Access & Power Integration
TMV2
- Altronix/Mercury/HID VertX
Installation Guide
TMV2 accommodates a variety of Mercury/HID VertX
twelve (12) doors.
• 16 Gauge backplane.
Dimensions (H x W x D): 23.75" x 18.125" x 0.3125" (603.3mm x 460.3mm x 7.9mm).
• Up to three (3) ACM4(CB), MOM5, PD4UL(CB), PD8UL(CB), PDS8(CB), VR6, GB1 (Genetec Synergis Cloud Link adapter plate).
• Up to six (6) Mercury EP1502, MR52, MR16IN, MR16OUT, EP2500, MUX8.
• Up to six (6) Vertx
®
V100, V200, V300, V1000, V2000.
Snap on Standoff
TMV2 - Altronix / Mercury / HID VertX Door Backplane
®
door backplane for Trove2 and Trove3

Backplane Accommodates a Combination of the Following:

Nylon Standoff

Overview:

®
boards with or without Altronix sub-assemblies for access systems of up to

Specifications:

Hardware:

7/8" Pan Head Screw
TMV2_Rev. 110217
SIGNALING
Lock Nut
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Trove TMV2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Altronix Trove TMV2

Summary of Contents for Altronix Trove TMV2

  • Page 1 Installation Guide Overview: TMV2 accommodates a variety of Mercury/HID VertX ® boards with or without Altronix sub-assemblies for access systems of up to twelve (12) doors. Specifications: • 16 Gauge backplane. Dimensions (H x W x D): 23.75” x 18.125” x 0.3125” (603.3mm x 460.3mm x 7.9mm).
  • Page 2 Altronix Sub-Assemblies and/or Adapters: Fasten nylon / snap on standoffs to pems which match the hole pattern for Altronix Sub-Assemblies (Fig. 1, 1a, pg. 2). Mount boards to standoffs utilizing pan head screws provided with the product or by depressing board onto snap on standoff (Fig.
  • Page 3 Altronix Sub-Assemblies and/or Adapters: 1. Fasten nylon / snap on standoffs to pems which match the hole pattern for Altronix Sub-Assemblies (Fig. 1, 1a, pg. 2). 2. Mount boards to standoffs utilizing pan head screws provided with the product or by depressing board onto snap on standoff (Fig.
  • Page 4 13.7” (350mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Made in U.S.A. IITMV2 A16S MEMBER - 4 -...
