UTV/Rockcrawler Quad Camera and DVR Monitor
Please read thoroughly before starting installation and check that kit contents are complete.
Items Included in the Kit:
Roll Bar Mounts (1.5" 1.75" 2")
7" Quad Screen Monitor with DVR
IR Remote
Monitor Sun Shade
Front Camera W/Extension cable
Rear Infrared Camera W/Extension cable
SUTV-1040 Miscellaneous Parts Package
SUTV-1020V2 8-10-20
I NSTALLATION INSTRUCTIONS
(Kit #SUTV-1020V2)
Tools & Supplies Needed:
Plastic Trim Removal Tool
Phillips Screwdriver
Center Punch/Scribe Tool
Power Drill
1/2" Drill Bit
Wire Ties
Soldering Iron & Solder
Tape or Heat Shrink Electrical Tubing
Page 1 of 3
( Recommended)
Advertisement
Related Manuals for BrandMotion SUTV-1020V2
Summary of Contents for BrandMotion SUTV-1020V2
- Page 1 I NSTALLATION INSTRUCTIONS UTV/Rockcrawler Quad Camera and DVR Monitor (Kit #SUTV-1020V2) Please read thoroughly before starting installation and check that kit contents are complete. Items Included in the Kit: Tools & Supplies Needed: Roll Bar Mounts (1.5” 1.75” 2”) Plastic Trim Removal Tool 7”...
- Page 2 ● NOTE: We strive to provide accurate and up-to-date installation instructions. For additional assistance please call Brandmotion Technical Assistance at (734) 619-1250 then dial 2. Rear Camera Installation: 1. Remove the 4 Allen screws that are located on the sides of the camera. Then remove the camera mounting bracket and visor.
- Page 3 Also needs the composite video output cable ran to Video inputs on monitor. (1-3). Can be hooked up to desired orientation on video screen. All outside connections please use supplied heat shrink as to not VOID WARRANTY. SUTV-1020V2 8-10-20 Page 3 of 3...
