ASROCK IMB-1310 Settings Manual

*15G06M067000AK*
P/ N: 15G06M067000AK V1.0
IMB-1310
The terms HDMI™ and HDMI High-Definition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
COM Port Pin9 PWR Setting Jumpers
1 : PWR_COM3 (For COM Port3)
22 : PWR_COM2 (For COM Port2)
PWR_COM1 (For COM Port1)
PWR_COM4 (For COM Port4)
2 : Panel Power Select (PNL_PWR1)
1-2 : +3V
2-3 : +5V
4-5 : +12V
3 : BL2
Open: Protect LCD_VCC
Short: No Protect LCD_VCC
4 : LVDS Panel Connector
* PD (Panel Detection): Connect this pin to LVDS Panel's Ground pin to
detect Panel detection.
5 : Backlight & Amp Volume Control
(BLT_VOL1)
PIN Signal Name
7 GND
6 GND
5 GPIO_BLT_DW
4 GPIO_BLT_UP
3 PWRDN
2 GPIO_VOL_DW
1
1 GPIO_VOL_UP
Jumpers and Headers Setting Guide
1
LVDS1
1
1
1
1
PWR_BAT1
CMOS
Battery
USB 3.0
Top:
T: USB1
RJ-45
1
B: USB2
1
USB 3.0
Top:
T: USB3
RJ-45
B: USB4
BUZZ1
PCIE2
SPEAKER1
1
1
HD_AUDIO1
USB2_5_6
SPDIF1
USB2_PWR1 USB2_PWR2
1 1 1
1
BUZZ2
6 : Inverter Power Control Wafer
(BLT_PWR1)
7 : Backlight Control Level (BLT_PWM1)
(CON_LBKLT_CTL)
1-2 : +3V
2-3 : +5V
8 : BL1
Open: Protect LCD_BLT_VCC
1
Short: No Protect LCD_BLT_VCC
39
1
9 : Backlight Power Select
(LCD_BLT_VCC) (BKT_PWR1)
2 40
1-2 : LCD_BLT_VCC : +5V
2-3 : LCD_BLT_VCC : +12V
10 : CPU FAN Connector (+12V)
FAN_SPEED_CONTROL
11 : 24-pin ATX Power Input Connector
12 24
1 13
12 : PWR LOSS Header (PWR_LOSS1)
Short : Power Loss
Open : no Power Loss
BKT_PWR1
1
1
BL1
1
1
CPU_FAN1
1
BLT_PWM1
IMB-1310
CHA_FAN1
Industrial
PCIE1
PCI1
PCI2
SATA3_1 SATA3_3
USB2_7_8
1
1 1
SATA3_2 SATA3_4 CLRMOS2
PIN Signal Name
1 GND
2 GND
3 CON_LBKLT_CTL
4 CON_LBKLT_EN
5 LCD_BLT_VCC
1 6 LCD_BLT_VCC
3 2 1
1
3 2 1
GND
+12V
CPU_FAN_SPEED
1
SIO_AT1
1
BIOS
ROM
1
1
1
JGPIO_SET1
CI1
1
1
COM1
CI2
1
1 LPC1
1 1
COM2 COM4
PLED PWRBTN
1 1 1
1
CLRMOS1 PWR_COM2 PWR_COM1 PWR_COM4
HDLED RESET
PANEL1
13 : ATX/AT Mode Jumper (SIO_AT1)
Open: ATX Mode
Short : AT Mode
14 : Chassis FAN
Connector (+12V)
15 : Printer Port / GPIO Header (LPT_GPIO1)
Printer Port:
PIN Signal Name PIN Signal Name
SLCT
26
GND PE
GND BUSY
24
GND ACK#
22
GND SPD7
20
GND SPD6
18
GND SPD5
GND SPD4 16
GND
SPD3
14
SLIN# SPD2
12 JGPIOPWR
PINIT# SPD1
10 JGPIOPWR
ERROR# SPD0
8 SIO_GP43
AFD# STB#
1
6 SIO_GP44
4 SIO_GP45
2 SIO_GP46
* If you want to use the printer port function, please short pin4 and pin5 on
Digital Input / Output Power Select (JGPIO_PWR1).
16 : Digital Input / Output Default Value
Setting (JGPIO_SET1)
1-2 : Pull-High
2-3 : Pull-Low
17 : LPC Header
+3.3V STANDBY
18 : Digital Input / Output Power Select
(JGPIOPWR) (JGPIO_PWR1)
1-2 : +12V
2-3 : +5V
3-4 : +5V
4-5: GND
1
GND
+12V
CHA_FAN_SPEED
FAN_SPEED_CONTROL
GPIO:
NC 25 NA
GND 23 SIO_GP30
GND 21 SIO_GP31
GND 19 SIO_GP32
GND 17 SIO_GP33
GND 15 SIO_GP34
GND 13 SIO_GP35
11 SIO_GP36
9 SIO_GP37
7 SIO_GP40
5 SIO_GP41
3 SIO_GP42
1 SIO_GP47
1
PCICLK GND
FRAME SMB_CLK_MAIN
PCIRST# SMB_DATA_MAIN
LAD3 LAD2
+3.3V LAD1
GND
LAD0
S_PWRDWN#
SERIRQ#
GND GND
+5V 48MHz
