AUTOMATIC FAUCET
Important Safeguards .............
Precautions ..............................
Model Number and
Components ..............
Before Use ...............................
How to Use ...............................
How to Adjust ..........................
Maintenance .............................
Periodical Checking ................
Troubleshooting ....................
Speci cations ..........................
WARRANTY
2006.3
1~2
2
3
4
4
5
6~7
7~8
9~10
10
Advertisement
Table of Contents
Related Manuals for Toto EcoPower TEL3GSC
Summary of Contents for Toto EcoPower TEL3GSC
- Page 1 0GU3007E 2006.3 NOTE TO INSTALLER : PLEASE GIVE THIS MANUAL TO THE CUSTOMER AFTER INSTALLATION. AUTOMATIC FAUCET Important Safeguards ..... Precautions ......Model Number and Components ....Before Use ....... How to Use ....... How to Adjust ......Maintenance ......Periodical Checking ....
- Page 2 Important Safeguards (For your safety, please follow the instructions below.) Read these Important Safeguards thoroughly before using your Automatic Faucet, and follow the precautions carefully. After you read this Instruction Manual, keep it where it can be easily referred to again. Symbols are shown for safe and proper use of your Automatic Faucet and in order to alert you possible personal injury and damage to your property.
- Page 3 Warning Do not touch the stop valve of the controller, the surface may be very hot. Don't touch This may cause personal injury. Controller For EcoPower model, disconnect the back-up battery connector, when the Automatic Faucet is not in use for a long period of time.
- Page 4 Model Number and Components < Model Number > Single Supply Faucet Thermal Mixing Valve Faucet EcoPower type Battery type EcoPower type Battery type ® ® Standard TEL3GSC TEL3DSC TEL5GSC TEL5DSC Gooseneck TEL3GGC TEL3DGC TEL5GGC TEL5DGC Duration of water discharge : 10 seconds Duration of water discharge : 60 seconds Spout Controller...
-
Page 5: Before Use
Before Use Con rmation of connectors Make sure all connections are made. Sensor connector (green) Back-up battery connector (for EcoPower type : white) Battery connector (for battery type : white) For Single supply faucet For Thermal mixing valve faucet Pull Back-up battery connector EcoPower... -
Page 6: How To Adjust
How to Adjust Bits of Knowledge About EcoPower Model Mechanism for Hydropowered generator The ow of water causes the turbine in the power generator to rotate, which generates electric power, and enables the Automatic Faucet to operate. Power generator Spout Cover A turbine rotates to generate power. -
Page 7: Maintenance
Maintenance Follow these instructions for daily maintenance. Use soft cloth for maintenance For general cleaning Use a damp, soft cloth to clean the spout and the sensor. For cleaning dirt Use a soft cloth with diluted dish washing detergent. Wipe the area using a wet cloth and dry using a soft cloth. Caution Do not scratch the sensor when cleaning. -
Page 8: Periodical Checking
Battery Replacement Procedure (Battery operated models) For Single supply faucet For Thermal mixing valve faucet 1. Remove the controller cover. (See page 4) battery case controller controller 2. Detach the battery connector (white). battery case 3. Remove the rubber cover from the battery case and replace the AA alkaline batteries. - Page 9 Loose spout Check if the spout is loose. If the spout is loose, tighten the hexagonal nut underneath the spout. Flow rate When the strainer or spout nozzle is clogged, the ow rate will decrease. Make sure to clean the strainer and the spout nozzle. Close Pay special attention to the Eco power model, since low ow rate may result in low power generation.
-
Page 10: Troubleshooting
Troubleshooting Before contacting a repairman, check the following common problems and solutions. If the problem persists contact your dealer. Problem Cause Solution Ref. page The surface of the sensor is dirty. Clean the surface of the sensor. There is an obstruction in front of the sensor. Remove the obstruction. -
Page 11: Speci Cations
This automatic faucet is equipped with a self-adjusting sensor which automatically adjust its detection range once every 15 seconds. This sensor may exhibit the following phenomena. Note these are implemented for safety and conservation purposes, they are not malfunctions. Phenomenon Explanation The sensor activates by detecting hand movements. - Page 12 WARRANTY 1. TOTO warrants its products to be free from manufacturing defects under normal use and service for a period of three (3) years from the date of purchase. This warranty is extended only to the ORIGINAL PURCHASER and applies only to product purchased and installed in North America.
