OWNER'S MANUAL
24V UTV
this manual contains important safety
maintenance information
first ride or allowing your child to ride your new electric
-
.
ride
on toy
keep the manual handy for future reference
DO NOT RETURN THIS ITEM TO THE STORE
CONTACT DYNACRAFT CUSTOMER SERVICE FOR ASSISTANCE
FOR AGES 3+
MAXIMUM WEIGHT: TOTAL 130 lb (59 kg), 65 lb (29.5 kg) per seat
NOTE: Illustrations in this Manual are for reference purposes only and may not reflect the
exact appearance of the actual product. Specifications are subject to change without notice.
.
read the manual before taking your
dynacraftwheels.com/contact
or 1-800-551-0032 9
,
performance and
– 5
ET
AM
PM
.

Advertisement

Table of Contents
loading

Summary of Contents for Dynacraft Realtree

  • Page 1 DO NOT RETURN THIS ITEM TO THE STORE CONTACT DYNACRAFT CUSTOMER SERVICE FOR ASSISTANCE dynacraftwheels.com/contact or 1-800-551-0032 9 – 5 FOR AGES 3+ MAXIMUM WEIGHT: TOTAL 130 lb (59 kg), 65 lb (29.5 kg) per seat...
  • Page 2 TABLE OF CONTENTS A Introduction, Safety and Warnings B Before You Begin Assembly C Parts Diagram D Assembly E How to Use Your Ride-on Toy F Detailed Maintenance and Repair G Troubleshooting Guide H Limited Warranty SPECIFICATIONS SUITABLE AGE CAPACITY Up to 130 lb (59 kg) MAX SPEED Low 2 5 MPH / High 5 0 MPH...
  • Page 3 INTRODUCTION, SAFETY AND WARNINGS ABOUT THIS MANUAL: This Manual was written to help you and your child get the most performance, comfort, enjoyment and safety when riding your new electric ride-on toy. It is important for you to understand your new electric ride-on toy.
  • Page 4 RIDER USE AND REQUIRED PARENTAL SUPERVISION RIDERS MUST NOT EXCEED THE WEIGHT LIMIT OF 130 LB (59 KG) AND MUST BE OVER 3 YEARS OLD. NEVER ALLOW MORE THAN 2 CHILDREN TO RIDE THE RIDE-ON TOY SIMULTANEOUSLY. The age grade for the electric ride-on toy is for 3 years and older. Just because your child is within the age and weight limitations specified for the electric ride- on toy, does not mean that his/her size is appropriate to fit or maintain control of the electric ride-on toy, or that he/she is capable of safely operating the electric...
  • Page 5 SAFE RIDING PRACTICES AND WARNINGS • Check and obey all local laws or regulations which may be in effect in the locations where the electric ride-on toy may be used. • Always wear appropriate clothing and shoes. • Observe the age and weight limitations on the cover of this manual. •...
  • Page 6 • Do not to allow hands, feet, hair, body parts, clothing, or similar articles to come in contact with wheels or other moving parts. • Before each cycle of operation, you must perform the preoperation checks specified in this manual or by the manufacturer, including: –...
  • Page 7 BEFORE YOU BEGIN ASSEMBLY Remove all packing and items from the display box. NOTE: Parts are packaged at both ends of box and in ride-on chassis. Ensure all parts are present before assembly. ESTIMATED ASSEMBLY TIME Because this ride-on toy is heavy and large, we strongly suggest two people to complete assembly.
  • Page 8 PARTS DIAGRAM 1 Roof x1 14 Rear Axle x1 2 U shape Support x2 15 Battery x1 3 Roof Front Support x2 16 Cargo Bed (5 pcs) 4 Steering Wheel Assembly x1 17 Seat (2 pcs) 5 Cargo Basket x1 18 Roof Rear Support x2 6 Plastic Body Assembly x1 19 Charger x1...
  • Page 9 ASSEMBLY Your new ride-on toy requires adult assembly. Because your new ride-on toy is heavy and large, we strongly suggest using two people to finish assembly. Set aside around 60 minutes for assembly. Identify all parts before assembly and save all packaging material until assembly is completed to ensure that no parts are discarded.
