Heltun HE-HLS01 User Manual

High load switch
Hide thumbs Also See for HE-HLS01:

Advertisement

Quick Links

HIGH LOAD SWITCH
HE-HLS01 USER MANUAL
v1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HE-HLS01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Heltun HE-HLS01

  • Page 1 HIGH LOAD SWITCH HE-HLS01 USER MANUAL v1.0...
  • Page 2: Table Of Contents

    Parameters ................................. 15 External Input Configuration ............................. 16 Power and Energy Consumption ..........................17 Z-Wave Network ................................17 Including HE-HLS01 to an Existing Z-Wave Network ....................17 Removing HE-HLS01 from Z-Wave network ......................18 Security ..................................18 SmartStart .................................. 18 Associations ................................
  • Page 3: Overview

    Based on the latest Z-Wave platform The HE-HLS01 integrates a Z-Wave Plus™ v2 700 platform module allowing it to be used with Z-Wave home automation systems. The HE-HLS01 supports Z-Wave ‘S0’ and ‘S2’ security protocols, SmartStart technology, and can be connected (associated) to other Z-Wave devices, such as relays, motor controllers, dimmers, etc.
  • Page 4: Functions & Features

    – min. depth 40mm Functions & Features The functions and features of HE-HLS01 could be different depending on how the device is included in Z- Wave network. Depending on the number of button presses (two or four) during the inclusion process HE- HLS01 could function as either “Binary...
  • Page 5: Installation

    Temperature hysteresis selection range: 0.2°C (1°F) to 10.0°C (18°F) Installation The HELTUN HE-HLS01 High Load Switch must be be installed by a licensed electrician in a manner that conforms to local regulations and building codes. Provide these instructions to the licensed electrician who is installing the HE- HLS01.
  • Page 6: Disassembly

    Note: If an NTC sensor other than 10 kΩ is used, you must change the sensor resistance value in Parameter 8. 4. If you will be using an external device to select modes for the HE-HLS01 (such as a security system or wall switch), connect wires from the external device’s dry contacts to the two HE-HLS01 terminals labeled “S1”...
  • Page 7: Common Configurations

    Common Configurations 1-30 configuration parameters are common for both “Binary Switch” and “Thermostat” device types. All configuration parameters are accessed through COMMAND_CLASS_CONFIGURATION Parameter Parameter Default Parameter Name Available Values Number Size Value 1 byte DEVICE TYPE 0, 1 0 … 9 1 byte FREQUENCY REGION 1 byte...
  • Page 8: Time Configuration

    Parameter 04 – Time Correction by Gateway If this Parameter value = 1 and the HE-HLS01 is connected to a Z-Wave gateway, the HE-HLS01 time and day will be periodically polled and corrected from the gateway. To switch off auto-correction set the Parameter value to 0. The factory default value is 1.
  • Page 9: Protections And Notifications

    Parameter 10 – Temperature Scale Mode This parameter determines in which unit of measurement (degrees Celsius or Fahrenheit) the device will report the temperature, and also determines the scale that will be interpreted by the configuration parameters. Set the value 0 for Celsius and the value 1 for Fahrenheit.
  • Page 10 Parameter 16 – Temperature Rise Notification Use this parameter if you want to know about temperature rise before it reaches the critical value, defined in the “Overheat Protection” parameter. The device will send “Rapid Temperature Rise” notification to the gateway if the temperature sensor reading reaches the value defined in this parameter.
  • Page 11: Device Type "Binary Switch

    Device type “Binary Switch” These parameters will take affect only in case if the device is included in the Binary Switch mode. For more information about the different inclusion modes see the section Z-Wave Network. Default Number Size Name Available Values Value 1 byte LOAD ON NOTIFICATION...
  • Page 12: Auto On/Off Function

    Note: The function works only if the device is AC powered. External Input Configuration The HE-HLS01 can be connected to the dry output contacts of an external device (i.e. security system or wall switch) to control the Switch output state depending on the state of the external device.
  • Page 13: Scenarios

    Parameter 39 – External Input: Click Control Mode 0 – Click function disabled 1 – Toggle switch: relay inverts state (ON to OFF, OFF to ON). 2 – Relay switches to ON state only 3 – Relay switches to OFF state only 4 –...
  • Page 14: Device Type "Thermostat

    This mode is recommended for use if a high floor temperature is required for a limited period of time. For example, after washing the floor. By choosing DRY Mode, the HE-HLS01 will increase the temperature to the selected Set Point for the time specified in the “Dry Time”...
  • Page 15: Parameters

    Parameters These parameters will take affect only in case if the device is included in the Thermostat mode. For more information about the different inclusion process see the section Z-Wave Network. Default Number Size Name Available Values Value 1 byte LOAD ERROR NOTIFICATION 0, 1 2 …...
  • Page 16: External Input Configuration

    This Parameter defines which Operating Mode the HE-HLS01 reverts to if the Basic Set command is received. If the Basic Set command value is 0 (OFF state) the HE-HLS01 will go to Manual mode and switch Off the heating element (IDLE mode).
  • Page 17: Power And Energy Consumption

    To add the HE-HLS01 to an existing Z-Wave network (i.e. “inclusion”), do the following: 1. Ensure the HE-HLS01 is Powered On and the LED indicator blinks red slowly (i.e. it is excluded). 2. Start the Inclusion Mode from the gateway/controller.
  • Page 18: Removing He-Hls01 From Z-Wave Network

    Note: It is not recommended to modify this group. Group 2 – “Relay Basic Set”: is assigned to the HE-HLS01 relay state. It sends a Basic Set command with value 255 (On) when relay goes to On state and sends 0 (Off) when relay goes to Off state. Max supported nodes: 1 Group 3 –...
  • Page 19: Z-Wave Plus V2 Specifications

    The device also can receive Basic Set command via associations. In the “Binary Switch” mode the device will change the relay state according to the value in Basic Set command. In the “Thermostat” mode the device will change the operating more according to the Parameter 33 value. Z-Wave Plus V2 Specifications Thermostat Generic Device Class: GENERIC_TYPE_THERMOSTAT Thermostat Specific Device Class: SPECIFIC_TYPE_THERMOSTAT_GENERAL_V2...
  • Page 20: Notification Types

    If during the Warranty Period the product is determined to be defective or malfunctions due to workmanship or materials, HELTUN, at HELTUN's option, shall either repair or replace the defective product. If the product is defective, (i) return it with dated proof of purchase to the place it was purchased;...
