Access & Power Integration
Trove2Z2
- Trove2 enclosure with Altronix/ZKTeco backplane (TZ2)
TZ2
- Altronix/ZKTeco backplane only
Installation Guide
All registered trademarks are property of their respective owners.
Trove2Z2/TZ2_Rev. 013118
Installing Company: _____________________ Service Rep. Name: __________________________________________
Address: ________________________________________________________ Phone #: _________________________
Trove2Z2/TZ2_Rev. 013118
More than just power.™
Advertisement
Table of Contents
Related Manuals for Altronix Trove2Z2
Summary of Contents for Altronix Trove2Z2
-
Page 1: Installation Guide
Trove2Z2/TZ2_Rev. 013118 Access & Power Integration Trove2Z2 - Trove2 enclosure with Altronix/ZKTeco backplane (TZ2) - Altronix/ZKTeco backplane only Installation Guide More than just power.™ All registered trademarks are property of their respective owners. Trove2Z2/TZ2_Rev. 013118 Installing Company: _____________________ Service Rep. Name: __________________________________________... -
Page 2: Specifications
Overview: Trove2Z2 accommodates various combinations of ZKTeco door controllers with or without Altronix power supplies and accessories for access control systems. Specifications: Trove2Z2 • Includes: tamper switch, cam lock, board mounting hardware. • 16 Gauge. • 16 Gauge grey enclosure with ample knockouts for convenient access. - Page 3 Installation Instructions for Altronix Power Supplies and/or Sub-Assemblies to TZ2: 1. Fasten standoffs (included) to pems that match the hole pattern for Altronix Power Supply/Chargers or Altronix Sub-Assembly boards (Fig. 2, pg. 3). Fasten metal standoffs in the correct locations to provide proper grounding, see below (Fig. 2, pg. 3).
- Page 4 1. Fasten DIN Rail (provided by ZKTeco) to pem standoffs, utilizing 5/16” pan head screws (included) (Fig. 3, pg. 4). 2. Mount ZKTeco modules to DIN Rail (refer to below chart for model number, Fig. 3, pg. 4). 3. Fasten TZ2 backplane to Trove2 enclosure utilizing lock nuts (provided by Altronix). Pem Mounting Altronix Model...
- Page 5 2. Mount ZKTeco boards to standoffs utilizing 5/16” pan head screws (included) (refer to below chart for model number, Fig. 4, pg. 5). 3. Fasten TZ2 backplane to Trove2 enclosure utilizing lock nuts (included). Pem Mounting Altronix Model SMB/Pro Series C3 400 SMB/Pro Series C3 100/200 Fig. 4 - Trove2Z2/TZ2 Configurations Fig. 4a Standoff ZKTeco C3 100/200/400...
- Page 6 - UL Listed in the U.S. and Canada. - Local or remote control of up to (2) two Altronix eFlow power output(s) via LAN and/or WAN. - Monitor real time diagnostics: DC output voltage, output current, AC & battery status/service, input trigger state change, output state change and unit temperature.
- Page 7 25.375” x 19.375” x 0.325” (644.5mm x 482.6mm x 8.3mm) 19.375” (482.6mm) 7.5” 7.5” (190.5mm) (190.5mm) 0.156” ( 3.96mm) 25.375” (644.5mm) 12.62” (320.6mm) 1.0” (25.4mm) 0.45” 1.0” (11.4mm) (25.4mm) 7.5” 7.5” (190.5mm) (190.5mm) 9.2” (233.7mm) Trove2Z2 / TZ2 - 7 -...
- Page 8 (133.35mm) (50.8mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Made in U.S.A. MEMBER IITrove2Z2 I10R - 8 -...
