Page 4
Explanatory text is also given for more complicated steps. In the event of any problems with the instructions or the accessory, contact your local Volvo dealer. Note! On cars being installed with the portable Navigation system and TMC kit, the short cable harness in the Navigation system kit (see image) must not be used.
Page 5
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the ventilation outlet by carefully inserting special tool 9995919 between the ribs and carefully pulling up the four catches on the lower edge. Carefully pry using a weatherstrip tool. Note! Pay particular care to the dashboard and the outlet ribs. These can easily be damaged as the outlet is mounted very firmly.
Page 6
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Open the glovebox. Carefully pry off the panel inside the centre console. Use a plastic weatherstrip tool. The panel is secured by two clips on each of the short sides. Pull the panel away downwards.
Page 7
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Detach the surround around the display and the media player by pressing in the catch at the edge of the media player cover. Use a small screwdriver. Carefully pry off the surround at the corner.
Page 9
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to cars with manual gearbox Remove the gear selector lever boot from the center console. First pry it off at the front edge using a weatherstrip tool and then unhook it at the rear edge.
Page 10
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to all models Remove the two screws holding the centre console at the rear edge. IMG-263584 Applies to the C70 Remove the rear seat cushion by first pressing the outer edges of the cushion backwards and then by pulling them upwards so that the outer hooks release.
Page 11
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Lift the cushion straight up in the middle so that the inner hooks release. IMG-263945 Remove the rear cup holder from the rear tunnel compartment by prying at the leading edge and pressing in the catches, first at the leading edge and then on the sides.
Page 13
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to all models Remove the two screws along the front edge of the tunnel console. IMG-279050 A and B Carefully pull up the lock catch with special tool 9995919. At the same time, slide the whole tunnel console backward so that the two rear screws in the centre console's panel can be accessed.
Page 14
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the two screws. IMG-263589 Remove the two screws holding the centre console to the dashboard. Remove the connector on the reverse of the dashboard environment panel. Remove the centre console's panel from the dashboard and tunnel console.
Page 15
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the two clips securing the cables to the media player by first pressing them to the sides and then pulling them away downwards. Note! Make sure that the optic cables are not bent or stretched. They may not be bent with a radius less than 25 mm (1").
Page 16
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to cars with and without speaker grilles Press in the catch and disconnect the connector on the underneath of the GPS cradle. IMG-311843 Disconnect the two green connectors on the cable for the cradle from each other.
Page 17
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take cable harness A and TMC unit C from the kit and connect the larger green connectors to each other. IMG-311903 Take the foam tape from the kit and remove the protective tape from it.
Page 18
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Wrap the foam tape around the ferrite and the green connectors to prevent any rattling. IMG-311905 Now take the gray connector on the joined cable harnesses and connect underneath the GPS cradle.
Page 19
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Carefully pry up and remove the catch in the receptacle housing on the cable terminal for the socket marked 1 in the contact to the media player. Use a thin pointed object.
Page 20
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take the antenna cable B from the kit. Carefully pry up the catch and pull out the cable terminal from the receptacle housing. IMG-312006 Take the newly removed receptacle housing and carefully push it into the loose cable terminal on the contact in the cable for the media player.
Page 21
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take the loose cable terminal in the antenna cable B and carefully secure the receptacle housing to the cables for the media player. IMG-312024 Press the catch securely into the receptacle housing.
Page 22
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Connect the previously disconnected cable terminal on the cable from the media player's receptacle housing to IN on TMC unit C. IMG-312026 Connect the remaining end to antenna cable B to OUT on TMC unit C.
Page 24
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Clamp the cable excess around the TMC unit using a cable tie from the kit. Ensure that there is enough excess to connect the antenna cable to the media player and the cable to the GPS cradle.
Page 25
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden A and B Connect the disconnected connectors to the media player. Note! Space is confined at the media player and there are many cables so take care to ensure that it is positioned so that no cables are trapped or are at risk of being chafed.
Page 26
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden A and B Now position the cable harnesses from the GPS cradle and the hazard warning flasher in-between the two air ducts, when pushed into position. Secure the two small green connectors from the thin cable harness from the GPS cradle using a piece of butyl tape in a suitable position to prevent rattling.
