Access & Power Integration
Altronix/Mercury Rack Kits
Models Include:
T2RM7F8SV
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2R enclosure with TM2R Altronix/Mercury backplane
- One (1) eFlow104RLBV - Power Supply/Charger
- One (1) ACMS8 - Dual Input Fused Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Module
T2RM7F8SQV
8 Door Networked Kit with Fused Outputs
Fully assembled kit includes:
- Trove2R enclosure with TM2R Altronix/Mercury backplane
- One (1) eFlow104RLBV - Power Supply/Charger
- One (1) LINQ8ACM - Dual Input Networked Fused
Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Module
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners
Rev. 111424
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T2RM7F8SDV
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2R enclosure with TM2R Altronix/Mercury backplane
- One (1) eFlow104RLBV - Power Supply/Charger
- One (1) ACMS8CB - Dual Input PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
T2RM7F8SDQV
8 Door Networked Kit with PTC Outputs
Fully assembled kit includes:
- Trove2R enclosure with TM2R Altronix/Mercury backplane
- One (1) eFlow104RLBV - Power Supply/Charger
- One (1) LINQ8ACMCB - Dual Input Networked PTC
Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
More than just power.™
Advertisement
Related Manuals for Altronix TROVE T2RM7F8SV
Summary of Contents for Altronix TROVE T2RM7F8SV
- Page 1 8 Door Kit with PTC Outputs Fully assembled kit includes: Fully assembled kit includes: - Trove2R enclosure with TM2R Altronix/Mercury backplane - Trove2R enclosure with TM2R Altronix/Mercury backplane - One (1) eFlow104RLBV - Power Supply/Charger - One (1) eFlow104RLBV - Power Supply/Charger...
-
Page 2: Configuration Chart
Overview: Altronix Trove Mercury rack kits are pre-assembled and consist of Trove enclosures/backplanes with factory installed Altronix power supply/charger and sub-assemblies. All kits accommodate a variety of Mercury modules for up to eight doors in a single enclosure. Configuration Chart:... -
Page 3: Hardware Included
Z Bracket Installation for Trove2R: Altronix Trove2R enclosure includes Z Bracket, a convenient and reliable wire management accessory. Fig. 3 Hardware (included): Twelve (12) bolts and eight (8) lock nuts. 1. Carefully unpack Z Bracket. Do not discard included hardware (Fig. - Page 4 Mercury Access Controller Position Chart for the Altronix Following Models: ACMS8(CB) Altronix/Mercury Pem Mounting LP1502, LP4502, MR52, MR16IN, MR16OUT Altronix VR6 is mounted LP2500, MUX8 under ACMS8(CB) Genetec Cloudlink To LED lense Altronix PDS8(CB) Fig. 6a Pan Head Screw...
- Page 5 Position Chart for the Following Models: Altronix Altronix/Mercury Pem Mounting Altronix eFlow104RLBV eFlow104NB LP1502, LP4502, MR52, MR16IN, MR16OUT Altronix VR6 is mounted LP2500, MUX8 under LINQ8ACM(CB) Genetec Cloudlink COM - R- GND GND + PS1 - + BAT - + PS2 -...
- Page 6 Notes: - 6 - T2RM V Kits Installation Guide...
- Page 7 Notes: T2RM V Kits Installation Guide - 7 -...
- Page 8 0.52” (13.2mm) 4.5” (114.3mm) 11.2” (284.5mm) Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
