Page 4
Certain steps in the instructions are only presented in the form of images. Explanatory text is also given for more complicated steps. In the event of any problems with the instructions or the accessory, contact your local Volvo dealer. Note! This accessory requires software unique to the car. Note! For European users, the TMC unit, part number 6849907, can be purchased separately.
Page 5
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Place the driver's seat in its rearmost position. Turn the ignition switch to position 0. Disconnect the battery negative lead Note! Wait at least one minute before unplugging the connectors or removing other electrical equipment.
Page 6
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to cars without centre loudspeakers Remove the bracket for the loudspeaker grille by removing the five screws and pulling the grille up from the dashboard. Applies to cars with a centrally mounted loudspeaker Remove the five screws in the loudspeaker.
Page 8
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the two screws. IMG-326558 Remove the bracket with the A/C panel and radio from the center console. Pull from the lower edge and then downwards until it releases from the mounting at the upper edge.
Page 10
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Does not apply to cars with Volvo On Call (VOC) Pry off the covers on the grab handle in the right-hand front door and remove the screws under them. R8504175 Pull of the weatherstrip (1) for the door at the A-pillar.
Page 11
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Detach the rear-view mirror and front interior lighting (1) by first removing the two screws (2) and then pressing in the eight catches (3) around the interior lighting. Carefully pull the components downwards and allow them to hang from their cables.
Page 12
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Install the cover over the antenna. For cars with a rain sensor, use the larger cover from the kit. For cars without a rain sensor, use the smaller cover from the kit.
Page 13
Connect both connectors (1) at the A-post to each other. Wrap foam tape around the connectors to prevent rattling. IMG-250470 Applies to cars with Volvo On Call (VOC) Applies to cars with Volvo On Call (VOC) Locate the joint on the existing antenna cable. Disconnect the connector, this will not be reused.
Page 14
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to all cars Take the cable harness (A) from the kit. IMG-393650 Note! Do not damage the fibre optic cables. They must not be bent to a radius less than 30 mm (1 11/64") as they can damage and affect the function of the system.
Page 15
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-268410 Take the cable with the two 4 pin connectors and route forward on the driver's side Locate the 4 pin, grey connector for the power supply. It is secured on the thick cable harness under the dashboard on the driver's side.
Page 16
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Reinstall the A post panel. Tighten the grab handle to 10 Nm (7.5 lbf. ft.) and reinstall the covers. Reinstall the rubber trim in the right-hand front door. Reinstall the panel on the dashboard end face.
Page 17
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Connect the TMC cable (Europe) as illustrated. Connect the TMC wiring between IAM and the existing connector in the car's cable harness. IMG-250477 Note! It is important that the wiring is connected to the Integrated Audio Module (IAM) and not the Infotainment Control Module (ICM).
Page 18
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take the bend protection from the kit and attach it with tape as illustrated. The bend protection is to prevent the fiber optic cable from bending too much, being damaged and risking malfunction of the accessory.
Page 19
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take the Multimedia Module (MMM) from the kit and remove the protective plug from the connector to the fibre optic cable connection. R3903835 Connect the pre-routed cables to the Multimedia Module (MMM) the cable (1) for the display screen.
Page 21
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the screws. IMG-351388 Remove the surround for the combined instrument panel IMG-308587 Turn the steering wheel 90º to the position shown in the illustration and so that the two holes on the back side are accessible.
Page 22
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Insert a screwdriver in the hole along the rear edge of the steering wheel perpendicular to the rear surface of the steering wheel. Insert the screwdriver as far as possible to find the end of the locking spring (1).
Page 23
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Turn the steering wheel to the left so that the right-hand side of the steering wheel points to the left. Take the cutting template from the kit and secure it to the right- hand side of the steering wheel as illustrated.
Page 24
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Cut away some of the material on the back side of the steering wheel spoke. Test and cut until the keypad fits properly. R3904966 Remove the keypad, two screws and clamp from the kit.
Page 25
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Position the horn ring and position it as illustrated. Plug in the installed keypad connector to the terminal on the back side of the keypad on the right-hand side of the horn ring. The cable from the installed keypad is very short and it is not easy to plug into the connector.
Page 26
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Reconnect the battery negative lead IMG-336901 Warning! When the ignition is to be switched on for the first time after the battery has been disconnected, this must be done whilst by standing outside the vehicle, stretching your arm in and avoiding the working area for the airbags Set the ignition key to position II.
