell your exce at our full-service, in-house repair center We also offer •...
