BrandMotion 9002-2750v1 Installation Instructions

Myford factory display radio camera interface for 4.2” display

Advertisement

Quick Links

MyFord Factory Display Radio Camera Interface
Please read thoroughly before starting installation and check that kit contents are complete.
Items Included in the Kit:
Video input T-harness
Interface box
Instructions
Safety Precautions:
• Work in well ventilated area that is clear of obstructions.
• Secure vehicle with tire chucks in both front and rear of tires.
• Turn vehicle accessories OFF and ensure ignition key is in OFF position.
• Wear safety goggles and snug fitting clothes.
• Use tools only for their intended purpose and which are in good repair.
• Only perform this task if confidence, skill, and physical ability permit.
NOTE: We strive to provide accurate and up-to-date installation instructions. For the latest full color
instructions, as well as an installation video, please visit
9002-2750v1.doc instructions V1
For 4.2" Display
(Kit # 9002-2750v1)
Tools & Supplies Needed:
7-12-16
Page 1 of 5
INSTALLATION INSTRUCTIONS
Plastic trim removal tool
7 mm socket
Phillips screw driver
Wire strippers
Wire cutters
Electrical tape or Heat shrink
www.brandmotion.com
JM
