PCM-3355 PC/104 SBC w/AMD LX800/LX600, VGA,
LCD, LAN, USB 2.0 , SATA, and CF
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following materials have been shipped:
1 x PCM-3355 SBC
1 x SATA cable
1 x Keyboard/Mouse cable
1 x Y cable for KB/MS extension
1 x Ethernet RJ-45 Conn.
conversion cable
1 x LPT port cable
1 x VGA cable
1 x USB cable (bracket type
with two USB ports)
1 x RS-422/485 COM cable
1 x RS-232 COM cable
1 x Startup manual
1 x CD-ROM (Manual, Driver, Utility)
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1:
Acrobat Reader is required to view PDF files.
Acrobat Reader can be downloaded at: www.
adobe.com/Prodindex/acrobat/read-step.html
(Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://service.advantech.com/support
This manual is for the PCM-3355 Series Rev. A1.
Part No. 2006335500
Printed in China
(p/n: 1700008894)
(p/n: 1703060053)
(p/n: 1700060202)
(p/n: 1700005158)
(p/n: 1700260250)
(p/n: 1701160150)
(p/n: 1703100121)
(p/n: 1703040157)
(p/n: 1701200220)
1st Edition,
Jun. 2009
Specifications

Standard SBC functions

CPU: AMD Geode® LX800/LX600 processor, up to
500/366 MHz
System Memory: supports Double Data Rate (DDR)
DDR333 SDRAM up to 1GB
2nd Cache Memory: 128 KB on the processor
System Chipset: AMD Geode LX800/LX600
BIOS: AWARD 4Mbit Flash BIOS
Watchdog timer: 255 levels timer interval
Expansion Interface: PC/104 (ISA bus)
Battery: Lithium 3V/196 mAH
Power management: ACPI supported
Serial ATA: One Serial ATA interface, Speed up to 100
MB/s (Transfer from IDE)
Note:
We strongly suggest not using CF card and SATA
device together due to transmission rate bottle-
neck on ARC772, IDE to SATA bridge.
If you find your CF card cannot be detected when
using a SATA device at the same time, please
adjust CF card to Slave via SW2 and SATA to
Master via SW3; this will cause CF card and
SATA device to be detected together. Or you can
select a suitable CF card that Advantech has
confirmed compatible.
Serial ports: two serial RS-232 ports , one RS-422/485
ports
Parallel port: One parallel port, supports SPP/EPP/ECP
mode
Keyboard/mouse connector: Supports one standard
PC/AT keyboard and a PS/2 mouse
USB: Two USB 2.0 ports compliant universal serial bus
ports
CF: Solid State Disk (SSD) supports one 50-pin socket for
CFC type I (type II optional)
VGA/TTL Interface
Chipset: AMD Geode LX800/LX600
Memory Size: Optimized Shared Memory Architecture,
supports 64 MB frame buffer using system memory
CRT resolutions supported:
- Supports up to 1920x1440x32 bpp at 85 Hz
- Supports up to 1600x1200x32 bpp at 100 Hz
TFT resolutions supported: Supports up to 1024 x 768
x 32 bpp at 60 Hz
LCD Interface: Supports up to 24-bit TFT LCD (TTL
signal)
Dual Simultaneous Display: CRT + LCD

Ethernet Interface

Chipset supports: 1 x 10/100 Mbps - Intel 82551QM
Interface: 1 x internal box header
Standard IEEE 802.3u (100 Mbps) protocol compatible
