eFlowRLBV Series
Sub-Assembly
Power Supply/Charger Boards
with LED Cable Assembly
Models Include:
eFlow4RLBV
- 12 or 24VDC @ 4A
eFlow6RLBV
- 12 or 24VDC @ 6A
Installation Guide
Rev. EFRLBV-022624
eFlow102RLBV
- 12VDC @ 10A
eFlow104RLBV
- 24VDC @ 10A
More than just power.
TM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Altronix eFlowRLBV Series
Summary of Contents for Altronix eFlowRLBV Series
- Page 1 Series Sub-Assembly Power Supply/Charger Boards with LED Cable Assembly Models Include: eFlow4RLBV eFlow102RLBV - 12 or 24VDC @ 4A - 12VDC @ 10A eFlow6RLBV eFlow104RLBV - 12 or 24VDC @ 6A - 24VDC @ 10A Installation Guide More than just power.
- Page 2 Overview: Altronix eFlow power supply/chargers convert a 220VAC, 50/60Hz input to a 12VDC or 24VDC output. Specifications: Altronix Input Rating Aux. Power-Limited Maximum Output Voltage (Current) Model 220VAC Output Charge 12VDC 24VDC Number 50/60Hz (unswitched) Current eFlow4RLBV 2.1A 1.54A eFlow6RLBV 2.1A...
- Page 3 Stand-by Specifications: eFlow4RLBV: Burg. Applications Fire Applications Access Control Battery 4 hr. Stand-by/15 min. Alarm 24 hr. Stand-by/5 min. Alarm Applications Stand-by 0.4A/4A – 15 Mins./4A 12AH 1A/4A 0.3A/4A 35 Mins./4A 40AH 4A/4A 1.2A/4A Over 4 Hours/4A 65AH 4A/4A 1.5A/4A Over 4 Hours/4A eFlow6RLBV: Burg.
- Page 4 Installation Instructions: Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, the Canadian Electrical Code and with all local codes and authorities having jurisdiction. Product is intended for indoor use only. 1. Refer to Sub-Assembly Installation Instructions for mounting Rev. MS020119. 2.
- Page 5 Fig. 2 - LED Cable Harness Connection BAT FAIL AC DELAY SHUTDOWN 1 min. enable C NO 2 hr. disable White Lead Lead Wiring: Use 18 AWG or larger for all low voltage power connections. Note: Take care to keep power-limited circuits separate from non power-limited wiring (220VAC, Battery) Maintenance: Unit should be tested at least once a year for the proper operation as follows: Output Voltage Test:...
- Page 6 Terminal Identification: Terminal Function/Description Legend Connect 220VAC 50/60Hz to these terminals: L to hot, N to neutral, L, G, N G to ground (non power-limited) (Fig. 1a, pg. 4). eFlow4RLBV: 12VDC or 24VDC @ 4A continuous output (Power-Limited output). – DC + eFlow6RLBV: 12VDC or 24VDC @ 6A continuous output (Non Power-Limited output).
- Page 7 Notes: Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIeFlowRLBV B26X MEMBER eFlowRLBV Power Supply/Chargers Installation Guide...
- Page 8 - UL Listed in the U.S. and Canada. - Local or remote control of up to (2) two Altronix eFlow power output(s) via LAN and/or WAN. - Monitor real time diagnostics: DC output voltage, output current, AC & battery status/service, input trigger state change, output state change and unit temperature.