  • Page 10 2. CARGO BED INSTALLATION • Align the cargo bed assembly with the four screw holes on the ride-on toy body. Use four M5x16 machine screws to tighten each corner securely. M5x16 mm Machine Screw M5x16 mm M5x16 mm Machine Screw Machine Screw Finished Status...
  • Page 11 3. FRONT WHEEL ASSEMBLY • Turn the ride-on toy body upside down (this should be handled carefully by two adults) • Cut the tie on the front axle with scissors. • Adjust the front wheel axle until the axle clicks into position to ensure that it is secure for safety (see Figure A).
  • Page 12 • Find a rear wheel marked with an “R” and Rear Wheel Axle Cap labeled “Rear”. Find the “R” marking at the Ø12 Split Pin Washer rear end of the ride-on toy body to match this wheel and slide the wheel onto the axle. •...
  • Page 13 5. STEERING WHEEL ASSEMBLY Steering Wheel • Gently turn the ride-on toy body upright. • Remove the M5x35 machine screw and nut Screwdriver M5 Nut from the steering wheel. • Insert the steering wheel onto the end of M5x35 the steering column, line up the hole in the Machine steering wheel and the hole in the steering Screw...
  • Page 14 7. ROOF ASSEMBLY U Shape 4x16 Round Support Head Screw • Find the roof and two U shape supports as shown. • The U shaped supports are marked with either an “L” or “R”. Find the "L" "R" corresponding “L” and “R” markings on the roof panel and then fit each U shaped support to the corresponding spot on the roof panel as shown in the diagram to the...
  • Page 15 9. ROOF REAR SUPPORTS “R” Mark “L” Mark Roof Rear ASSEMBLY supports 4x12 • Find the Rear Support marked with an Round “R” and attach it to the corresponding U Head Screw shaped support also marked with an “R”. Use two 4x12 mm round head screws to secure the supports, as shown at right.
  • Page 16 11. CARGO BASKET ASSEMBLY • Place the Basket into the four correspond- ing holes in the Hood and push down until it clicks into place. Use four 4x16 mm round head screws to secure the basket to the Hood, as shown in diagram 1. •...
  • Page 17 12. POWER SUPPLY CONNECTION Battery NOTE: The battery is disconnected for shipment to prevent the battery from draining. • Securely plug the battery connector into the control module connector. Control Battery Module Connector Connector 13. SEAT INSTALLATION • Find Seat Back that marked “6” on its back, also find the Seat Bottom marked Seat Bottom “7”...
  • Page 18 BATTERY CHARGING IMPORTANT! Before first time use, charge the battery for at least 18 hours. Charge the battery for at least 12 hours after each use of the ride-on toy. Never charge the battery longer than 30 hours. Overcharging or undercharging the battery may shorten battery life and decrease ride-on toy running time.
  • Page 19 • Do not charge the battery on a surface (such as a kitchen counter top) which could be damaged by the acid contained inside the battery. Take precautions to protect the surface on which you charge your battery. • Use only an original charger (AC 120V 60Hz) with an output of DC 24V (1A) to charge your ride-on toy battery.
  • Page 20 HOW TO USE YOUR RIDE-ON TOY Sound Button Foot Pedal 23.0 Power Switch Forward/Reverse Shift Lever POWER SWITCH • Turn the ride-on toy on or off. FOOT PEDAL • To move the car, press the foot pedal down. • To stop, take your foot off the foot pedal. FORWARD-REVERSE SHIFT LEVER •...
  • Page 21 Audio Input Cable (Included) Audio Input Jack MP3 here Audio Input Jack Use the Audio input cable (Included) to connect your MP3 player or other compatible audio device with this ride-on toy to listen to and enjoy music. 1. Plug one end of the audio input cable (Included) into the audio input jack on the ride-on toy as shown.
  • Page 22 IMPORTANT • Always stop ride-on toy when changing the direction to avoid damage to the gears and motor. • This ride-on toy has an adjustable seat belt; instruct children on how to fasten the seat belt before using. • Do not let any child touch the wheels or be near them when the car is moving. •...
  • Page 23 DETAILED MAINTENANCE AND REPAIR WARNING: Disconnect power supply before conducting any maintenance procedures. Phillips Screwdriver 17 mm Socket Wrench TOOLS REQUIRED: (included) (not included) Flat head Screwdriver Needle-Nose Pliers (not included) (not included) HOW TO REPLACE FRONT Axle Cap Front Wheel WHEEL Ø12 Spilt Pin...
  • Page 24 HOW TO REPLACE REAR WHEEL AND GEAR BOX 1. Remove the axle cap by sliding a flat head screwdriver along the edge of the cap and carefully prying the cap open. 2. Use needle nose pliers to remove the split pin in the hole of the rear axle end. 3.
  • Page 25 HOW TO REPLACE THE FOOT PEDAL 1. Use a flat head screwdriver to gently pry the LEFT side of foot pedal. 2. Gently remove the foot pedal. 3. Disconnect the old foot pedal from the pedal switch socket. 4. Replace and reconnect the new foot pedal to the pedal switch socket to ensure they are connected in the correct position (see Figure 3) and then insert the right side of the foot pedal into the foot pedal compartment first, and gently push down on the left side of the pedal so that it snaps into place.
  • Page 26 HOW TO REPLACE FORWARD-REVERSE SHIFT LEVER 1. Unscrew the two screws on the seat and remove the seat. 2. Unscrew four 4x12 round head screws as shown to remove the Forward-Reverse Shifter Assembly from the ride-on toy body (diagram A). 3.
  • Page 27 BATTERY CARE AND DISPOSAL Do not store the battery in temperatures above 75° F (23.5° C) or below 32° F (0°C). THIS PRODUCT CONTAINS SEALED LEAD ACID BATTERIES WHICH MUST BE RECYCLED IN ACCORDANCE TO YOUR LOCAL AND STATE LAWS PLEASE CAREFULLY READ AND UNDERSTAND THE FOLLOWING DISPOSAL INSTRUCTIONS: DISPOSAL: This product contains sealed lead acid batteries which must be...
  • Page 28 MAINTAINING YOUR RIDE-ON TOY Occasionally use a lightweight oil to lubricate moving parts such as wheels and the steering linkages. Park the ride-on toy indoors or cover it with a tarp to protect it from wet weather. Keep the ride-on toy away from sources of heat, such as stoves and heaters. Plastic parts may melt.
  • Page 29 TROUBLE SHOOTING GUIDE Problem Possible Cause Solution Ride-on toy Undercharged Charge the battery. A new battery should have does not run battery been charged for at least 18 hours before using the ride-on toy for the first time. After first-time use, recharge the battery for at least 12 hours after each use.
  • Page 30 Problem Possible Cause Solution Ride-on toy Loose wires or Check all wires and connectors. Make sure the was running connectors battery connector is tightly plugged into the but suddenly control module connector, and that there are no stopped loose wires around the motor. Tripped thermal fuse The thermal fuse may “trip”...
  • Page 31 Problem Possible Cause Solution Ride-on toy runs Undercharged battery Charge the battery. A new battery should have sluggishly been charged for at least 18 hours before using the ride-on toy for the first time. After first-time use, recharge the battery for at least 12 hours after each use.
  • Page 32 UPGRADE YOUR WARRANTY WITH PRODUCT REGISTRATION Free warranty upgrade with online registration at dynacraftwheels.com/register. We respect your privacy. Any information collected by Dynacraft Wheels will never be shared with any other company or organization. See Dynacraft's privacy policy for further information: dynacraftwheels.com/dynacraft-privacy-policy.
  • Page 33 This Warranty is not transferable to anyone else and is the only warranty for your Dynacraft product, to the extent permitted by law No other express or implied warranty is given, and except to the extent prohibited by applicable law, any implied...
  • Page 34 DO NOT RETURN THIS ITEM TO THE STORE CONTACT DYNACRAFT CUSTOMER SERVICE FOR ASSISTANCE dynacraftwheels.com/contact or 1-800-551-0032 9 – 5 Please have the following information available: Model Number Example: 8000-00 Production Date Example: MM.DD.YYYY Serial Number Example: DA00000000000 This information is required to help us handle your request effectively.
